WOLF GMBH /POSTFACH 1380 /D-84048 MAINBURG /TEL. +49.0.875174-0 /FAX +49.0.875174-1600 /www.WOLF.eu
Art.-Nr.: 3062049_201610 Subjecttotechnicalmodications GB
Installationandmaintenanceinstructions
Air-handling unit KG/KGW Top
(Translation of the original)
23062049_201610
KG TopContents
Standards ....................................................................................................3
Function symbols.........................................................................................4
Symbols /Safety instructions .......................................................................5
Delivery / Handling ......................................................................................7
Installation instructions ................................................................................9
Power connection......................................................................................22
Commissioning..........................................................................................24
Maintenance..............................................................................................28
Frost protection..........................................................................................31
Shutdown / Fire / End-of-life disposal........................................................32
Checklist ...................................................................................................33
Fortypeofdevice,serialnumberandordernumber,seetypeplateontheequipment.
Order-relateddevicespecicationssuchasweights,dimensions,sounddata,spareparts,energydataetc.
aretobetakenfromtheorderdatasheets.
OriginalWolfsparepartscanbeprocuredatshortnotice,statingtheordernumber(onthetypeplate),by
faxto0049(0)8751/74-1574.
3
3062049_201610
KG Top
The following standards and regulations apply to the KG/KGW Top series air-handling
units:
- Machine directive 2006/42/EU
- Low voltage directive 2014/35/EU
- EMC directive 2014/30/EU
- Pressure vessel directive 97/23/EU
- DIN EN ISO Safety of machinery; design guidelines
12100
- DIN EN ISO 13857 Safety of machinery; safety distances
- DIN EN 349 Safety of machinery; minimum clearances
- DIN EN ISO 14120 Safety of machinery – Guards –
- DIN EN 1886 Ventilation for buildings - central air-handling units
- DIN ISO 1940/1 Mechanical vibration; balance quality
- DIN EN 60335-1 Safety of electrical appliances for domestic use
and similar purposes
- DIN EN 13053 Ventilation of buildings - central ventilation appliances
Section 6 Performance characteristics for appliances, components
and assemblies
- VDMA 24167 Fans; safety requirements
- RLT Guideline 01
- VDI 3803 Technical requirements for ventilation appliances
Section 5
The following regulations and safety instructions are to be observed for installation
and servicing:
- DIN VDE 0100 Requirements for high voltage installations up to 1000 V
- DIN VDE 0105 Operation of high voltage installations
- DINVDE0701-0702 Repair,modicationandtestingofelectricalappliances
Standards
Standards
43062049_201610
KG TopFunctionsymbols
Functionsymbols
+
++
°C
-
_
Fan section Fan section
Bagltersection Heater section
KGXD section KGX section
Empty section Empty section with
damper
Empty section with
damper and tray
Empty section with
tray
Silencer section Humidiersection
Heater section with
frost protection frame
Cooling section
Rotary heat ex-
changer section
GS-PWT section
5
3062049_201610
KG Top
General These installation and maintenance instructions apply only to WOLF KG/KGW Top
series air-handling units.
Each person tasked with installing, commissioning or maintaining the equipment must
read through these instructions before commencing work.
Compliance with these instructions is mandatory.
Onlysuitablytrainedandqualiedpersonnelarepermittedtoundertakeinstallation,
commissioning and maintenance work.
The assembly and maintenance instructions are an element of the appliance supplied
and must be kept in an accessible place.
Non-compliance with the installation and maintenance instructions voids all WOLF
warranties.
Symbols Thefollowingsymbolsandwarningsareusedintheseinstallationandmaintenance
instructions.Theseimportantinstructionsapplytotheprotectionofpersonnel
andtotechnicaloperationalsafety.
"Safetyinstruction"identiesinstructionsthatmustbepreciselycompliedwithin
ordertoavoidendangeringorinjuringpersonsandtopreventtheriskofdamage
totheequipment.
Electricshockhazardduetoelectricallylivecomponents.
Note:SwitchOFFtheON/OFFswitchbeforeremovingthecasing.
Neverattempttotouchelectricalcomponentsorcontactswhilethemasterswitch
isON.Electricshockhazardwithriskstohealthorfatalinjury.
TerminalsremainliveevenaftertheON/OFFswitchhasbeenswitchedOFF.
"Note"identiestechnicalinstructions thatmust be complied with toprevent
equipmentdamageandmalfunctions.
Inadditiontotheinstallationandmaintenanceinstructions,labelsafxedtothe
equipmentbearinformation.
Compliancewiththese,too,ismandatory.
Note
- The persons tasked with installation, commissioning, maintenance and operation of
theair-handlingunitmustbeadequatelyqualiedandmusthavereceivedsuitable
instruction.
- Onlytrainedandqualiedelectriciansarepermittedtoundertakeworkontheelectrical
system.
- All electrical work must be in compliance with VDE requirements [or local regulations]
and the regulations of the local power supply utility.
- The air-handling unit must always be operated within the range of operating parameters
stipulated in the technical documentation supplied by WOLF.
-
Correct use of the air-handling unit means exclusively the use for ventilation purposes.
Air is the only medium that can be handled by the equipment.
- Never remove, jumper, bypass or by any other means render inoperative safety
devices and monitoring devices.
- Never operate the air-handling unit unless it is in full working order. Malfunctions
and damage that impair or could impair safety must be repaired immediately and
professionally.
- Intheeventofaretheair-handlingunitmustshutdownautomaticallybysuitable
meanssuchasareprotectiondamper(installedonsite),asotherwisehazardous
substances can be transported into the rooms downstream of the air-handling unit.
- Check the electrical equipment of the appliance regularly. Tighten loose connections
and replace faulty cables immediately.
Safetyinstructions
Symbols/Safetyinstructions
63062049_201610
KG Top
IntendedUse Intended use of the Wolf air conditioning units is exclusively restricted to their use for
ventilation purposes. The air conditioning units are to be used only for the transport
andconditioningofnormalair.Thisincludestheltering,heating,cooling,humidify-
ing and dehumidifying of the air. Compliance with the instructions supplied with the
appliance are also part of its use for the intended purpose!
Unintendeduse Uses of the appliance for purposes other than those described above are considered
unintended. Wolf GmbH accepts no liability whatsoever for damages resulting from
unintended use. The user bears the risk alone.
On no account may air be transported that contains any constituents that are inju-
rioustohealth,inammable,explosive,aggressive,corrosiveordangerousinany
other way, since these substances can otherwise be spread throughout the duct
system and the building and impair the health of people, animals or plants living there
or even kill them.
Airconditioningunitsforthetransportofinammableorexplosivegasesmustbe
specially designed. Normal air conditioning units may not be operated in these dan-
ger areas unless there are remarks to this effect in our technical documents.
Technicaldescription Wolf air conditioning units are central air conditioning units and are used for the sup-
ply and exhaust ventilation of rooms. The modular structure of the appliances allows
themostdiverserequirementsforairconditioningtobemetbyconguration.The
transportedaircanbeltered,heated,cooled,dehumidiedandhumidied.
InformationSigns/Safety
Instructions
7
3062049_201610
KG TopDelivery / Handling
Delivery KG Top air-handling units are delivered to site as transportable subassemblies.
On receipt of the incoming goods, check the unit or components to ensure no damage
has occurred in transit.
If damage is evident or if there is a suspicion that damage might have occurred, the
recipient must make a note to this effect on the freight papers and have this countersigned
by the carrier.
Notify WOLF immediately of such circumstances.
Always transport the equipment upright.
Exception:Plate-typeheatexchangers(subjecttotypeandsize)andheatwheelheat
exchangersarelaidat(turned90°)fortransportation.
Otherwise the internal components will suffer damage and this can result in malfunctions.
Handle the appliances with slings.
Tall appliances on a small footprint (e.g. RWT) are connected with an increased risk of
tipping over during unloading and handling on site.
This requires additional measures
on site to prevent tipping over (e.g. securing with straps).
If a forklift or rollers are used to move the units, always ensure that the forks or rollers are
located underneath the frame sections at all times, so that weight is never allowed to rest
ontheoorpanels.
With lifting eyes (available on request), use slings at minimum centres L between lifting
eyes. Ensure that the slings are of uniform length.
Always use a crane lifting beam to lift appliances with more than 4 lifting eyes.
On no account may cladding panels be removed in order to lift the device, since the
cladding panels are structurally integrated in the device's bracing system.
No additional loads may be lifted together with the transport unit supplied by Wolf.
Note
Handling
83062049_201610
KG Top
Final location Always install KG air-handling units in rooms where frost cannot occur.
Iftheoccurrenceoffrostatthenallocationcannotberuledout,adoptsuitablemeasures
to prevent water-containing components from freezing. If an outside thermostat is
installed ensure it is adequately insulated to prevent the air-handling unit from shutting
down inadvertently (see frost protection measures, page 25).
KGW air conditioning units are designed to be installed outdoors.
Note
Spacerequirements Make sure a clear space equal to at least the width of the equipment units is available
on the operator side; this is the minimum space necessary for installation, operation
and maintenance (see the table below).
Footprint of space required for installation, operation and maintenance:
Fan section 0.8 x appliance width
Cooling coil, heating coil, KVS 1 x appliance width + 250 mm
Filter section up to KG 96 1 x appliance width
from KG 130 0.5 x appliance width
Inback-to-backcongurationswithside-by-sideunits,leaveclearancesasstatedabove
on both sides for installation, operation and maintenance.
Install units that require a siphon (scrubber, humidier, cooling coil, plate-type heat
exchanger, mist eliminator) in such a way as to ensure correct installation and operation
of the siphon (make adequate provision for the foundation height).
Itisadvisabletoinstallawaterprooffoundationforunitswithhumidiersand/orcooling
coils installed above rooms containing moisture-sensitive equipment (e.g. IT rooms, etc.).
Delivery / Handling
9
3062049_201610
KG TopInstallationinstructions
Equipmentinstallation Appliances for weatherproof installation must not take on any static load or act as a
substitute for the roof of the building.
When assembling and installing combined ventilation and extract appliances with heat
recovery (KGXD, RWT), observe the correct sequence of assembly and installation
(see diagram). For this, one complete appliance train should always be assembled/
installed completely. The second appliance should then be installed from the heat
recovery onwards.
This offers the most effective prevention of alignment errors and installation inaccuracies.
Appliance example - top view:
Note
Note
When installing high or perhaps smaller appliance components (e.g. RWT, RWT duct
components or standing appliance layouts with several components above each
other),securetheseduringassembly/installationagainsttippinguntiltheyarenally
connected to other components that ensure that tipping is prevented.
Requires permanent securing against tipping over.
Note
Risk of tipping
Baseframe/foundation
base
Internalunitbaseframe
WOLF internal unit base frames (suitable only for internal installation) are always sup-
plied loose (in advance).
Base frames delivered loose are knocked down for shipping and must be assembled,
aligned and secured to the base on site in accordance with the instructions enclosed
with the base frame.
10 3062049_201610
KG TopInstallationinstructions
A base frame or plinth is required for air-handling units installed as weatherproof version
to support the appliances and their components.
The height of the base frame or plinth is subject to the local snow depth; however, it
should be at least 180 mm.
Subject to the prevailing wind force, secure the appliances with bolts to the base frame
or plinth (observe the transmission of structure-borne noise).
Baseframesmustbehorizontalandperpendicular;thefoundationbasemustbelevel
andhorizontal.
Weatherproofdevicesmaynotassumeanybuildingsupportfunctions
ortasksoftheroofofthebuilding(VDI38035.1/BSEN130536.2).
Thelowerbaseframemustmakefull-surfacecontactwiththebase;
padorpointcontactisnotpermissible.
Note
It is essential to ensure that the base on which the units and components are to be
assembledandinstalledislevel,horizontalandofadequateload-bearingcapacity.
Thebaseframemustbehorizontal,andthefoundationmustbelevelandhorizontal
(check with browning rod).
To prevent the inspection doors from jamming, the lower base frame must make full-
surface contact with the base; pad or point contact is not permissible.
Provideapermanentlyexiblelayerbetweentheinstallationsurfaceorfoundation/plinth
and the air-handling unit to prevent the transmission of structure-borne noise from the
appliance to the building. Preferably, this intermediate layer should take the form of
insulation strips that are positioned longitudinally underneath the appliance frame or
underneath the base frame.
Note
Baseframe/
foundationbase
KG:
Strip insulation, on site
Fitted base
frame
50
Sealing tape
Baseframeprole
with drip strip
Insulation on site
On-site roof
membrane
Insulatingstriptted
on-site
Screwttedon-sitewith
sound decoupling, e.g.
neoprene washer
KGW:
Andere Handbücher für KG
1
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Wolf Luftaufbereiter Handbücher
