To charge your Xtreme Bluetooth® mono headset, connect the
supplied Micro USB cable to the Micro-USB (1) charging port and
connect the other end to a USB power outlet (5V adaptor not
included). LED indicator (5) will illuminate RED to indicate that
the mono headset is charging. Allow approximately 3-4 hours
charging time to fully charge the mono headset. When battery is
fully charged, the LED will turn BLUE. (Do not charge overnight).
Please make sure battery is fully charged before initial use.
Operating Bluetooth® Mono Headset
1.Turn the Bluetooth® Mono Headset on by holding down the
Multifunction button (2) for two seconds.The mono headset will state
“Power On”and The LED light indicator (5) will begin Flashing blue
and red to indicate that the earpiece is now in pairing mode.
2.Enable Bluetooth®search mode on your smartphone and select
pairing name“XHF9-0102”on your Bluetooth device list. Once the
mono headset has successfully connected, the mono headset will state
“Connected”and the LED indicator (5) will ash blue periodically.
3.Press the Multifunction button (2) to answer and hang-up
calls, pause and play music.
4. To raise the volume, long press theVolume“+”Button (3).To
change to the next track, short press the Volume“+”Button (3).
5. To lower volume, long press theVolume“–“ Button (4).To change
to the previous track, short press the“–“ Button (4).
6.To Power down the mono headset, hold down the Multifunction
button (1) for Four seconds. The Mono Headset will state
“Power O”and the LED indicator will remain o.
MANUAL (ENGLISH)
Charging Bluetooth® Mono Headset
2
