WUBEN C5 Bedienungsanleitung

User Manual V1.0

EDC FLASHLIGHT

CONTENTS

(EN) English

(DE) Deutsch

(CN) 中文

(JP) 日本語

(KR) 한국어

04

15

26

36

47

WARNINGS

Please read user manual carefully before using the light.

Product will generate heat while working, please becautious with that to avoid any

possible harm.

Please don’t shine into eyes directly to avoid harm to eyes.

Please keep the light away from children.

Please use WUBEN or WUBEN recommended batteries.

Please don’t disassemble the light or it will not be covered by WUBEN warranty policy.

Please don't throw the product into ﬁre.

This is not a diving product, please don't use it underwater for a long time.

- 04 -

Lanyard × 1

34Diﬀuser × 1

C5 × 1

12ABF750R × 1

Before using this product, please check whether the contents of the package are complete.

Package List

5Micro-USB charging

cable × 1

7Manual, warranty card,

quality certiﬁcate × 1

6Spare O-ring × 2

- 05 -

E

N

Switch(Battery power

indicator, breathing light)

C5 is a stylish EDC ﬂashlight. Utilized 1

piece OSRAM P9 LED, it emits 700 lumens

max output. Powered by 1 piece 14500

rechargeable Li-ion battery of 750mAh with

Micro-USB charging port. The ﬂashlight is

compatible with 1 piece AA alkaline

battery. Side switch and magnetic tail cap

make it more convenient to use.

1. About product

Product operation

Lanyard hole

Tail magnetic

function

- 06 -

2. Installation

Please remove the insulation plate before

using.

1

2

3

3. Operation

ON/OFF: Click on switch to turn on the ﬂashlight, click again to turn it oﬀ. The ﬂashlight

has memory function, will memorize default output selections, but not ﬂash modes.

Output Selections: When the ﬂashlight is on, long press switch to cycle through Moon

-Low-Med-High-Moon.It will lockout the brightness once releasing the switch at any modes.

Continuous Output Selections: When the light is oﬀ, long press switch to activate Moon

mode, after holding for 2 seconds, the brightness starts to rise slowly, ﬂashes once after

reaching the highest mode, then slowly descends, and then ﬂashes to the lowest mode.

Release the switch to select your desired brightness, single click to exit.

- 07 -

E

N

When the ﬂashlight is oﬀ, 4 times click on switch, the light blinks 3 times to indicate lockout

status. Then any operations on switch will be invalid unless another 4 times click on

switch, which will activate Moon mode, to indicate unlocking of the ﬂashlight.

4.Lockout /Unlock

Take out the battery, connect Micro-USB charging cable and adapter of 5V/1A to charge.

It takes about 3 hours to fully charged.

5.Charging

4

5

Quick Turbo: When the light is on and not High mode, double click on switch to High

mode, single click to exit.

Flash Modes: When the ﬂashlight is oﬀ or at High mode, double click on switch to

activate Strobe, double click again to swap between Strobe and SOS, single click to exit

ﬂash modes.

- 08 -

Red light constant onCharging

Green light constant onCharging ﬁnished

Blue light constant on(oﬀ after 5 seconds)

Blue light ﬂashes(oﬀ after 5 seconds)

Red light constant on(oﬀ after 5 seconds)

C ≥ 90%

Red light ﬂashes

90% > C ≥ 40%

40% > C ≥ 15%

15% > C > 0

6.Charging Status Indication

7.Battery Capacity (C) Status Indication

- 09 -

E

N

All data from experiments of WUBEN lab according to the ANSI/NEMA FL1 standard, may vary because of

diﬀerent experiment equipment, experiment environment or other factors. Experiments are based on WUBEN

14500 Li-ion battery(750mAh) and AA alkaline battery(2700mAh) .

FL1

Standard

700 300 150

Lumens Lumens

3

Hours

1.5

Hours

14500

battery

AA Alkaline

battery

15

Hours

4.5

Hours 70

Hours

/

/ /

/

/

120

Hours

30

Lumens 1

Lumen 150

Lumens

700

Lumens

1Min +

1.5 Hours

126 Meters

3940 Candela

1.5 Meters

I P65

35g/1.23oz (without battery) | 57g /2.01oz (with battery)

87.5mm × 21.5mm | 3.45in × 0.85in (L × D)

High Med Low Moon Strobe SOS

Parameters

- 10 -
