Xo XOU24BCGSL Bedienungsanleitung

I worked really hard

on this manual -

so please read it...

+|+d

n:<O6

UsO++'

nUFOU~

!UsnUsd

UNDERCOUNTER

Before You Get Started

Safety Instructions

Electrical and Grounding Instructions

Care and Cleaning

Helpful Hints

Cleaning the Interior / Exterior

Changing the Carbon Air Purification Filter

FAQ’s

Before You Call For Service

Warranty

4 - 7

Installation Instructions

Sizes and Installation Dimensions

Leveling Your XO

Door Handle Installation

8 - 11

19 - 20

21 - 22

please read and follow

all safety instructions

It’s for your

own good...

Honest.

Installer Checklist

Find Your Model

Operating Instructions

Control System Overview

Setting the Temperature

Functions

Wine and Beverage Storage

Shelf Instructions

- 18

To ensure that the installation process is successfully completed,

here are few things to review...

Is the unit plugged in?

Are the controls on? (Panel will illuminate.)

Are the controls operating correctly?

Has the unit been properly leveled - both side to side and front to back -

with all 4 leveling feet securely making contact with the floor?

Is the door sealing properly?

Is the handle secure?

Have you thoroughly inspected the stainless steel surfaces for any imperfections?

Have you reviewed this manual with the customer and explained the unit’s operation and care?

Has the customer received copies of the literature and keys?

Have you properly disposed of all packing materials properly (recycle, please)?

Is the customer satisfied?

After installation, does the door open sufficiently to fully extend the shelves?

RISK OF CHILD ENTRAPMENT!

An empty refrigerator is a very dangerous attraction to children.

Remove door gaskets, latches, lids, lock and/or doors from unused or discarded appliances,

or take other actions to guarantee them harmless.

Always dispose of old appliances in accordance with local laws and regulations.

XOU15WGS

XOU24WGS

XOU24WDZGS

WINE COOLERS

24” 15”

BEVERAGE CENTERS

XOU15BCGS

XOU15BCSF

XOU24BCGS

XOU24BCSF

XOU24BWDDGS

XOU30BWDDGS

30” 24” 15”

take a minute to circle your model above

and record your serial number

here in case you need it later

Please read through completely before using your XO Unit

To prevent damage to the door gasket, the door must be opened all the way before pulling shelves out.

The appliance must be positioned so that the plug is accessible.

Empty your XO unit before attempting to move the appliance. Moving while loaded may damage or

distort the frame.

The compressor will get HOT during operation / touching it may cause injury.

During installation follow all safety tips provided in this manual / appropriate safety equipment such as

safety glasses and work gloves should be worn.

Two people should move or lift your XO unit to prevent injury or damage.

Remove all interior and exterior packing materials prior to installation and dispose of properly.

Never cover the bottle racks with foil or other material which will impede internal air circulation.

For maximum efficiency, keep the door tightly shut unless loading or unloading and never overload your

XO unit.

Before installing, allow your XO unit to sit upright for 2 hours at the install site. This will allow the cooling

system to stabilize after transportation. Failure to follow this step may cause problems.

Location

Your XO unit should be located away from direct sunlight and heat sources (stove, heaters, etc.) which may

increase electrical consumption. High or low ambient temperature may cause units to work improperly.

The floor must be strong enough to support your XO unit fully loaded.

Your XO unit must not be installed in areas of where water or e

xcessive moisture are present.

Your XO unit’s final installation must observe the correct minimum air clearances around and behind the

unit to ensure adequate ventilation. In addition, all ventilation openings must be kept clear and free of

obstructions, failure to do so will result in damage to the unit.

WARNING

NEVER use external heat sources to accelerate defrosting

NEVER permit unauthorized service or modifications to your XO unit

NEVER tamper with the sealed refrigerant system - this unit uses R600A Refrigerant which is flammable.

It should never be used in the vicinity of any flammable or explosive ignition sources.

ALWAYS FOLLOW THE ELECTRICAL SAFETY INSTRUCTIONS OUTLINED IN THIS MANUAL.

your safety matters

Never store perishable food products such as meat or cheese in your wine cooler or beverage center.

Your XO unit must not be installed near

where flammable, corrosive or hazardous materials are present.

Failure To Follow All Electrical Safety Measures May Result in Serious Injury,

Fire Or Death

All electrical work should only be performed by an

experienced, licensed electrician.

All XO units MUST be grounded for safe operation and

come equipped with a

3 Prong molded cord/plug for that

purpose.

NEVER remove or disable the 3rd prong with an adapter.

NEVER use an extension cord to operate your XO unit.

Your XO unit is built to operate on 115V 60Hz and

should be plugged directly into a dedicated 15 amp

3 prong outlet. If you are uncertain as to the

voltage, amperage capacity or if the 3rd prong is

properly grounded - consult a licensed electrician.

To maximize the depth of the installation recess -

your outlet should be mounted flush with the wall.

Your XO unit should not share the circuit with any other

electrical devices as this may cause overloading,

overheating, blown fuses ortripping circuit breakers.

In a worst case this can pose a fire hazard.

NEVER handle your XO unit in wet conditions as this

can pose a severe danger of electric shock.

Exercise care when moving your XO unit to avoid

damage to the electrical cord. If the electrical cord of

your XO unit becomes worn or damaged it must be

replaced immediately by a qualified technician.

NEVER unplug your unit by pulling on the cord.

Unplug by gripping the plug firmly and pull out

straight from the outlet.

INDOOR USE ONLY:

This model isintended for indoor/interior

applications only and is not to be used in

installations that are open/exposed to natural

elements.

This unit isdesigned to operate between 60 F and

90 F. Higher ambient temperatures may reduce

the unit’sability to reachlowtemperatures and/or

reduce performance.

Forbest performance, keep the unit out ofdirect

sunlight and away from heat generating equipment.

In climates where high humidity and dewpoints are

present, condensationmay appearonoutside surfaces,

particularly in non airconditioned spaces.

This isconsidered normal. The condensation will

evaporate when the humidity drops.

CAUTION

Damagescaused by ambient extremesare not

covered by the warranty

SERVICE 115V - 60 Hz - 1 phase

AMPS 15 Amp Circuit Breaker

Requires a DedicatedOutlet

All electrical work must be performed by

a licensed electrician

Serious injury, ﬁre or death...

Okay -

use free standing - or - install under counter

when installing -

you might use a recessed outlet or

cut the adjoining cabinet wall to

reach an outlet there...

ALL XO UNDERCOUNTER

UNITS ARRIVE PRE-WIRED

WITH LOW PROFILE PLUGS

FOR EASY INSTALLATION

34 1/4” MIN

“A”

SEE CHART

MODEL DIMENSION “A”

XOU15

XOU24

XOU30

15” MIN

24” MIN

30” MIN

90°

Door Swing

WALL

Clearance

Gap

IF THE DOOR CAN’T OPEN FULLY - YOU CAN’T PULL THE SHELVES OUT.

SS DOOR MODELS

INSTALLING WITH

THE HINGE SIDE

NEXT TO A WALL -

LEAVE A 2 1/4” SPACE

DOOR MUST BE

ABLE TO OPEN 90 .

FRENCH DOOR

MODELS INSTALLING

NEXT TO A WALL -

DOOR MUST BE

ABLE TO OPEN 120 .

120°

Door Swing

WALL

Clearance

Gap

15”

MODELS

24”

MODELS (Single or Double Door)

30”

MODELS

14 31/32" 23 27/32" 23 27/32" 29 9/16"

ALL

MODELS

ARE

HIGH

3/32"

W W W

MODELS WITH

OVERLAY DOORS

ALL OTHER

MODELS

23 11/16” 23 1/4"

D D

THE DEPTH IS SHOWN

WITHOUT HANDLES

EITHER THE STANDARD OR

PRO HANDLE WILL ADD 1 3/4”

TO THE DEPTH

DO NOT NEGLECT THIS IMPORTANT STEP

Rotate to raise or lower the LEVELING LEGS located at each of the four corners until all four legs

are seated firmly on the floor and the interior floor of the unit is level both front to back and

side to side.

Failure to follow this important step may cause problems with proper door operation, excessive

condensation, vibration and noise.

get your level out
