YASKAWA PROFINET V1000 Bedienungsanleitung

MANUAL NO. TOBP C710606 21D

フィンレスタイプ設置要領書

To properly use the product, read this manual thoroughly and retain

for easy reference, inspection, and maintenance. Ensure the end user

receives this manual.

安川インバータV1000

形式 CIMR-VAJ

CIMR-VAL

小形ベクトル制御

容量範囲 200 V級（三相電源用）

0.1〜18.5 kW

200 V級（単相電源用）

0.1〜3.0 kW

400 V級（三相電源用）

0.2〜18.5 kW

製品を安全にお使い頂くために，この取扱説明書を必ずお読みください。

また，本書をお手元に保管していただくとともに，最終的に本製品をご使用になる

ユーザー様のお手元に確実に届けられるよう，お取り計らい願います。

Finless Type Installation Guide

YASKAWA AC Drive -V1000

Type CIMR-VAJ

CIMR-VAL

Compact Vector Control Drive

Models 200 V Class, Three-Phase Input: 0.1 to 18.5 kW

200 V Class, Single-Phase Input: 0.1 to 3.0 kW

400 V Class, Three-Phase Input: 0.2 to 18.5 kW

YASKAWA EL E C TRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide 3

Table of

Contents

1 PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3 CONDITIONS OF ACCEPTABILITY. . . . . . . . . . . . . . . . . . . . 9

4 PERIODIC MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . 16

5 DIMENSIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

6 SELECTING AN EXTERNAL HEATSINK. . . . . . . . . . . . . . .22

7 REVISION HISTORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide

transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or

otherwise, without the prior written permission of Yaskawa. No patent liability is assumed with

respect to the use of the information contained herein. Moreover, because Yaskawa is constantly

striving to improve its high-quality products, the information contained in this manual is subject to

change without notice. Every precaution has been taken in the preparation of this manual.

Nevertheless, Yaskawa assumes no responsibility for errors or omissions. Neither is any liability

assumed for damages resulting from the use of the information contained in this publication.

YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide 5

1 Preface

◆Applicable Documentation

This manual provides instructions on installing the V1000 Finless drive. For more specific

information on the operation of this product, refer to the other manuals listed in the

following table:

◆Terms

Note: Indicates supplementary information that Yaskawa highly recommends be followed,

even though equipment may not be at risk.

Yaskawa AC Drive - V1000 Finless Installation Guide

Manual No.: TOBPC71060621

This guide contains basic information required to install the V1000 Finless.

Yaskawa AC Drive - V1000 Technical Manual

This manual describes installation, wiring, operation procedures, functions,

troubleshooting, maintenance, and inspections to perform before operation.

To obtain instruction manuals for Yaskawa products access these sites:

U.S.: http://www.yaskawa.com

Europe: http://www.yaskawa.eu.com

Japan: http://www.e-mechatronics.com

Other areas: contact a Yaskawa representative.

Yaskawa AC Drive - V1000 Quick Start Guide

This guide is packaged together with the product. It contains basic information

required to install and wire the drive. This guide provides basic programming and

simple setup and adjustment.

Drive: Yaskawa AC Drive-V1000 Finless Drive

STOP

(Hz)

(A)

(V)

V1000

周波数指令

正転逆転選択

出力周波数

出力電流

出力電圧

モニタ

ベリファイ

セットアップ

パラメータ設定

オートチューニング

据え付け、運転の前には必ず取扱説明書を読むこと。

通電中および電源遮断後

分以内はフロントカバーを

外さないこと。

400V

級インバータの場合は、電源の中性点が接地

されていることを確認すること。（対応）

けが．感電のおそれがあります。

危険

1 Preface

6YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide

◆Registered Trademarks

• Company names and product names listed in this manual are registered trademarks

of those companies.

General Precautions

• The diagrams in this manual may be indicated without covers or safety shields to show details.

Restore covers or shields before operating the drive and run the drive according to the instructions

described in this manual.

• The products and specifications described in this manual or the content and presentation of the

manual may be modified without notice to improve the product and/or the manual. Such

modifications are indicated by a revised manual number.

• When ordering a new copy of the manual due to damage or loss, contact your Yaskawa

representative or the nearest Yaskawa sales office and provide the manual number shown on the

front cover.

• If nameplate becomes worn or damaged, order a replacement from your Yaskawa representative or

the nearest Yaskawa sales office.

• Yaskawa is not responsible for any modification of the product by the end user. Modification of the

product voids the warranty.

NOTICE

For UL/CE compliance, a separate A6T50 fuse must be installed drive models

CIMR-V4A0023J. For all other models drives, refer to the Quick Start Guide

packaged with the drive for the type of fuse required.

Failure to use the specified fuse can damage the drive.

YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide 7

2 Product Overview

◆About This Product

This manual describes installation conditions and dimensions for the V1000 Finless drive.

Use this product only after you have a full understanding of the manual and its contents.

This V1000 Finless drive is a component recognized by Underwriters Laboratories

Inc.(UL). The installation procedure and instructions have been provided to fulfill the

requirements as specified by the “Conditions of Acceptability”.

◆Model Number and Nameplate Check

Please perform the following tasks after receiving the drive:

• Inspect the drive for damage.

• If the drive appears damaged upon receipt, contact the shipper immediately.

• Verify receipt of the correct model by checking the information on the nameplate.

• If you have received the wrong model or the drive does not function properly, contact

your supplier.

2 Product Overview

8YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide

■Nameplate

Figure 1

Figure 1 Nameplate Information

■Drive Model Identification

The V1000 finless drive type is indicated by the letter “J” or “L” in the AC drive model

designation code. Refer to the Quick Start Guide for complete model number information.

Figure 2 Understanding the Model Number

<1> The drive must be installed a control panel with a proper heat sink.

PRG : 1011

CIMR-VA2A0003JAA

YASKAWA ELECTRIC CORPORATION

MADE IN JAPAN

: AC3PH 200-240V 50 / 60Hz 2.7A / 1.4A

: AC3PH 0-240V 0-400Hz 1.2A / 0.8A

: 0.6 kg

: E131457 IP20

PASS

MODEL

MAX APPLI. MOTOR : 0.75kW / 0.4kW REV : A

INPUT

OUTPUT

MASS

O / N

S / N

FILE NO

7J48

AC drive model

Max applicable motor

Input specifications

Output specifications

Mass

Lot number

Serial number

Software version

CIMR

V A2A0001 JAA

Drive V1000

Series

Region

Code

Voltage

Class

No. Enclosure

Type

Environmental

Specification

Design

Revision

Order

Customized

Specification Finless

(IP20) <1>

Finless

(IP00) <1>

Unit

No.

YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide 9

3 Conditions of Acceptability

Adhere to the installation conditions specified in this guide to take full advantage of the

finless design of this drive.

◆Installation Environment

The drive must be installed a control panel with a proper heat sink. The drive ambient

temperature shall not exceed 50 ºC (122 ºF) for the drives installed location.

◆Heatsink Plate Temperature

The aluminum panel on the back of the drive is referred to as the “heatsink plate.” The

heatsink plate temperature should never exceed the following values:

CIMR-VBA, CIMR-V2A0001~0020, CIMR-V4A0001~0011: 90 °C

CIMR-V2A0030~0069, CIMR-V4A0018~0038: 80 °C

Table 6 and Table 7 lists the thermal characteristics of the drive.

Use parameter U4-08 to check the temperature of the heatsink plate as described below.

NOTICE: The drive may be damaged if the temperature of the heatsink plate exceeds specified tolerance

levels (90 °C or 80 °C, depending on the model). Excessive heat can also shorten the performance life of

various drive components.

■Checking and Monitoring Heatsink Plate Temperature

Checking Heatsink Plate Temperature Using the LED Operator

Scroll to parameter U4-08 (heatsink plate temperature).

When the temperature of the heatsink plate is 89 ºC, U4-08 will display:

Note: Parameter U4-08 is available in drive software version 1011 or later.

Checking Heatsink Plate Temperature Using an Analog Output

Example: When using Multi-Function Analog Output Terminal AM, set the parameters

shown in Table 1.

Table 1 Using Analog Output 1

No. Name Description

H4-01 Analog Output Terminal AM Function Selection 00408

(heatsink plate temperature)

H4-02 Analog Output Terminal AM Gain 100.0%

H4-03 Analog Output Terminal AM Bias 0.0%

3 Conditions of Acceptability

10 YASKAWA ELECTRIC TOBP C710606 21D YASKAWA AC Drive - V1000 Finless Installation Guide

Figure 2

Figure 3 Output of Heatsink Plate Temperature by Analog Output

Note: 1. Accuracy of the temperature reading may vary ±5 ºC between 50 and 100 ºC.

2. The heatsink temperature is affected by the ambient temperature. Never exceed the allowable maximum

heatsink plate temperature.

■Drive Overheat Alarm (oH)

Use parameter L8-02 to cause the drive output an alarm when the heatsink plate exceeds the

specified temperature.

L8-03 determines the action taken by the drive when an oH alarm is triggered. Refer to the

V1000 Technical Manual for more details.

◆Installation to Metallic Surface

The mating surface shall have the following properties:

• Surface flatness shall not exceed 0.2 mm across the entire mating surface.

• Surface roughness shall not exceed 25 S.

Note: A surface roughness of 25 S means “Ra” (average roughness) is not greater than 6.3 a and “Ry”

(maximum peak) is not greater than 25 μm.

◆Thermal Compound

Apply a thermal compound between the heatsink plate and the mating surface. The thermal

compound assists in drive heat dissipation.

Yaskawa recommends the thermal compounds in Table 2.

Output Voltage㧔V㧕

10.0

9.0

5.0

9050 100 Temperature（°C）
