XMOS XC-1A Bedienungsanleitung

XC-1A Quick Start Guide

Version 1.0

Publication Date: 2009/12/20

XC-1A Quick Start Guide (1.0) 2/7

1 Introduction

The XC-1A Development Kit contains everything you need to start exploring the XMOS

event-driven processor technology. It comprises a single XS1-G4 device, 4Mbits SPI

FLASH memory, 16 user-conﬁgurable LEDs, four pushbuttons, a speaker, JTAG and

serial interfaces, four expansion areas suitable for IDC headers and a through-hole

prototyping area for connecting external components.

The XC-1A card can be powered by an external 5V power supply, or the USB cable

provided which also provides a JTAG interface between the card and XMOS Tools.

1.1 XC-1A Features

Button D

Button C

Speaker

Button B

Button A

Button LED

Clock LEDs Through-holes for

16-way 0.1” IDC Header

Prototyping area

0.1” Through-holes

Further information on the XC-1A is available from the XMOS web site. Download the

XC-1A tutorial, hardware manual, schematics and design ﬁles from:

www.xmos.com/xc1a

www.xmos.com

XC-1A Quick Start Guide (1.0) 3/7

2 Microsoft Windows Users

1. Download and conﬁgure the tools

•Download the tools installer from the following URL:

http://www.xmos.com/downloads

•

Double-click the installer to run it. Follow the on-screen prompts to install

the tools on your PC.

2. Install the USB-to-JTAG drivers

•

Connect the XC-1A card to your development system using the USB cable

provided.

The New Hardware Wizard is displayed. If you are prompted to connect to

Windows Update, click No.

•Click Next to proceed.

•Select Install from list and click Advanced.

•

Browse to your tools installation folder, open the drivers subdirectory and

select the FTDI folder.

•Click Next and follow the instructions on screen.

•Click Finish to complete the driver installation.

The XC-1A card starts up and ﬂashes the LEDs around the XMOS chip on the

card. The XC-1A card has four demonstrations which you can launch using

the push buttons—see Section 5.

3. Start the tools

•

To start the integrated development environment,

Start ·Programs ·XMOS

·XMOS Desktop Tools 9.9 ·XMOS Development Environment.

•

To use the command-line tools,

Start ·Programs ·XMOS ·XMOS Desktop

Tools 9.9 ·Desktop Tools Prompt.

You are now ready to follow the XC-1A tutorial which explains how to write XC

programs for your XC-1A board. Download the tutorial from

http://www.xmos.com/published/xc1atut.

www.xmos.com

XC-1A Quick Start Guide (1.0) 4/7

3 Mac OSX Users

1. Connect the XC-1A card to your system

•

Connect the XC-1A card to your development system using the USB cable

provided.

The XC-1A card starts up and ﬂashes the LEDs around the XMOS chip on the

card. The XC-1A card has four demonstrations which you can launch using

the push buttons—see Section 5.

2. Download and conﬁgure the XMOS Tools

•Download the Macintosh installer from the following URL:

http://www.xmos.com/downloads

•

Double-click the downloaded installer to open it, and then drag the XMOS

icon into your Applications folder.

The installer copies the ﬁles to your hard disk.

•Unmount the installer.

3. Start the tools

•

To start the integrated development environment, open a new Finder window,

navigate to the Applications folder, open the XMOS folder and double-click

on the XDE.app icon.

•

To use the command-line tools, open a Terminal window, change to the

installation directory and type:

SetEnv.command

You are now ready to follow the XC-1A tutorial which explains how to write XC

programs for your XC-1A board. Download the tutorial from

http://www.xmos.com/published/xc1atut.

www.xmos.com

XC-1A Quick Start Guide (1.0) 5/7

4 Linux Users

1. Connect the XC-1A to your system

•

Connect the board to your development system using the USB cable provided.

•Log into a shell with root permissions.

•

Open the ﬁle

/etc/fstab

in an editor and add the following lines to access

the USB USB ﬁle system:

none /proc/bus/usb usbfs defaults,devmode=0666 0 0

•Unmount the USB ﬁle system with the following command:

umount /proc/bus/usb

•Remount the USB ﬁle system with the following command:

mount /proc/bus/usb

The XC-1A card starts up and ﬂashes the LEDs around the XMOS chip on the

card. The XC-1A card has four demonstrations which you can launch using

the push buttons—see Section 5.

2. Download and conﬁgure the tools

•Download the tools archive from the following URL:

http://www.xmos.com/downloads

•Uncompress the archive to an installation directory using the command:

tar -xzf archive.tgz -C /home/user

The 64-bit tools require the 32-bit compatibility-layer libraries to work correctly.

For further information on installing these libraries on RedHat distributions,

browse to the following URL:

http://www.redhat.com/support

3. Start the tools

•

Conﬁgure the XMOS Tools environment. Change to the installation directory

and type:

source SetEnv

•To start the integrated development environment, type the command:

xde

•To use the command-line tools, call the required tool directly.

You are now ready to follow the XC-1A tutorial which explains how to write XC

programs for your XC-1A board. Download the tutorial from

http://www.xmos.com/published/xc1atut.

www.xmos.com

XC-1A Quick Start Guide (1.0) 6/7

5 XC-1A Pre-loaded Demonstrations

The XC-1A runs pre-loaded demonstration code on power up. The default behaviour

is to twinkle the bi-colour clock LEDs around the XS1 chip and to pulse the LEDs next

to the buttons. Press any of the four buttons to launch a simple demo application.

5.1 Button A: Clock

Displays a clock on the clock LEDs with the hands as follows:

Red Minutes

Green Hours

Orange Seconds

The 12 clock LEDs on the XC-1A provide 5-second resolution. When the clock is

running use the buttons as follows:

A Return to default LED demo

B Speed up clock to set time

C Tick-tock sound on

D Tick-tock sound oﬀ

5.2 Button B: Simple Audio Synthesizer

Press buttons B-D to generate diﬀerent tones. Press A to return to the default LED

demo.

5.3 Button C: Reaction Game

A simple reaction game. The red LED cycles around the clock face. After a varied

delay a LED will illuminate green. The aim of the game is to press button D when the

red LED is over the green LED. The game speeds up as you progress. There are ﬁve

levels to the game and the current level is shown on the four button LEDs. Press A to

return to the default LED demo.

www.xmos.com

XC-1A Quick Start Guide (1.0) 7/7

5.4 Button D: Simple UART Demo

A simple UART demonstration using the virtual COM port of the XC-1A. Once you

have started the program, connect to it using a standard terminal (such as realTerm

for Windows or GTKTerm for Linux). When you press a key, a list of three commands

is displayed that you can use to illuminate the clock LEDs via the terminal. The UART

settings are as follows:

Bits per sec 115200

Parity None

Data bits 8

Stop bits 1

Flow control None

Press A to return to the default LED demo.

Disclaimer

XMOS Ltd. is the owner or licensee of this design, code, or Information (collectively,

the “Information”) and is providing it to you “AS IS” with no warranty of any kind,

express or implied and shall have no liability in relation to its use. XMOS Ltd. makes

no representation that the Information, or any particular implementation thereof, is

or will be free from any claims of infringement and again, shall have no liability in

relation to any such claims.

registered trademarks of XMOS Ltd in the United Kingdom and other countries,

and may not be used without written permission. Company and product names

mentioned in this document are the trademarks or registered trademarks of their

respective owners. Where those designations appear in this document, and XMOS

was aware of a trademark claim, the designations have been printed with initial

capital letters or in all capitals.

www.xmos.com
