DTX-MULTI 12 Firmware Update Guide 1
DTX-MULTI 12
Firmware Update Guide
Thank you for choosing a Yamaha product.
This document explains how to update the firmware of the DTX-MULTI 12 and the update history.
For details of the major new functions and operations, refer to DTX-MULTI 12-related documents on the
following website:
http://download.yamaha.com
■Special Notices
・ When you execute this update program, any settings you have made such as Trigger Setups and pad
types will be overwritten with the corresponding defaults.
・ Please save your important data onto the USB storage device before updating the firmware of the
DTX-MULTI 12.
・ This updater is to be used at the user’s own risk.
・ DO NOT power off or disconnect the cable from the product during the updating process. The DTX-
MULTI 12 may be damaged.
・ DO NOT remove the USB storage device from the product during the updating process. The DTX-
MULTI 12 and the USB storage device may become inoperable.
・ If the update fails, and the DTX-MULTI 12 still does not operate correctly even after you execute the
update once again, please contact your Yamaha dealer.
・ This software and documentation are the exclusive copyrights of Yamaha Corporation.
・ Reproducing or modifying all or parts of this software or its documentation without permission is strictly
prohibited.
・ The company names and product names in this document are the trademarks or registered trademarks
of their respective companies.
EN
DTX-MULTI 12 Firmware Update Guide 2
Included Files
This folder contains the following files:
・dtx_m12_en_update_guide_v***.pdf This document (PDF file)
・the "***.PGM" file The update program
Required Items
・USB storage device formatted on the DTX-MULTI 12
For details of compatible USB Devices, please visit the following website:
http://download.yamaha.com
Confirming the Current Version
Hold down the [SHIFT] button and then turn the power on by pressing the Standby/On switch.
"Firm Ver : *.**" indicates the current version of the firmware.
NOTE
If the message above does not appear, turn the power off by pressing the Standby/On switch and try again.
DTX-MULTI 12 Firmware Update Guide 3
Updating Procedure
NOTICE
Please save your important data onto the USB storage device before updating the firmware of the DTX-
MULTI 12.
1. After downloading, decompress the archived file, and then find the "***.PGM" file. Copy the
"***.PGM" file to the root of the USB storage device.
2. Make sure to turn the power off (the Standby/On switch is set to the Standby position,) and then
connect the USB storage device to the [USB TO DEVICE] terminal on the side panel.
3. Hold down the [▽△] button, and then turn the power on by pressing the Standby/On switch.
4. Press the [ENTER] button to start the update process. This process takes a few minutes.
5. When the update process is completed, the message “Completed. Reboot MULTI 12” will appear,
and you can turn the power off (the Standby/On switch is set to the Standby position.)
6. Confirm the version of the firmware as described in “Confirming the Current Version.”
This completes the update process.
Manual Development Group
©2016 Yamaha Corporation
Published 07/2016 YJ-A0
DTX-MULTI 12 Firmware Update Guide 4
Main Enhancements
【V1.03 → V1.10】
・ Added new pad types for the DT50S/DT50K and KP100. (101 page of Owner’s Manual)
・ Added the new trigger parameter “NoiseFilterTable.”
・ Added the new trigger parameter “2P Balance.”
・ Added new setting values “14&15” and “16&17” for Copy Trigger parameters “Pad to copy” and “Pad
to replace.” (104 page of Owner’s Manual)
■Version History
【V1.02 → V1.03】
・ Added “ph2” setting for ClkOutSel (Click-track output selection) parameter. (84 page of Owner’s
Manual) This setting is used to output the click-track via the PHONES jack only, and all other sound
via the OUTPUT (L/MONO and R) jacks only.
・ Added new pad types as follows. (101 page of Owner’s Manual)
KU100, TP70S Snare, TP70S Tom, TP70S HiHat, TP70, PCY100, PCY90, XP80 Snare, XP80Tom,
XP70
・ Expanded the input gain setting range. (101 page of Owner’s Manual)
【V1.01 → V1.02】
・ Fixed a bug where, when two HH65 Hi-hat Controllers connected to the FOOT SW and HH CTRL
jacks were simultaneously operated, a sound would be produced only for one of them.
【V1.00 → V1.01】
・ Added new pad types for external pads as follows.
New Pad Type Model
KP125W/125 KP125W/125
XP120/100Sn XP120SD/100SD
XP120/100Tm XP120T/100T
・ Fixed a problem in which the DTX-MULTI 12 may freeze along with the loss of currently recorded data,
when the recording operation uses up the full memory for User patterns.
・ Solved some minor errors.
