OWNER’S MANUAL

READ THIS MANUAL CAREFULLY!

It contains important safety information.

LIT-11626-19-15 3B5-28199-10

This ATV should not be ridden by anyone under 16 years of age.

YFZ350V

3B5-9-10 hyoshi 4/8/05 1:41 PM Page 1

3B5-9-10 hyoshi 4/8/05 1:41 PM Page 2

EBU13320

INTRODUCTION

Congratulations on your purchase of the Yamaha YFZ350. It represents the result of many years

of Yamaha experience in the production of fine sporting, touring, and pacesetting racing

machines. With the purchase of this Yamaha, you can now appreciate the high degree of crafts-

manship and reliability that have made Yamaha a leader in these fields.

This manual will provide you with a good basic understanding of the features and operation of this

ATV. This manual includes important safety information. It provides information about spe-

cial techniques and skills necessary to ride your ATV. It also includes basic maintenance and

inspection procedures.If you have any questions regarding the operation or maintenance of your

ATV, please consult a Yamaha dealer.

AN IMPORTANT SAFETY MESSAGE:

8READ THIS MANUAL TOGETHER WITH TIPS FOR THE ATV RIDER CAREFULLY AND

COMPLETELY BEFORE OPERATING YOUR ATV. MAKE SURE YOU UNDERSTAND ALL

INSTRUCTIONS.

8PAY CLOSE ATTENTION TO THE WARNING AND CAUTION LABELS ON THE ATV.

8NEVER OPERATE AN ATV WITHOUT PROPER TRAINING OR INSTRUCTION. FREE

TRAINING IS AVAILABLE TO ANYONE WHO BUYS A NEW ATV. CALL 1-800-887-2887 FOR

MORE INFORMATION.

8THIS ATV, AND ANY OTHER ATV OVER 90cc, SHOULD NOT BE RIDDEN BY ANYONE

UNDER 16 YEARS OF AGE.

8THIS ATV IS A HIGH PERFORMANCE ATV FOR OFF-ROAD USE ONLY, FOR SPORT TYPE

RECREATIONAL AND COMPETITIVE USE BY EXPERIENCED OPERATORS.

3B5-9-10-01 3/31/05 1:36 PM Page 1

EBU00801

IMPORTANT MANUAL INFORMATION

FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN

SERIOUS INJURY OR DEATH.

Particularly important information is distinguished in this manual by the following notations:

QThe Safety Alert Symbol means ATTENTION! BECOME ALERT!

YOUR SAFETY IS INVOLVED!

wFailure to follow WARNING instructions could result in severe injury or death

to the machine operator, a bystander or a person inspecting or repairing the

machine.

cCA CAUTION indicates special precautions that must be taken to avoid

damage to the machine.

NOTE: A NOTE provides key information to make procedures easier or clearer.

3B5-9-10-01 3/31/05 1:36 PM Page 2

EBU15000

IMPORTANT NOTICE

This ATV is designed and manufactured for OFF-ROAD use only. It is illegal and unsafe to oper-

ate this ATV on any public street, road or highway.

This ATV complies with all applicable OFF-ROAD noise level and spark arrester laws and regula-

tions in effect at the time of manufacture.

Please check your local riding laws and regulations before operating this ATV.

AFFIX DEALER

LABEL HERE

EBU13330

YFZ350V

OWNER’S MANUAL

U.S.A.

1st edition, April 2005

Any reprinting or unauthorized use

without the written permission

of Yamaha Motor Corporation, U.S.A.

is expressly prohibited.

Printed in Japan.

P/N LIT-11626-19-15

3B5-9-10-01 3/31/05 1:36 PM Page 3

LOCATION OF THE WARNING AND

SPECIFICATION LABELS....................1-1

SAFETY INFORMATION......................2-1

DESCRIPTION AND MACHINE

IDENTIFICATION .................................3-1

Identification number records............3-2

Key identification number..................3-2

Vehicle identification number ............3-3

Model label........................................3-3

CONTROL FUNCTIONS ......................4-1

Main switch........................................4-1

Handlebar switches...........................4-2

Throttle lever .....................................4-3

Throttle OverRide System.................4-4

Speed limiter .....................................4-4

Clutch lever .......................................4-6

Front brake lever ...............................4-6

Brake pedal .......................................4-7

Parking brake ....................................4-7

Shift pedal .........................................4-9

Kick starter ........................................4-9

Fuel tank cap...................................4-10

Fuel cock.........................................4-10

Starter (choke).................................4-11

EBU00014

Indicates a potential hazard that could

result in serious injury or death.

CONTENTS

3B5-9-10-01 3/31/05 1:36 PM Page 4

Seat.................................................4-12

Front shock absorber

adjustment.....................................4-13

Rear shock absorber

adjustment.....................................4-14

PRE-OPERATION CHECKS ................5-1

Front and rear brakes........................5-3

Fuel ...................................................5-5

Engine mixing oil ...............................5-6

Transmission oil ................................5-7

Chain.................................................5-7

Throttle lever .....................................5-7

Tires ..................................................5-8

How to measure tire pressure ...........5-9

Tire wear limit ..................................5-10

Fittings and fasteners......................5-10

Lights...............................................5-10

Switches..........................................5-10

OPERATION .........................................6-1

Starting a cold engine........................6-1

Starting a warm engine .....................6-3

Warming up .......................................6-3

Shifting ..............................................6-4

To start out and accelerate................6-5

To decelerate.....................................6-6

Engine break-in .................................6-7

Parking ..............................................6-8

Parking on a slope ............................6-9

Accessories and loading .................6-10

Riding Your ATV....................................7-1

Getting to know your ATV ..................7-3

Ride with care and good

judgement .......................................7-4

Be careful where you ride ...............7-16

Turning your ATV ............................7-23

Climbing uphill.................................7-25

Riding downhill ................................7-30

3B5-9-10-01 3/31/05 1:36 PM Page 5

Crossing a slope .............................7-32

Crossing through shallow water ......7-34

Riding over rough terrain.................7-36

Sliding and skidding ........................7-38

What to do if... ................................7-40

What to do... ...................................7-40

PERIODIC MAINTENANCE AND

ADJUSTMENT......................................8-1

Owner’s manual and tool kit..............8-1

Periodic maintenance/Lubrication .....8-3

Transmission oil ................................8-6

Cooling system..................................8-8

Spark plug inspection......................8-13

Air filter element cleaning................8-14

Spark arrester cleaning ...................8-17

Carburetor settings..........................8-19

Idle speed adjustment .....................8-26

Throttle lever adjustment.................8-28

Front and rear brake pad

inspection ......................................8-29

Brake fluid level check ....................8-30

Brake fluid replacement ..................8-31

Front brake lever free play ..............8-32

Brake pedal height adjustment........8-33

Parking brake adjustment ...............8-34

Adjusting the rear brake light

switch ............................................8-36

Clutch adjustment ...........................8-36

Drive chain slack check...................8-37

Drive chain slack adjustment ..........8-37

Lubricating the drive chain ..............8-38

Cable inspection and lubrication .....8-39

Brake and shift pedal/brake and

clutch lever lubrication...................8-40

Lubricating the front upper and

lower arm pivots ............................8-40

Rear arm pivot lubrication ...............8-41

Wheel removal ................................8-42

Wheel installation ............................8-42

Replacing the headlight bulb...........8-43

Headlight beam adjustment ............8-45

3B5-9-10-01 3/31/05 1:36 PM Page 6

Tail/brake light bulb replacement.....8-46

Troubleshooting...............................8-47

Troubleshooting chart......................8-48

No spark..........................................8-51

CLEANING AND STORAGE ................9-1

A. Cleaning........................................9-1

B. Storage .........................................9-3

SPECIFICATIONS ..............................10-1

NOISE REGULATION.........................11-1

MAINTENANCE RECORD.................12-1

ATV LIMITED WARRANTY ................13-1

3B5-9-10-01 3/31/05 1:36 PM Page 7

Read and understand all of the labels on your

machine. They contain important information

for safe and proper operation of your ATV.

Never remove any labels from your ATV. If a

label becomes difficult to read or comes off, a

replacement label is available from your

Yamaha dealer.

1-1

EBU00464

LOCATION OF THE WARNING AND

SPECIFICATION LABELS

wr y
