WowWee CHIP Bedienungsanleitung

USER MANUAL

YOUR NEW BEST FRIEND

Item No.: 0805

CONTENTS

INTRODUCTION

P.1

POWERING CHIP™

P.2

POWERING THE CHIP SMARTBED™

P.3

POWERING THE CHIP SMARTBALL™

P.4

POWERING THE CHIP SMARTBAND™

P.5

QUICK OVERVIEW - CHIP™

P.6

QUICK OVERVIEW - ACCESSORIES

P.7

PLAY WITH CHIP™

P.8 - P.9

PLAY WITH CHIP™ - CHIP SMARTBALL™

P.10

PLAY WITH CHIP™ - CHIP SMARTBAND™

P.11 - P.12

CUSTOM VOICE COMMAND

P. 13

SLEEP & STANDBY MODE

P.14

APP FUNCTIONALITY

P. 15

Q & A

P.16

WARRANTY

P.17

THANK YOU FOR PURCHASING CHIP™ FROM WOWWEE®!

CHiP™ is an intelligent, affectionate robot pup. With advanced sensors and smart accessories, CHiP™ is

always ready to play! And, CHiP™ aims to please. Praise him when you like what you see and CHiP™ will

learn to favor the behaviors, animations and actions that you prefer. Ready to get started?

Take a few minutes to look through this user manual, and check out the video tutorials and FAQs at

wowwee.com/chip#getting-started.

You can also access a list of tricks, including a full list of Voice Commands, in the app.

NOTE: When using CHiP™, adult supervision is required.

INTRODUCTION

PRODUCT CONTENTS:

1 x CHiP™

1 x CHiP SmartBall™

1 x CHiP SmartBand™

1 x CHiP SmartBed™

4 x Wheel guards

8 x Screws (for wheel guards)

1 x AC/DC power adapter

1 x USB Charge cable

1 x Instruction manual

1 x Quick start guide

CHiP™

8 x Screws

4 x Wheel Guards

CHiP SmartBand™

CHiP SmartBall™AC Adaptor

CHiP SmartBed™ Micro USB Cable

PLEASE NOTE THE FOLLOWING WHEN OPERATING CHIP™

• Do not immerse CHiP™ or any parts in water or any other form of liquid.

• Do not drop, throw, or kick CHiP™ as this might damage mechanical functions.

• Do not leave CHiP™ on surfaces from which he can easily fall.

• Always turn off when not in use.

USING CHIP™

When you first turn on CHiP™, CHiP™ will look surprised and stretch his legs.

POWERING CHiP™

TURNING ON CHIP™ LOW BATTERY INDICATORS

To get started with CHiP™, first turn him on by pushing the power

switch located on his chest, to On.

When the batteries grow weak, CHiP™'s eyes will turn PURPLE and

will move very slowly and will make a low battery indication sound.

You can also see current battery levels via the CHiP™ App.

There are 2 ways to recharge CHiP™, either by direct charging or by

using the CHiP SmartBed™.

POWERING CHIP™ - DIRECT CHARGING

Follow the diagram as shown for direct charging.

The CHiP™ product is operated by 1 x 7.4V 1800 mAh

Lithium-ion rechargeable.

ON OFF

NOTE: Do not remove/replace CHiP™ Rechargeable

Battery without first contacting WowWee®

support (www.wowweezone.com).

CHIP™ BATTERY DIAGRAM/INSTALLATION

INSTALLING OR CHANGING BATTERIES IN THE CHIP™:

1. Using a Phillips screwdriver (not included) remove the

screws on the battery compartment cover.

2. Insert the batteries according to the diagram. Ensure that

the positive and negative polarities match the illustrations

inside the battery compartment.

3. Replace the battery compartment cover and replace the

screws using the screwdriver. Do not over-tighten.

Rechargeable Battery

(included)

USING THE CHIP SMARTBED™

When you first plug in the CHiP SmartBed™, CHiP™ will return to it to demonstrate his ability to dock autonomously.

POWERING THE CHIP SMARTBED™

POWERING CHIP™ - WITH THE CHIP SMARTBED™

1. Ensure that both CHiP™ and CHiP SmartBed™ are ON and within close proximity (3 meters). CHiP™ will

automatically detect when its power is low, and will drive to CHiP SmartBed™ and recharge; or

2. Hold the Like button on CHiP SmartBand™ while both CHiP™ and CHiP SmartBed™ are within close

proximity. CHiP™ will drive to CHiP SmartBed™ and recharge; or

3. In the case that CHiP™'s power is extremely low and unresponsive to (1) or (2), use the CHiP SmartBed™'s

AC/DC adaptor to directly charge CHiP™.

4. When CHiP™’s battery is fully charged, he will stand up to avoid over charging. If you want to call

CHiP™ off his SmartBed before he is fully charged, press and hold the CHiP™ button in the center of

your CHiP SmartBand™.

CENTER POSITIVE

For optimal tracking, place the CHiP SmartBed™ in a room where CHiP™ would be most often.

CHiP™ will need to physically see the CHiP SmartBed™ before he can locate it.

When the CHiP SmartBed™

is plugged in, it's LED

will turn BLUE.

CHiP's SmartBed™ LED

with turn PURPLE when

CHiP™ is looking for

it, and will remain

PURPLE while CHiP™

is charging.

CHiP™’s eyes will turn PURPLE while he is looking for the CHiP SmartBed™, and

will change to BLUE sleepy eyes when CHiP™ has made contact and is charging

correctly. If CHiP™’s eyes remain purple after sitting, he will attempt to adjust his

position. We do not recommend forcing CHiP™ into a seated position, but you can

help CHiP™ by removing any objects that may be in his way, and/or unplugging

and replugging the charging bed to restart the process.

4POWERING THE CHIP SMARTBALL™

USING THE CHIP SMARTBALL™

When you first turn on the CHiP SmartBall™, CHiP™ will demonstrate his ball handling abilities and play with it.

4 x “AAA” Size Alkaline Batteries

(not included)

CHIP SMARTBALL™ BATTERY

DIAGRAM / INSTALLATION

ON OFF

TURNING ON THE CHIP SMARTBALL™ LOW BATTERY INDICATORS

To get started with the CHiP SmartBall™, toggle the power switch to

ON then follow the instructions in the "Playing With CHiP™" section.

When the batteries grow weak, the light on CHiP SmartBall™ will

flash PURPLE and then power down. When this happens, power off

and replace all batteries.

USING CHIP™ INSTALLING OR CHANGING

BATTERIES IN THE CHIP SMARTBALL™:

1. Using a Phillips screwdriver (not included) remove

the screws on the battery compartment cover.

2. Insert the batteries according to the diagram. Ensure

that the positive and negative polarities match the

illustrations inside the battery compartment.

3. Replace the battery compartment cover and

replace the screws using the screwdriver. Do not

over-tighten.

USING THE CHIP SMARTBAND™

When you first power up the CHiP SmartBand™, CHiP™ will respond by tracking and driving towards it.

POWERING THE CHiP SMARTBAND™

* The CHiP SmartBand™ is operated by 1 x 3.7V 130 mAh

Lithium-ion rechargeable.

DC IN 5V 0.5A

TURNING ON THE CHIP SMARTBAND™ LOW BATTERY INDICATORS

To get started with the CHiP SmartBand™, Press and hold the "CHiP™"

button in the middle of the band for 2 seconds then follow the instructions

in the "Playing With CHiP™" section of this instruction manual.

To power off, press and hold the "CHiP™" button for 4 seconds.

When the battery grow weak, CHiP SmartBand™ will

flash PURPLE and then power down. When this happens,

recharge CHiP SmartBand™ as indicated below.

POWERING THE CHIP SMARTBAND™:

1. Plug the Micro USB Cable into the Micro USB port

on the CHiP SmartBand™ and connect to a power

source as indicated in the diagram.

2. Charging is indicated by a flashing PURPLE light.

3. When fully charged, the LED light on the

CHiP SmartBand™ will remain PURPLE (no

longer flashing).

4. Press the center button on CHiP SmartBand™ to

reactivate the band.

ON OFF

IMPORTANT BATTERY INFORMATION

• Use only fresh batteries of the required size and

recommended type.

• Do not mix old and new batteries, different types of batteries

[standard (Carbon-Zinc), Alkaline or rechargeable] or

rechargeable batteries of different capacities.

• Remove rechargeable batteries from the toy before

recharging them.

• Rechargeable batteries are only to be charged under

adult supervision.

• Please respect the correct polarity, (+) and (-).

• Do not try to recharge non-rechargeable batteries.

• Do not dispose of batteries into fire.

• Replace all batteries of the same type/brand at the same time.

• The supply terminals are not to be short-circuited.

• Remove exhausted batteries from the toy.

• Batteries should be replaced by adults.

• Batteries should be recycled or disposed of as per state and

local guidelines.

6QUICK OVERVIEW - CHiP™

CHIP™ OVERVIEW:

A. LED indicator eyes

B. Tail

C. Omnidirectional wheels

D. Touch sensors

E. IR transmitter

F. Touch sense nose

G. Poseable rubber ears

H. Speaker

I. IR receiver

J. Power switch

K. Direct charge port

L. Charge contacts

J K

QUICK OVERVIEW - ACCESSORIES

CHIP SMARTBAND™ OVERVIEW:

A. 4-way joypad

B. CHiP™ button

C. Adjustable strap

D. Charging port

CHIP SMARTBALL™ OVERVIEW:

A. LED indicator

B. Charge contacts

C. Charging port

CHIP SMARTBALL™ OVERVIEW:

A. LED indicator

B. Power switch

C. IR sensors

8PLAY WITH CHiP™

GETTING STARTED

CHiP™ has omnidirectional wheels, so he can move in all directions – from side to side, left, right, forward,

backward and spin around. Children should be careful when playing with CHiP™’s feet and should not

put their fingers in his wheels. There are four wheel guards included in the CHiP™ package in order to

prevent this. We recommend that parents of younger children install the wheel guards by following the

"Wheel Guard Installation Sheet".

BASIC INTERACTIVE FUNCTION

Once CHiP™ is fully charged, turn him on by pushing the power switch located on his chest, to ON. You can start to interact with him,

even without the app. CHiP™ is quite independent and will move around and react to things, even if you are not sending him commands.

He might even bark to get your attention. Be sure not to leave CHiP™ on a surface from which he can easily fall, such as a countertop, or

near the top of the stairs.

TOUCH RESPONSE CHiP™ responds to various kinds of touch. He loves to be stroked on his head or patted on his head.

He also reacts when you touch his nose! Note that he sometimes reacts differently depending on

whether he is standing, sitting or lying down. Take some time to get to know CHiP™!

NOTE: See the"Tricks" section in the CHiP™ App for full list.

ICON INPUT RESPONSE

Pet Brush CHiP™'s head from front to back or back to front, CHiP™ will lie

down and get excited.

Boop (bop on the nose) Tap CHiP™ on the nose and CHiP™ will lick your hand.

Pat - While Standing Tap CHiP™'s head while standing to make CHiP™ sit.

Pat - While Seated Tap CHiP™'s head while seated to make CHiP™ lie down.

Pat - While Lying Down Tap CHiP™'s head while lying down to make CHiP™ stand up.
