Yardgard YG03 Montageanleitung
Congratulation on purchasing the YARDGARD safety alarm. he YARDGARD can
be used to monitor potential dangerous areas, and provides a loud volume
alarm/alert when these areas are entered. It can be used indoors or outdoors,
mounted on a wooden fence or metal gate. It can be mounted on any doorway or
opening that leads to potentially dangerous areas.
CAU ION: he alarm siren is very loud. Never place the unit close to your ear.
Prolonged exposure to the loud siren can affect your hearing. Install the unit at
minimum height 54", high enough to be out of reach of children.
his YARDGARD is an entry monitor device. All safety precautions should be
maintained, including parental supervision.
Neither SmartPool LLC. nor anyone else who has been involved in the creation,
reproduction or delivery shall be liable for any direct, indirect, consequential or
incidental damages arising out of the use of the YARDGARD.
NO. YG03
INS ALLA ION/OPERA ION INS RUC IONS
Installing the Battery
Before installing the battery, use a rubber band to
hold the magnet sensors together temporarily, with
dot matched to dot, thereby preventing the alarm
from sounding after the battery is installed when
mounting the unit.
o install the battery, remove the four screws at the
back, then open the battery door.
Install a fresh 9V battery (not included) into the
battery compartment. Check the polarity.
Close the battery door and tighten the four screws.
Now the unit is ON and in working mode. o check if
battery is installed properly, press the battery check
button located at the lower right corner. he unit will
beep when you press this button. If no beep sound is
heard, check the battery installation again, or replace
with a new battery.
Auto Battery Check
he unit will keep monitoring the battery level. When
it detects that the battery is low, you will hear a loud
and short beep every minute. Change battery when
you hear this beep.
Check battery periodically.
Change battery a minimum of once a year.
Mounting on a Wooden Fence
Install the mounting bracket onto a
fence post using the two bigger
screws. Slide the alarm unit onto this
mounting bracket. You will feel a click
when the unit is properly installed.
Mount the two magnet sensors onto
the fence post, one on each side,
using the four smaller screws.
Mounting on a Metal Gate
Install the mounting bracket onto a
gate post using two nylon straps.
Slide the alarm unit onto this
mounting bracket. You will feel a click
when the unit is properly installed.
Mount the two magnet sensors onto
the two spacer stands using the four
smaller screws and then mount this
sensor assembly onto the gate post
using the nylon straps.
Mounting on a Wall And Glass Doors
Install the mounting bracket using two pieces of
double sided foam tape. Slide the alarm unit onto
this mounting bracket. You will feel a click when the
unit is properly installed.
Apply the double sided foam tape onto the bottom
recessed area of magnet sensor pair. Mount the
magnet sensors, one on the door and the other on
the door frame.
Mount the magnet sensor with the wire onto the
stationary surface such as door frame.
Additional PASS/RESE Switch
his unit provides an additional PASS/ RESE
switch, which can be mounted on the other side of
the door for convenient access from both sides.
his additional switch can be mounted by the 2
smaller screws or double-sided foam.
Operation
his YARDGARD is designed to monitor the opening
of gate or door, to alert an adult if a child has opened
a gate or door to a potential dangerous area.
Check the battery. Press the CHECK button should
give a loud beep, otherwise replace with a new
battery. he unit will give a loud siren if gate or door
is opened by more than one inch.
For adult entry, press the PASS button. he unit will
allow the door be opened up to 7 seconds without
triggering alarm. However, if the gate or door is
opened for over 7 seconds, the alarm will trigger.
o reset the alarm, first close the door and then
press the PASS/RESE button. he alarm is now
back to stand by mode.
o exit the protected area, press the PASS/RESE
button and exit the area within 30 seconds.
Automatic Reset Under All Conditions
he unit will be reset automatically in 30 seconds
after the last key activation. If the PASS/RESE
button is pressed but the adult entry 7 seconds
allowance is not utilized, this adult entry allowance
will be canceled in 30 seconds, and reset to standby
mode automatically.
Auto Siren OFF
Siren can be turned OFF manually as describe on
previous section, or the unit will reset in 4 minutes
automatically if the gate is closed.
Automatic Continuous Monitoring
If alarm is triggered and reset by itself in 4 minutes,
the unit will check the condition of magnet contact
sensor to decide if the door remains open or not. If
the door is left open, the alarm sounds again for 4
minutes, check the door condition again and
continue the cycle until the door is closed.
Keep the distance between the two magnet sensor contacts to
a maximum of 3/4"
est the unit by opening the door. he alarm should go off immediately;
otherwise contact SmartPool at (732) 730-9880.
Do not rely on the alarm until the test results are satisfactory.
IMPOR AN
Install the unit at minimum height 54",
high enough to be out of the reach of children
www.smartpool.com
