YELLOWRIVER YR-S4001 Bedienungsanleitung

LED MINI SPOT MOVING

Model: YR-S4001

Contents

Section 1.Getting Started

Unpacking

Safety Instruction

Section 2. Set Up

Installation

Controlling Board

Machine Connection

Section 3. Troubleshooting

Troubleshooting

Section 4. Reference

Control Menu

DMX Protocol

Specification

本公司有权对此份产品说明书进行修改，恕不另行通知。

Our company reserve right to revise this user manual without notice!

Innovation | Efficiency | Dedication | Harmonious

Section 1. Getting Started

Unpacking

Safety Instruction

Unpacking

1pc Fixture

1pc User Manual

1pc Signal Cable

Thanks for using our MINI range. Carefully unpack the box and check the contents to ensure

that all parts are present and in good conditions. If anything looks as if it has been damaged in

transit, notify the shipper immediately and keep the packing material for inspection. Again,

please save the carton and all packing materials. If a fixture must be returned to manufacturer,

it is important that the fixture be returned in the original manufacturer box and packing.

Safety Instruction

Please

conserve this manual as operation guidance. If you sell this product to other user, please

make sure that they also receive this user manual.

Always make sure that you are connecting to the proper voltage and that the line voltage you

are connecting to is not higher than that stated on the decal or rear panel of the fixture.

The fixture is intended to indoor use only. To prevent risk of fire or shock, do not expose

fixture to rain or moisture. Make sure there are no flammable, explosive or corrosive

materials surrounded in 1.5 meter while operating.

The unit must be installed in a location with adequate ventilation, at least 50CM away from

adjacent surfaces. Be sure that no ventilation slots are blocked.

Do not operate at ambient temperatures higher than 95℉(35℃).

Safe wire should be used to install machine. Bearing of safe wire should be 3 times of the

machine weight. Complimentary signal cable transmits signals to 20 unit fixtures at most

within 20meters. Signal amplifier is a must to connect more fixtures. Sectional area of

complimentary power cable is 1㎡. In daisy chain model, it allows to connect to 4 fixtures at

most.

Always disconnect from the power source before servicing or replacing fuse/lamp and be

sure to replace with same fuse/lamp size and type. Cut off power before moving, repairing

and cleaning the machine.

Secure fixture using a safety chain and carrying handles. Never carry the fixture by its cord.

In case of failure or misfunction occurred, stop using the unit immediately.

Repairs carried out by unskilled people can lead to damage or malfunction. Buy the same

spare parts/components from manufacturer directly.

To avoid electric shock, all fixtures must be connected to circuits with a suitable ground.

Make sure the power cord is never crimped or damaged. Do not power on and power off the

fixture in a short time. For your safety, do not touch fixture when running.

When use DMX controller, please make sure that there is no interference sources(e.g.

intercom, high frequency radio waves and radiation source)

Caution! There are no user serviceable parts inside the unit. Do not open the housing or

attempt any repairs yourself. In the unlikely event your unit may require service, please contact

your local distribution or after-sale service center.

For your safety，please read this user manual carefully before

operation. The machine should be operated by qualified engineer！

Specification:

Voltage：AC110V-240V

Frequency：50/60Hz

Rated Power：80W

LED: 40W white

Strobe: 1-10 times / second

PAN: 540° (Electronic correction)

TILT: 220° (Electronic correction)

GOBO Wheel: 9 fixed gobo+ white beam, two ways flowage effect, gobo shaking,

electronic position

Color wheel: 7 color + white, rainbow effect, electronic position

Beam angle: 9°

Control：DMX512

Channel: 11 channels

Control Mode：DMX/sound active/auto/ master-slave/manual

Level of Protection: IP20

Stock: Clean and Dry place

Running Temp.: 0°C~35°C

Weight: 3.5kg

Size: 201.4X196X317.4MM

Section 2. Set Up

Installation

Controlling Board

Machine Connection

Installation

This machine should be mounted through the screw holes of truss. Safety wire is a must to

fix fixture well. Make sure truss and safety wire have strong load capacity to bear 3 times

weight than fixture at least. This machine should be installed by qualified technician.



Controlling Board

1. Display

LCD Display menu and selected function.

Button

ESC

switch menu function

On function: page up

On numerical value: increase value

DOWN

On function: page down

On numerical value: reduce value

ENTER

Settle selected function and value

Machine Connection

DMX CHART

Function

Description

CH1

0-255 0-540°

CH2

0-255 0-220°

CH3

X 16bit

0-255

CH4

Y 16bit

0-255

CH5

XY speed

0-255 from fast to slow

CH6

dimmer

0-255 from dark to bright

CH7

strobe

0-255 strobe from slow to fast

CH8

color

0-19 white，20-39 pink，40-59 green, 60-79

blue, 80-99 yellow, 100-119 purple, 120-139 blue,

140-159 orange, 160-207 rainbow effect with

clockwise run, 208-255 rainbow effect with

anti-clockwise run

CH9

gobo

0-9 beam，10-19 gobo 1，20-29 gobo 2，30-39

gobo 3，40-49 gobo 4，50-59 gobo 5, 60-69 gobo

6，70-79 gobo 7，80-89 gobo 8，90-99 gobo 9；

100-109 gobo 9 shaking，110-119gobo 8 shaking，

120-129 gobo 7 shaking，130-139gobo 6 shaking，

140-149 gobo 5 shaking，150-159 gobo 4shaking，

160-169 gobo 3 shaking，170-179 gobo 2

shaking，180-189 gobo 1 shaking；

190-222 gobo wheel in flowage run with clockwise

direction from slow to fast, 223-255 gobo wheel in

flowage run with anti-clockwise direction from slow

to fast

CH10

Auto/Sound

1-128 Auto, 129-255 Sound

CH11

reset

0-254 no work，255 reset （wait for 3 seconds）

Remarks: enter into each menu, please always remember to press ENTER to

save settings. Press ESC button is to go back previous menu.

Cable Connectors

Cables must have a male XLR connector on one end and a female XLR connector on the

other end.

A word on termination: DMX is a resilient communication protocol,

however errors still occasionally occur. Termination reduces signal errors, and therefore best

practices include use of a terminator in all circumstances. If you are experiencing problems

with erratic fixture behavior, especially over long signal cable runs, a terminator may help

improve performance.

To build your own DMX Terminator: Obtain a 120-ohm, 1/4-watt

resistor, and wire it between pins 2&3 of the last fixture. They are also readily available from

specialty retailers.

Master-Slave control model：

Set up one fixture as Master fixture(triggering),other fixtures as slave fixtures(receiving trigger

signals).Set up all fixtures same address value or following DMX controller

performance(Attention: all fixtures use the same DMX channel-11)

Option

Gobo:xxx

Gobo wheel reset finer adjust setting: UP/DOWN

adjust value 0-255, press enter to save.

MENU4:

Option

(PRESS ENTER)

Option

Sound:xxx

Sound active sensitivity adjust setting:

UP/DOWN adjust value 0-255, press

ENTER to save. value 0 is minimum

sensitivity, 255 is maximum

PassWord

UnLock

Password unlock: press ENTER,

UP/DOWN to choose three-digit-password

(default password is 988), press ENTER to

unlock password. power on after power

off, no need password.

MENU5:

PassWord

(PRESS ENTER)

PassWord

Lock

Password lock: press ENTER, UP/DOWN

to choose three-digit-password (lock password is

988), press ENTER to lock password. power

on after power off, need password.

MENU6:

Re- Def-

(PRESS ENTER)

Restore system default: press ENTER then fixture restore

factory default and reset.

MENU7:

Reset

(PRESS ENTER)

Fixture reset: press ENTER then fixture reset.

Maximum 20 PCS fixtures connected by Daisy chain connection.

Section 3. Troubleshooting

Section 4. Reference

Control Menu

DMX Protocol

Specification

Control Menu

MENU1:

Dmx:11CH

(PRESS ENTER)

Dmx:11CH

Add:xxx

DMX512: Press UP/DOWN to set up 1-512 add value,

always remember press ENTER to save your settings.

Test

Auto

AUTO: Press ENTER to active auto running and to

save the settings.

MENU2:

Test

(PRESS ENTER)

Test

Sound

SOUND: Press ENTER to active auto running and to

save the settings.

MENU3:

Manual

(PRESS ENTER)

Manual

CH01：xxx

…

Manual

CH11:xxx

Manual: UP/ DOWN adjust value 0-255, press ENTER

to save. (CH01-CH11 stands for 11 channels, SAME

function as DMX console.)

Option

Pan:Yes

X/Pan clockwise and anti-clockwise setting: UP/DOWN

to choose Yes/No, press ENTER to choose and save.

Choose Yes than X anti-clockwise running.

Option

Tilt:Yes

Y/Tilt clockwise and anti-clockwise setting: UP/DOWN to

choose Yes/No, press ENTER to choose and save.

Choose Yes than Y anti-clockwise running.

Option

YSet:xxx

Y/Tilt reset fine setting: UP/DOWN to adjust 0-255,

press ENTER to save.

MENU4:

Option

(PRESS ENTER)

Option

Color:xxx

Color wheel reset finer adjust setting: UP/DOWN adjust

value 0-255, press enter to save.

Probable cause(s)

Remedy

No power to fixture

Check power cables

Primary fuse blown

Replace fuse

No response from

fixture when power

is applies

Secondary fuse

blown

Replace fuse

Controller not

connected

Connect controller

Incorrect

addressing of the

fixtures

Check address setting on fixture and controller

Bad data link

connection

Inspect cables and correct poor connections

and/or broken cables.

Conflict between

tracking and vector

control

Eliminate scene cross-fade on controller

Data link not

terminated

Insert termination plug in output of last fixture

Fixture resets but

does not respond

correctly to

controller(DMX

mode operation)

Defective fixture or

2 devices

transmitting on link

Bypass fixtures one at a time until normal

operation is regained:unplug both connectors

and connect them directly together

Colors cannot be

mixed

Random color

mixing is on

Turn off random color mixing

Fixture does not

reset correctly

Electronic or

mechanical failure

Contact service technician

Lamp missing or

blown

Disconnect fixture and replace lamp

No light, lamp cuts

out intermittently,or

burns out too

quickly

Fixture or lamp is

too hot

Allow fixture to cool. If problem persists,contact

service technician

Inhaltsverzeichnis

Andere YELLOWRIVER DJ-Equipment Handbücher

YELLOWRIVER

YELLOWRIVER YR-W0384T Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-IP1007H Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-P0319SIR Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-COB5002 Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-IP350 Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-W0372T Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-W1036Q Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-1190 Bedienungsanleitung

YELLOWRIVER

YELLOWRIVER YR-W1004H Bedienungsanleitung

Beliebte DJ-Equipment Handbücher anderer Marken

ALPHA LITE

ALPHA LITE ALPHA 1500 Betriebsanleitung

Chauvet

Chauvet OVATION E-930VW Bedienungsanleitung

Zumtobel

Zumtobel APHRODITE Home Bedienungsanleitung

Snow Masters

Snow Masters Zig Oscillator Bedienungsanleitung

EuroLite

EuroLite 50530554 Bedienungsanleitung

Beamz

Beamz BUV243 Bedienungsanleitung

thomann

thomann Stairville DJ Lase 40-G MK-III Bedienungsanleitung

Eagletone

Eagletone 6 Eyes Flower Bedienungsanleitung

EuroLite

EuroLite FLD-1508 Bedienungsanleitung

Technical Pro

Technical Pro LG8xSEA Bedienungsanleitung

JB Systems

JB Systems Lounge Laser DMX Bedienungsanleitung

Lightmaxx

Lightmaxx Vega Halo 90 Bedienungsanleitung

Elation

Elation FUZE WASH Z350 Bedienungsanleitung

Maverick

Maverick MK3 WASH Bedienungsanleitung

Infinity

Infinity TF-260C7 Fresnel Bedienungsanleitung

Chauvet

Chauvet EVE E-50Z Bedienungsanleitung

Eliminator Lighting

Eliminator Lighting E 138 Bedienungsanleitung

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Bedienungsanleitung
