WinPAC-5000 Series User Manual, Version 1.0.2 Page: 1

WinPAC-5000 User Manual

(WinCE Based, eVC & .net)

Version 1.0.2, December 2010

Service and usage information for

WinPAC-5141

WinPAC-5441

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 2

Warranty

All products manufactured by ICP DAS are under warranty regarding

defective materials for a period of one year, beginning from the date

of delivery to the original purchaser.

Warning

ICP DAS assumes no liability for any damage resulting from the use of

this product.ICP DAS reserves the right to change this manual at any

time without notice. The information furnished by ICP DAS is believed

to be accurate and reliable. However, no responsibility is assumed by

ICP DAS for its use, not for any infringements of patents or other

rights of third parties resulting from its use.

Trademark

The names used for identification only may be registered trademarks

of their respective companies.

If you have any problem, please feel free to contact us.

You can count on us for quick response.

Email: [email protected]om

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 3

Table of Contents

1. Introduction ............................................................................................................6

1.1. WinPAC-5000 Family...................................................................................7

1.1.1. WinPAC-5000 Naming Convention....................................................7

1.1.2. WinPAC-5000 Comparison................................................................8

1.2. Features.......................................................................................................9

1.3. Specifications.............................................................................................12

1.4. Overview....................................................................................................14

1.5. Dimension..................................................................................................19

1.6. Companion CD...........................................................................................20

2. Getting Started.....................................................................................................21

2.1. Mounting the Hardware..............................................................................21

2.2. Configuring the Boot Mode.........................................................................24

2.3. Changing the Language of the User Interface............................................26

2.4. Using WinPAC Utility to Configure WinPAC-5000 Basic Functionality .......28

3. Tools and Tasks....................................................................................................32

3.1. Backup Utility .............................................................................................35

3.2. Dconmcnfg.................................................................................................37

3.3. Napopc_ce5...............................................................................................38

3.4. SendToCOM...............................................................................................39

3.5. VCEP .........................................................................................................40

3.6. WinPAC_Utility...........................................................................................41

3.6.1. Menu Bar .........................................................................................42

3.6.2. Property Tabs...................................................................................47

4. Your First Program ...............................................................................................56

4.1. Preparing the Development Tools ..............................................................57

4.2. Installing WinPAC-5000 SDK.....................................................................58

4.3. Your First Program in C#............................................................................59

4.3.1. Creating a New Project....................................................................59

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 4

4.3.2. Adding the WinPAC-5000 Reference...............................................61

4.3.3. Adding the Control to the Form ........................................................62

4.3.4. Adding the Event Handling to the Control ........................................64

4.3.5. Upload the Application to WinPAC-5000..........................................66

4.3.6. Executing the Application on WinPAC-5000.....................................68

4.4. Your First Program in VB.net......................................................................69

4.4.1. Creating a New Project....................................................................69

4.4.2. Adding the WinPAC-5000 Reference...............................................71

4.4.3. Adding the Control to the Form ........................................................72

4.4.4. Adding the Event Handling to the Control ........................................74

4.4.5. Upload the Application to WinPAC-5000..........................................75

4.4.6. Executing the Application on WinPAC-5000.....................................77

4.5. Your First Program in eMbedded Visual C++.............................................78

4.5.1. Creating a Forms-Based Project......................................................78

4.5.2. Configuring the Platform ..................................................................83

4.5.3. Specifying the Path of the WinPAC-5000 Reference .......................84

4.5.4. Adding the Control to the Form ........................................................88

4.5.5. Adding the Event Handling to the Control ........................................90

4.5.6. Upload the Application to WinPAC-5000..........................................92

4.5.7. Executing the Application on WinPAC-5000.....................................94

5. APIs and Demo Programs....................................................................................95

5.1. Demo Programs with C#............................................................................96

5.1.1. C# Demo Programs for WinPAC Standard API................................96

5.1.2. C# Demo Programs for PAC I/O API................................................98

5.2. Demo Programs with eVC++....................................................................100

5.2.1. eVC++ Demo Programs for WinPAC Standard API .......................100

5.2.2. eVC++ Demo Programs for PAC I/O API .......................................102

6. WinPAC-5000 Updates ......................................................................................104

6.1. OS Updates..............................................................................................105

6.1.1. OS Updates Using Installation Package File..................................107

6.1.2. OS Updates Using Eshell via Ethernet............................................111

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 5

6.2. SDKs Updates.......................................................................................... 116

6.2.1. WinPAC SDK updates for C# or VB.net......................................... 117

6.2.2. WinPAC SDK updates for eVC++ .................................................. 118

Appendix A. Tips-How to........................................................................................ 119

A.1. How to add a User Account .....................................................................120

A.1.1. How to Use telnet to remote login the WinPAC from PC.......................122

A.1.2. How to remove the user from the login list............................................124

A.2. How to online debug WinPAC..................................................................125

A.2.1. Debug WinPAC programs in EVC++ .............................................125

A.2.2. Debug WinPAC programs in Visual Studio 2005/2008..................134

A.3. How to use the printer..............................................................................143

A.3.1. How to use network printer............................................................144

A.3.2. How to use printer via USB............................................................146

A.4. How to use services tool..........................................................................147

A.5. How to use ActiveSync through USB port................................................150

A.6. How to automatically synchronize the WinPAC clock with an Internet Time

Server .............................................................................................................157

Appendix B. XW-board Modules ............................................................................159

Appendix C. Revision History.................................................................................160

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 6

1. Introduction

WinPAC-5000 Series is the new generation PAC (Programmable Automation

Controller). It is equipped a PXA270 CPU (520 MHz) running a Windows CE.NET

5.0 operating system, various connectivity (VGA, USB, Ethernet, RS-232/485) and

I/O expansion bus.

The WinPAC-5000 series has many advantages, including hard real-time capability,

small core size, fast boot speed, interrupt handling at a deeper level, achievable

deterministic control and low cost. Using Windows CE.NET 5.0 gives it the ability to

run PC-based control software such as Visual Basic.NET, Visual C#, Embedded

Visual C++, SCADA software, SoftPLC …etc. It give users all of the best features of

both traditional PLCs and Windows capable PCs.

For hardware expansion, it also supports an I/O expansion bus. The I/O expansion

bus can be used to implement various I/O functions such as D/I, D/O,A/ D, D/A,

Timer/Counter, UART, and other I/O functions. Nearly all kinds of I/O functions can

be implemented by this bus. But the bus can support only one board. There are

more than 10 boards available for WinPAC-5000 series, users can choose one of

them to expand hardware features.

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 7

1.1. WinPAC-5000 Family

The WinPAC-5000 family is divided into two main types according to Audio port.

▪WP-5141 (without Audio port)

▪WP-5441 (with Audio port)

For more detailed comparison information, please refer to “1.1.2. WinPAC-5000

Comparison”

1.1.1. WinPAC-5000 Naming Convention

As you examine this manual, you„ll notice there are many different models available.

Sometimes it is difficult to remember the specifications for any given model.

However, if you take a few minutes to understand the module naming conventions, it

may save you some time and confusion. The figure below shows how the module

naming conventions work for each WinPAC-5000 model.

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 8

1.1.2. WinPAC-5000 Comparison

The following table shows the comparison in all the features of WinPAC-5000 family.

Model

CPU

Flash

SDRAM

Ethernet

VGA

Resolution

RS-232/

RS-485

I/O Expansion Bus

Audio Port

WP-5141

CE5.0

PXA270

520 MHz

64 MB

128 MB

800 x 600

Yes

(for XW-board only)

WP-5441

Yes

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 9

1.2. Features

The key features of WinPAC-5000 include:

Windows CE.Net 5.0

●Supports PC based software: eVC and VS.NET

●Web server, FTP server, Telnet server

●ISaGRAF version for IEC 61131-3 programming

●InduSoft version for SCADA solution

Local I/O and Communication Expansion Board

WinPAC-5000 series equip an I/O expansion bus to support one optional expansion

board, called XW-board. It can be used to implement various I/O functions such as

DI, DO, A/D, D/A, Timer/Counter and various communication interface, such as

RS-232/422/485, CAN, FRnet, etc.

WinPAC-5000 Series User Manual, Version 1.0.2 Page: 10

Various Memory Expansions

WinPAC-5000 provides various memory storage options, such as

EEPROM and microSD. Customers can choose the

memory based on their characteristics.

●16 KB EEPROM: to store not frequently changed

parameters.

●microSD/microSDHC: to implement portable data logging applications.

Unique 64-bit Hardware Serial Number to Protect Your Program

A unique 64-bit serial number is assigned to each hardware device to protect your

software against piracy.

Remote I/O Module and Expansion Unit

With the built-in RS-485 and Ethernet port, the 5000

series can connect RS-485/Ethernet remote

I/O units (RU-87Pn/ET-87Pn) or modules

(I-7000/M-7000/ET-7000). With an XW-board,

the 5000 series can have more communication

ports or different interface to connect to other

type of devices, for example: CANOpen

devices, DeviceNet devices, or

FRnet I/O modules.

Plastic and Metal Casing

The default case is plastic material, customers can choose metal case if they want.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
