Winix HR1000 Bedienungsanleitung

WINIX AIR CLEANE

HR1000

User Manual

xPlease read and follow all safety rules and instructions in

this manual before operating.

xThe product warranty is printed on the back of this guide,

so please keep it in a safe place for future use.

Model

Use & Care

Guide

English HR 1000

CONTENTS

Set Up

Where to use 5

Installing the filters 6

Safety Instructions

Safety and Cautions 8

Operation

Initial Operation 9

Modes of Operation 10

Features and Settings 11

WINIX SMART Set Up 13

Care and Maintenance

Filter Care 14

Smart Sensor Care 18

Cleaning Care 19

Troubleshooting

Frequently Asked Questions 20

Unit Specifications 22

Product Warranty 24

5-Stage Air Purification 3

Controls 4

This product is suitable for 220 ~ 240V only.

French 25

Spanish 49

German 73

Italian 97

Nederlands 121

English HR 1000

PlasmaWave®

4 Anti-microbial coated

3 True HEPA filter 2 (CD) Coated Deodorization

Carbon filter

1 Pre-filter

5-STAGE AIR PURIFICATION

non-removable

replaceable

washable

replaceable

PACKAGE CONTENTS

Product

Pre-filter/CD Carbon Filter/

Anti-microbial True HEPA filter

(Included with the product.)

Power cord with

plug

User Manual

English HR 1000

Air

Outlet

Vent

Light Sensor

Detects the amount of

ambient light within

the environment, to

adjust the brightness

of the LED indicators.

Timer Indicator

If timer has been set, the LED

light Indicates the set time of

operation.

PlasmaWave® Indicator

Indicates whether

PlasmaWave® is

enabled or disabled.

Smart Sensor

Automatically

detects indoor air

quality.

Child Lock Indicator

LED light indicates

whether Child Lock mode

is enabled or disabled.

Wi-Fi Strength Indicator

Displays the strength of the Wi-Fi

connection.

Mode / Fan Speed Button

Every time the Mode button is

pressed, the Mode LED light will

cycle through the settings. (Auto,

Sleep, Low, Medium, High, Turbo)

Power Button

Turns the unit on or

off.

Timer / Air Quality Button

Press to cycle through and set

desired length of operation (1hr,

4hr, 8hr, [NO TIMER]).

Press and hold for 3 seconds to

enable or disable the Air Quality

light.

PlasmaWave® / Child Lock Button

Enables or disables PlasmaWave®. Press and hold for 3

seconds to enable or disable the Child Lock mode.

Check Filter

Indicator

LED light indicates

when it is time to

change the filter.

Reset Button

After replacing a filter, press

the RESET button for at least

5 seconds.

CONTROLS

Wi-Fi Button

Enables or disables

Wi-Fi function.

WINIX SMART

Indicator

LED light indicates

when WINIX SMART is

active with your unit.

Installation | Set up

English HR 1000

WARNING Follow these instructions to reduce the risk of serious

injury or death and to reduce risk of damaging the unit.

WHERE TO USE

Do not use around mist or fumes from

industrial oil or around large quantities of

metallic dust

Do not install in any sort of motor or

transport vehicle (trucks, boats, ships, etc.)

Do not place near any flammable materials

(aerosols, fuel, gases etc.)

Do not place below any electrical outlet

Do not place around heating elements

Do not place in an area with excessive

amounts of noxious gases

Do not have unit facing into wind or draft

Do not place in excessively humid areas

where unit may become wet

Allow 30 ~ 46 cm. of space between TVs, radios, and other electronic products

electromagnetic interference from certain electronics may cause product malfunction.

Place indoors away from direct sun light

direct exposure may cause product malfunction or failure.

Only place on hard, flat surfaces

flimsy or slanted surfaces may result in abnormal noise and vibrations.

This unit is not intended to be used to preserve documents or in art conservation.

30~46 cm

10 cm

Set up | Installation

English HR 1000

3 Anti-microbial

True HEPA filter

CD Carbon

filter

1 Pre-filter

INSTALLING THE FILTERS

This product comes with all of the required filters. The protective plastic wrap must be

removed from the filters before use.

Operating the unit without removing the plastic wrap may result in product failure.

Unplug and make sure the unit is turned off before installing filters.

The unit will automatically power off when front panel is opened.

󰴤Remove the front panel by grasping

its upper edge and gently pulling

towards yourself.

xTo remove the front panel, the latch

at the lower edge of the panel must

be released from its position. Latch

󰴥Remove the filters from the unit,

they are protected inside a plastic

wrap.

󰴦Remove filters from protective

plastic wrap.

xOperating the unit without removing

lters from plastic may cause abnormal

noise, deformation, or re as a result of

overheating.

󰴧Install the filters until they fit

securely in place.

Filters must be installed in this order:

3Anti-microbial True HEPA filter

(rear)

2CD Carbon filter (middle)

1Pre-filter (front)

xTo install the pre-lter, insert

bottom tabs into the slots on either side

of the lower part of the unit, then rotate

upward to insert the upper tabs into the

slots at the top part of the unit until both

sides audibly click into place.

Installation | Set up

English HR 1000

󰴨Replace the front panel by first

inserting the latch at the bottom

edge into the base of the unit, then

rotate the panel upward toward the

top of the unit until it magnetically

snaps closed.

󰴩When to service and replace filters:

Filter Indicator Light When to

service

When to

replace

1Pre-filter none Clean once

every 14 days Permanent

2 CD Carbon filter

Can NOT be

WASHED

Lasts up to

12 months

3 Anti-microbial True

HEPA filter

Intervals between filter replacement may vary depending on environment.

For optimal use, Pre-filter can be cleaned every 14 days which can extend the life of

other filters.

▶Refer to pages 14-18 for detailed information on filter care and

how to replace them.

INSTALLING THE FILTERS

this unit

is compatible

with this

filter

ITEM: 117130

FILTER

Safety Instructions | Operation

English HR 1000

SAFETY AND CAUTIONS

Before operating this equipment, carefully read and follow these safety cautions and

instructions to avoid damage and ensure safe use.

WARNING Follow these instructions to reduce the risk of serious

injury or death and to reduce risk of damaging the unit.

Ensure filters are inserted before running unit

running unit without filters can shorten the units life and cause electric shock or injury.

Be sure foreign objects are NOT inserted into the vents on the unit

objects can include pins, rods, and coins.

Do not touch any part of the interior of the unit with wet hands

the high voltage may cause electric shock.

Ensure unit intake and outlet vents do not become blocked

blockage may lead to increased internal temperatures causing product failure and deformation.

Do not use the unit as a step stool or place heavy objects on it

personal injury may occur or product failure and deformation.

Do not pull on the power cord when

unplugging the unit

Do not touch the plug with wet hands

Do not plug additional appliances into the

same outlet or power supply

Unplug unit when not in operation for

extended periods of time

Do not tie or knot power cord when unit

is in operation

Do not unplug or move the unit while in

operation

If the unit becomes submerged in water,

unplug it and contact customer service

Cord can become damaged by forcefully

bending, pulling, twisting, bundling,

pinching or placing heavy objects on it

If the supply cord is damaged, it must be replaced by a special cord or assembly

available from the manufacturer or its service agent.

This appliance is not intended for use by a person (including children) with reduced

physical sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by

a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

Operating the air cleaner | Operation

English HR 1000

󰴤Insert the unit plug into an electrical outlet.

xThe Control Panel lights will turn on and o.

󰴥Press the [Power] button.

▶During the first 4 minutes of power up,

the Air Quality light will flash as the

Smart Sensors measure the air quality in

the environment, after which normal

operation will begin.

󰴦By default, when the unit first powers on, the mode will be set to Auto

with PlasmaWave® enabled.

xWhen in Auto Mode the fan speed will be automatically adjusted according to the

environments air quality.

xPlasmaWave® works to remove harmful airborne contaminants.

▶In Auto mode, as the indoor air quality improves, the fan speed

will automatically be reduced to Low.

▶When the unit is running, you may hear a chirping or buzzing

sound. The sound is from large particles passing through

PlasmaWave®, it is normal and does not signify product failure. To

disable PlasmaWave®, see page 11.

INITIAL OPERATION

Operation | Operating the air cleaner

English HR 1000

1. Auto Mode

Enables Auto operation based on the unit's air quality Smart Sensors.

󰴤Press the Mode button to select Auto mode.

xThe mode LED light will indicate when‘Auto’ mode has been selected, and

operation will begin.

xEach time the Mode button is pressed, the modes will be cycled.

(Auto, Sleep, Low, Medium, High, Turbo).

▶

▶When in Auto Mode the fan speed is automatically adjusted

according to the indoor air quality. As the indoor air quality

improves, the fan speed will automatically be reduced. If the

indoor air quality decreases the fan speed will automatically be

increased.

▶When unit is first started, Auto Mode is enabled and set to Low

fan speed.

2. Sleep Mode

󰴤Press the Mode button to select Sleep

mode.

xThe mode LED light will indicate when‘Sleep’

mode has been selected, and operation in

that mode will begin.

▶When Sleep mode is selected, the fan

speed is automatically set to Low. Fan

speed can be changed by pressing the

Fan Speed (Mode) Button.

▶When Sleep Mode is enabled, the Air

Quality light is disabled.

AUTO AND SLEEP

Every time the Mode button is pressed, the Mode LED light will cycle through the

settings. (Auto, Sleep, Low, Medium, High, Turbo)

Andere Handbücher für HR1000

Inhaltsverzeichnis

Sprachen:

Andere Winix Luftreiniger Handbücher

Winix

Winix NK305 Bedienungsanleitung

Winix

Winix HEPA 5500 Bedienungsanleitung

Winix

Winix ZERO+ WiFi Bedienungsanleitung

Winix

Winix ZERO Bedienungsanleitung

Winix

Winix FreshHome PlasmaWave WACP150 Bedienungsanleitung

Winix

Winix FreshHome PlasmaWave WACP150 Bedienungsanleitung

Winix

Winix U300 Bedienungsanleitung

Winix

Winix ZERO Bedienungsanleitung

Winix

Winix C535 Bedienungsanleitung

Winix

Winix C535 Bedienungsanleitung

Winix

Winix 5500-2 Bedienungsanleitung

Winix

Winix Zero AUS-1050AZBU Bedienungsanleitung

Winix

Winix ZERO AZBU330-HWE Bedienungsanleitung

Winix

Winix T810 Bedienungsanleitung

Winix

Winix 5300-2 Bedienungsanleitung

Winix

Winix NK300 Bedienungsanleitung

Winix

Winix ZERO Bedienungsanleitung

Winix

Winix 5500-2 Bedienungsanleitung

Winix

Winix C545 Bedienungsanleitung

Winix

Winix AAPU500-JLE Bedienungsanleitung

Winix

Winix AM90 Bedienungsanleitung

Winix

Winix 9500 Bedienungsanleitung

Winix

Winix ZERO Pro Bedienungsanleitung

Winix

Winix Tower XQ Bedienungsanleitung

Beliebte Luftreiniger Handbücher anderer Marken

IKEA

IKEA UPPÅTVIND Bedienungsanleitung

Nash

Nash AP-1 PureSmart Bedienungsanleitung

LG PH-U450 Series Bedienungsanleitung

DeLonghi

DeLonghi DDSX 220WFA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Bedienungsanleitung

Sharp

Sharp FU-40SE Bedienungsanleitung

Philips

Philips AC2721 Bedienungsanleitung

Hitachi

Hitachi EP-A3000 Bedienungsanleitung

TruSens

TruSens Z-2000 Bedienungsanleitung

Motorola

Motorola MBP87SN Bedienungsanleitung

Beko

Beko ATP 7100I Bedienungsanleitung

Carrier

Carrier INFINITY 1620 Bedienungsanleitung

AtmosAir

AtmosAir P2002 Bedienungsanleitung

Friedrich

Friedrich C-90A Bedienungs- und Montageanleitung

Surgically Clean Air

Surgically Clean Air JADE2.0 Bedienungsanleitung

Base aire

Base aire 555 Pro Bedienungsanleitung

Champion

Champion CP25 Bedienungsanleitung

vollara

vollara Air & Surface Pro+ Bedienungsanleitung
