Xmotion XW2 Bedienungsanleitung
XW2
2
For the use of the XMOTION (used for manufacturer and all authorized XMOTION
distributors and sellers) dashcam device.
Read this manual carefully before using this device. This manual may be modified
supplemented without any notice.
XMOTION is an auxiliary device for recording while driving and parking. Use
this device for intended purposes only.
This device records and saves videos of significant incidents, but may not
capture certain events due to the operating environment. This device is not
guaranteed to record all incidents. Use the device only for reference purposes.
Recordings will not be saved while the device is booting. To ensure proper record-
ing, turn on the device and wait until the device is fully booted before operating.
01_DEVICE INSTALLATION AND
MAINTENANCE
zThe device’s firmware and dedicated viewer may be changed without prior
notice in order to enhance product performance or viewing quality.
zExtended periods of recording in parking mode may result in vehicle battery
drainage. Switch the device off before long time parking.
zThis device is powered through the vehicle’s auxiliary power socket or by
hardwiring to the vehicle’s fuse box. Incomplete or improper connection to
the power source may cause malfunction or fire. XMOTION is not responsi-
ble for any problems caused by hardwiring.
zFor hybrid vehicles, connect car charger to the vehicle’s auxiliary power
socket. Note that hybrid vehicle is more susceptible than non-hybrid vehicle
in battery discharge or fire. XMOTION is not responsible for any problems
caused by hardwiring the device to the vehicle.
zFull recording functionality or video quality may be affected by driving and
weather conditions including extreme dark/light such as when entering/
exiting a tunnel or parking garage. Video may be blurry or distorted in
vehicles with excessively tinted glass.
zThe optimal temperature for device operation is -4 ~ +158 ℉ (-20 ~ +70 ℃).
Maintain optimal temperature to avoid malfunction.
zDo not park in or expose to direct sunlight for extended periods of time to
avoid malfunction or breakdown.
3
01_DEVICE INSTALLATION AND MAINTENANCE｜
zDo not use the device in high temperature or high humidity environments.
This device is not waterproof. Exposure to liquids or foreign substances may
cause malfunction, short circuit, and/or fire.
zUse only genuine accessories and peripherals authorized by XMOTION.
XMOTION does not guarantee the safety or compatibility of accessories or
peripherals not approved by XMOTION, and any damage or malfunction as
a result of such use will not be covered by any warranty.
zDo not operate the device while driving. Operating the device while driving
may result in accidents. Park the vehicle in a safe place before operating the
device.
zTo avoid electric shock, do not operate or handle the power cable with wet
hands.
zTo avoid fire or electric shock, do not use a cut or damaged power cable.
zModifying or cutting power cables may lead to damage to the device or
the vehicle. XMOTION is not responsible for any damage caused by cut or
modified power cables.
zDo not mount the device in an area that blocks or obscures the driver’s view
as this may result in an accident.
zDo not disassemble, repair or modify the device. Contact the seller for
repairs. Any attempt to disassemble, repair or modify the device will result in
the cancellation of any warranty.
zDo not clean the device with chemicals or detergents. This may result in
discoloration, cracking, or malfunction of the device. Gently clean using a
soft and dry cloth. Ensure the device is clean at all times.
zDo not expose the device to direct impact, and prevent foreign substances
from entering the device.
zXMOTION is not responsible for any damage to the device or any damage
or injury caused by user’s negligence or from the device’s operation while
driving.
zThe device’s Low Battery Prevention (LBP) function may cause the vehicle’s
battery to discharge depending on the condition of the battery. XMOTION
is not responsible for vehicle battery discharge, fire or other vehicle battery
problems.
zTo avoid vehicle battery discharge or fire, disconnect the power cable from
the device if the device will not be used for an extended period. XMOTION
is not responsible for any damage to the device or vehicle caused by leaving
the power cable connected to the device for extended periods.
4
02
_
SCOPE OF WARRANTY AND
RESPONSIBILITY
zImages and recordings captured on this device may be used to assist in
determining the circumstances of an accident. XMOTION is not responsible
for any profit or loss arising out of any accident (lost money, business losses,
or other indirect damage).
zThis device records and saves videos of significant incidents in the Driving
Events folder but may not register minor events that do not activate the
impact detection sensor as Driving Events.
zXMOTION is not responsible for any problems that arise due to use of the
device in a contrary way to the manual.
03
_
MICRO SD CARD
zThe Micro SD Card is under a 6-month warranty from the date of purchase.
After the warranty period, any replacement SD cards must be purchased.
zThe Micro SD Card is re-writable. However, repetitive writing and deleting
may cause damage to the Micro SD Card as well as to any stored files. For-
mat the Micro SD Card at least two times each month to prevent damage,
and replace the Micro SD Card with a new card once every 6 months, as
data storage performance may decline after extended use.
zThe life of the Micro SD Card depends on the conditions of use and may be
significantly shortened when the device is hardwired to the vehicle for the
parking mode.
zUse only Micro SD Cards supplied by XMOTION. XMOTION is not responsible
for any problems caused by using Micro SD Cards not supplied by XMOTION.
zAlways turn the device off before removing the Micro SD Card. Failure to
turn the device off before removing the Micro SD Card may cause data
deletion, malfunction or operational errors.
zIf an accident occurs, turn the device off before ejecting the Micro SD Card. Fail-
ure to turn off the device before ejecting the Micro SD Card may result in delet-
ed or compromised data or recordings. XMOTION is not responsible for deleted
or overwritten data as a result of failure to properly eject the Micro SD Card.
zUse of the Micro SD Card in a smart phone is not recommended. If the
Micro SD Card is used in a smart phone or for other purposes, be sure to
format the Micro SD card on a computer before it is used in the device.
5
04_WHAT’S INCLUDED AND OPTIONAL
ACCESSORIES
The basic package and optional accessories are subject to change without prior
notice in order to improve quality or performance. Either a power cable or car
charger is included in each package.
In the Package
Main (front) camera
device Rear camera device Hardwiring power cable
Micro SD Card
with adapter
Mount with 3M
adhesive
Rear camera
cable
Quick Start Guide/
Warranty/
User Manual
Optional Accessories
Car charger GPS Antenna
6
05
_
INSTALLATION GUIDE
Install the Mount
Clean the area on the windshield where
the device will be installed.
Remove the film from the adhesive tab of
the mount.
Attach the adhesive side of the mount to
the windshield in an area that allows the de-
vice an unobstructed view of the road, but
does not interfere with the driver’s view.
TIP
The camera is located on the left side of the
main unit so install the device slightly right of
center behind the rearview mirror.
Attach the Device
Align the notch in front of the device with
the tab on the mount.
Tilt the device upward until it snaps into
the mount.
Connect to Power
Connect the power cable to the DC-IN
socket of the device.
Plug the car charger adapter end of the
power cable into the auxiliary power
socket.
The device should be facing forward and
be level with the vehicle and the road. Adjust angle by using the plastic
roller screw.
Hide the power cable by tucking it in the space between the windshield
and headliner.
EMERGENCY Wi-Fi
EMERGENCY Wi-Fi
EMERGENCY Wi-Fi
1
1
1
2
2
2
3
3
4
7
05_INSTALLATION GUIDE｜
For 2-Channel only
< Front Camera >
EMERGENCY Wi-Fi
< Rear Camera >
EMERGENCY Wi-Fi
Clean the area on the rear windshield where the device will be installed.
Remove the film from the adhesive portion of the mount.
Attach the adhesive side of the mount to the rear windshield in an area
that allows the device an unobstructed view of the road, but does not
interfere with the driver’s view.
Attach the rear camera to the rear mount and adjust the camera angle so
it is level with the vehicle and the road.
Connect the front camera (“R CAM” port) and the rear camera using the
rear camera connection cable.
Hide the rear power cable by tucking it in the space between the rubber
window sealing and/or molding.
1
2
3
4
5
6
8
06
_
DEVICE COMPONENTS
EMERGENCY Wi-Fi
①Front lens ⑦Micro SD Card slot
②Security LED ⑧Wi-Fi on/off button
③Speaker
⑨Manual recording button
& MIC on/off button*
④Power connection
⑤GPS connection ⑩Wi-Fi LED
⑥Rear camera connection ⑪Status LED
* Short press : Manual recording button
Press and hold : Toggle between MIC on and off
9
07
_
MAIN FUNCTION
Night Vision
Advanced image processing technology provides enhanced visibility in dark and
low-light environments such as in parking garages, tunnels and at night.
ADAS: State-of-the-art safe driving support system
Advanced Driver Assistance System (ADAS) detects danger in various operating
environments and helps to prevent accidents.
FVSA (Front Vehicle Start Alarm), LDWS (Lane departure Warning System)
Format free
Advanced format free technology (FFT) and serial encoding allow for maximum
Micro SD Card file stability and long-lasting storage.
Supercapacitor
The supercapacitor is used to safely store and save video files during a sudden
power failure.
Smart parking impact notification
Upon starting the vehicle’s ignition, the device’s screen turns on and displays
the number of motion detection and impact detection events that occurred
during parking recording.
Auto Overwrite
When memory is full, the automatic deletion function is activated and over-
writes older files to allow for continuous storage of new videos.
Driving Recording
Continuously records video while vehicle is running.
Parking Mode
The device must be hardwired to enable parking mode recording. In parking
mode, the device’s impact and motion detection functions are activated, but
driving recording is turned off. Parking mode is initiated around 10 seconds
after the vehicle’s engine is shut off. Parking mode recording commences upon
impact or motion detection. The device’s Low Battery Prevention (LBP) function
prevents vehicle battery discharge when battery power drops below a user-de-
fined level. Specify desired battery level or set timer in Settings.
10
08
_
LED LIGHT INDICATORS
LED Location Color Recording signal Event signal
Front - Security LED BLUE Flashing slowly
(Every 2 Sec)
Flashing rapidly
(Every 1/4 sec)
Rear – Status Indication LED
RED
09
_
RECORDING & PLAYBACK
Recorded video files may be viewed on a generic file player or the XMOTION PC
viewer or on the device’s screen without file conversion.
The files on the Micro SD Card may be viewed by connecting the card to your
computer.
For 2-channel devices only : The device combines front and rear video record-
ings into a single file for simultaneous front and rear playback on the XMOTION
PC Viewer or the VLC Player.
File Folder
Driving Driving Impact Parking Parking Impact Parking Motion
Folder File
Driving Driving recording (Driving mode)
Driving Impact (Impact, Manual) recording (Driving mode)
Parking Parking mode recording (Time lapse)
Parking Impact Impact recording (Parking mode)
Parking Motion Motion recording (Parking mode)
Inhaltsverzeichnis
Andere Xmotion Dashcam Handbücher
