DISHWASHER

DA 6153

Instruction Book

152968 28/1 UK

The control panel

Description of the appliance

1. Upper basket stop

2. Water hardness switch

3. Salt container

4. Detergent dispenser (type A / type B)

5. Control panel

6. Rating plate

7. Rinse aid dispenser (type A / type B)

8. Filters

9. Lower spray arm

10. Upper spray arm

11. Upper basket

12. Worktop

IN148

Open the door and slide out the baskets to load the dishes.

The lower basket

The lower basket is designed to take saucepans, lids, plates,

salad bowls, cutlery etc.

Serving dishes and large lids should be arranged around the

edge of the basket, ensuring that the spray arms can turn

freely.

The cutlery basket

Long bladed knives stored in an upright position are a

potential hazard.

Long and/or sharp items of cutlery such as carving knives

must be positioned horizontally in the upper basket.

Take care when loading or unloading sharp items such as

knives.

Cutlery should be placed in the removable cutlery basket with

the handles facing downwards. If the handles protrude from

the bottom of the basket, obstructing the lower spray arm, load

the cutlery with the handles

facing upwards.

Mix spoons with other cutlery

to prevent them from sticking

together.

For best results we

recommend you to use the

cutlery grids provided (if the

size and dimensions of the

cutlery allow it).

In daily use

UI90 UI89

●Check if it’s necessary to refill with special salt or rinse aid

●Load cutlery and dishes into the dishwasher.

●Fill with dishwasher detergent .

●Select a wash programme suitable for the cutlery and

dishes.

●Start the wash programme.

Loading cutlery and dishes

Sponges, household cloths and any object that can

absorb water may not be washed in the dishwasher.

●Before loading the dishes, you should:

- Remove large left-overs.

- Soften remnants of burnt food in pans

●When loading the dishes and cutlery, please note:

- Dishes and cutlery must not impede the rotation of the

spray arms .

- Load hollow items such as cups, glasses, pans, etc. with

the opening downwards so that water cannot collect in the

container or a deep base.

- Dishes and items of cutlery must not lie inside one

another, or cover each other.

- To avoid damage to glasses, they must not touch.

- Lay small objects in the cutlery basket.

●Plastic items and pans with teflon have a tendency to

retain water drops; these items will not dry as well as

porcelain and steel items.

For washing in the dishwasher the following cutlery/dishes

are of limited suitability:

- Only wash stoneware in the dishwasher if it is specifically

marked as being dishwasher-safe by the manufacturer.

- Glazed patterns may fade if machine washed frequently

- Silver and aluminium parts have a tendency to discolour

during washing. Left-overs, e.g. egg white, egg yolk and

mustard often cause discolouring and staining on silver.

Therefore always clean left-overs from silver immediately, if

it is not to be washed straight after use.

- Some types of glass can become dull after a large number

of washes

are not suitable:

- Cutlery with wooden, horn, china or

mother-of-pearl handles

- Plastic items that are not heat resistant

- Older cutlery with glued parts that is not

temperature resistant

- Bonded cutlery items or dishes

- Pewter or copper items

- Lead crystal glass

- Steel items subject to rusting

- Wooden platters

- Items made from synthetic fibres

UI63

The cutlery basket is in two parts which can be separated to

give greater loading flexibility.

To separate the two parts,

slide them horizontally in

opposite directions and pull

them apart.

To reassemble, reverse the

procedure.

The upper basket

The upper basket is designed for plates (dessert plates,

saucers, dinner plates of up to 24 cm in diameter), salad

bowls, cups and glasses.

Arrange items on and underneath the cup racks so that water

can reach all surfaces.

Glasses with long stems can be placed upside down in the cup

racks.

Light items (plastic bowls

etc.) must be loaded in the

upper basket and arranged

so they do not move.

In case that plates are loaded in the upper

basket:

load them starting from the

rear positions of the basket;

tilting them slightly forwards

and avoiding the front

positions near the door.

Before closing the door, ensure that the spray arms can

rotate freely.

Adjusting the height of the upper basket

If washing very large plates you can load them in the lower

basket after moving the upper basket to the higher position.

To move to the higher position proceed as

follows:

1. Move the front runner stops (A) of the upper basket

outwards and slide the basket out.

2. Refit the basket in the higher position and replace the stops

(A) in their original position.

When the basket is in the

higher position you will not

be able to use the cup

rack(s).

After loading your machine always close the door, as an

open door can be a hazard.

UI62

US47

US71

With upper basket raised 20 cm 31 cm

With upper basket lowered 24 cm 27 cm

Maximum height of the dishes in

upper basket lower basket

RC01

BRILLIANT

FOR A

SHINE

RINSE

CONCENTRATED DISHWASHER DETERGENT

ACTION

NEW

DOUBLE

LIQUID GEL

POWDER

EASY

POURING

PACK

For best results we recommend the use of Finish detergents, rinse aid and salt.

DE15

Washing programmes

Programme Degree of soil

and

type of load

Starting

position of the

programme

selector dial

Required

main wash

temperature

push button

Heavy soil

Crockery,

cutlery, pots and

pans

Normal soil

Crockery and

cutlery

Normal soil

Crockery and

cutlery

Any.

Partial load (to

be completed

later in the day).

Cycle description

INTENSIVE

65°C

(1) ECONOMY

50°C

NORMAL

65°C

RINSE &

HOLD

Cold prewash

Main wash up to 65°C

2 cold rinses

1 hot rinse

Drying

Cold prewash

Main wash up to 50°C

1 cold rinse

1 hot rinse

Drying

Main wash up to 65°C

2 cold rinses

1 hot rinse

Drying

1 cold rinse (to avoid

food scraps from

sticking together).

(1) Testing programme for EN 50242 (see "Hints for Test Centres"). This programme, developed for the use of detergents with

enzymes, allows you to achieve, with reduced consumption of energy the same cleaning results that would otherwise be

obtained only with the 65°C programmes and conventional detergents. To compensate the lower temperature, the duration of

washing and drying have been extended.

(2) Ideal for washing crockery and cutlery of breakfast and dinner (fresh soil).

Characterised by a duration of about 30 minutes and a washing temperature of 60°C.

The time value is approximate and depends on the pressure and the temperature of the water and also by the variations

of the power supply.

This is the perfect daily programme, made to meet the needs of a family of 4 persons who only wish to load breakfast

and dinner crockery and cutlery.

(3) The consumption values are intended as a guide and depends on the pressure and the temperature of the water and also by

the variations of the power supply.

AECONOMY

50°

(3) Consumption values

Programme

duration

(in minutes)

Energy

consumption

(in kWh)

Water

consumption

(in litres)

125 - 135 1,4 - 1,5 18 - 20

115 - 125 0,95 - 1,05 16 - 18

110 - 120 1,4 - 1,5 14 - 16

Fresh soil

Crockery and

cutlery

(2) QUICK

65°C Main wash up to 65°C

1 hot rinse

C30 - 40 1,05 - 1,15 11 - 13

12 0,1 10

1. Check that the baskets have been

loaded correctly and that the spray

arms can rotate freely

2. Turn on the water tap

3. Close the dishwasher door

4. Set and start of the programme

Turn the programme selector dial clockwise until the

letter of the programme you wish to select corresponds

with the programme marker on the control panel.

If necessary select the temperature of the main wash

according to the instructions in the "Washing programmes"

chart (see "Required main wash temperature push

button").

Depress the On/Off push button.

The On/Off indicator light will come on and the machine

will start.

5. Interrupting a washing programme

in progress

Interrupt a washing programme in progress ONLY if

it’s absolutely necessary.

Attention! Hot steam may escape when the door is

opened. Open the door carefully.

To interrupt a washing programme

a) Open the dishwasher door; the programme will stop.

Close the door; the programme will start from the

point in which it was interrupted.

b) Press the On/Off push button (in this case the On/Off

indicator light turns off). Press the On/Off push button

again; the programme will start from the point in

which it was interrupted.

6. End of the washing programme

The dishwasher will automatically stop.

The On/Off indicator light remains on until the On/Off

push button is depressed.

Only the On/Off integrated indicator light will remain on.

Switch off the dishwasher by pressing the On/Off push

button.

Open the door and wait a few minutes before removing

the dishes; in this way they will be cooler and the drying

will be improved.

Water may appear on the sides and door of the

dishwasher as the stainless steel will eventually become

cooler than the dishes.

Unloading the dishwasher

Hot dishes are sensitive to knocks. The dishes should

therefore be allowed to cool down before removing from

the appliance.

Empty the lower basket first and then the upper one; this

will avoid water dripping from the upper basket onto the

dishes in the lower one.

When the washing programme has finished, it is

recommended that the dishwasher is unplugged and the

water tap turned off.

Operating sequence

Fitting under a counter

(kitchen worktop or sink)

By removing the machine’s worktop, you can install it under a

close fitting sink unit or a pre-existing top, providing the

dimensions of the recess correspond to those shown in the

picture.

Proceed as follows:

Remove the machine’s worktop by unscrewing the two rear

retaining screws, pull from the front and slide out the rear

slots, lifting the worktop.

Insert the machine after adjusting height and levelling with the

adjustable feet. When inserting the machine, ensure that the

water inlet and drain hoses are not kinked or squashed.

If the dishwasher is later used as a free-standing appliance,

the original worktop must be re-mounted.

The plinth on free-standing appliances is not adjustable.

Levelling

Good levelling is essential for correct closure and sealing of

the door.

When the appliance is correctly levelled, the door will not catch

on either side of the cabinet.

If the door does not close correctly, loosen or tighten the

adjustable feet until the machine is perfectly level.

820

570 - 600

600

IN05

Dimensions Width 60 cm

Height with worktop 85 cm

Height without worktop 82 cm

Max depth 63.5 cm

Max depth with open door 118.5 cm

Electrical connection: Information on the electrical connection is given on the rating plate on the

Voltage inner edge of the dishwasher’s door.

Overall power

Fuse

Water supply pressure Minimum 50 kPa (0.5 bar)

Maximum 800 kPa (8 bar)

Capacity 12 place settings

Technical specifications

This appliance complies with the following E.E.C. Directives:

- 73/23 or 19.2.73 (Low Voltage Directive) and subsequent modifications;

- 89/336 or 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.

In the event of your appliance requiring service, or if you wish

to purchase spare parts please contact your local Service

Force Centre by telephoning:

08705 929929

Your telephone call will be automatically routed to the Service

Force Centre covering your post code area.

For the address of your local Service Force Centre and further

information about Service Force, please visit the website at

www.serviceforce.co.uk

Before calling out an engineer, please ensure you read the

details under the heading "What to do, when...".

When you contact the Service Force Centre you will need to

give the following details:

1. Your name, address and post code

2. Your telephone number

3. Clear and concise details of the fault

4. The model and serial number of the appliance (found on the

rating plate)

5. The purchase date

Please note that a valid purchase receipt or guarantee

documentation is required for in-guarantee service calls.

For Customer Service in Ireland please contact us at the

address below:

Zanussi Electrolux

Electrolux Group (Irl) Ltd

Long Mile Road

Dublin 12

Republic of Ireland

Tel: + 353 (0)1 4090751

Email: [email protected]

Customer Care

Department

For general enquiries concerning your Zanussi Electrolux

appliance or for further information on Zanussi Electrolux

products please contact our Customer Care Department by

letter or telephone at the address below or visit our website at

www.zanussi.co.uk

Customer Care Department

Zanussi Electrolux

55-77 High Street

Slough

Berkshire

SL1 1DZ

Tel: 08705 727727 (*)

*calls to this number may be recorded for training purposes

Service and Spare Parts

Standard Guarantee Conditions

We, Zanussi Electrolux, undertake that if within 12 months of

the date of purchase this ZANUSSI ELECTROLUX appliance

or any part thereof is proved to be defective by reason only of

faulty workmanship or materials, we will, at our option repair or

replace the same FREE OF CHARGE for labour, materials or

carriage on condition that:

●The appliance has been correctly installed and used only on

the electricity supply stated on the rating plate.

●The appliance has been used for normal domestic purposes

only, and in accordance with the manufacturer’s instructions.

●The appliance has not been serviced, maintained repaired,

taken apart or tampered with by any person not authorised

by us.

●All service work under this guarantee must be undertaken by

a Service Force Centre.

●Any appliance or defective part replaced shall become the

Company’s property.

●This guarantee is in addition to your statutory and other legal

rights.

Home visits are made between 8.30am and 5.30pm Monday

to Friday. Visits may be available outside these hours in which

case a premium will be charged.

Exclusions

This guarantee does not cover:

●Damage or calls resulting from transportation, improper use

or neglect, the replacement of any light bulbs or removable

parts of glass or plastic.

●Costs incurred for calls to put right an appliance which is

improperly installed or calls to appliances outside the United

Kingdom.

●Appliances found to be in use within a commercial

environment, plus those which are subject to rental

agreements.

●Products of Zanussi Electrolux manufacture which are not

marketed by Zanussi Electrolux.

European Guarantee

If you should move to another country within Europe then your

guarantee moves with you to your new home subject to the

following qualifications:

●The guarantee starts from the date you first purchased your

product.

●The guarantee is for the same period and to the same extent

for labour and parts as exists in the new country of use for

this brand or range of products.

●This guarantee relates to you and cannot be transferred to

another user.

●Your new home is within the European Community (EC) or

European Free Trade Area.

●The product is installed and used in accordance with our

instructions and is only used domestically, i.e. a normal

household.

●The product is installed taking into account regulations in

your new country.

Before you move please contact your nearest Customer Care

centre, listed below, to give them details of your new home.

They will then ensure that the local Service Organisation is

aware of your move and able to look after you and your

appliance.

France Senlis +33 (0) 344 62 29 29

Germany Nurnberg +49 (0) 800 234 7378

Italy Pordenone +39 (0) 434 39 4700

Sweden Stockholm +46 (0) 8 672 53 90

UK Slough +44 (0)1753 219897

Ireland Dublin +353 (0)1 4090751

Guarantee Conditions

Inhaltsverzeichnis

Andere Zanussi Electrolux Spülmaschine Handbücher

Zanussi Electrolux

Zanussi Electrolux DE 540 X Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZDF 601 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DE 6554 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZDT 6053 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 6171 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 6150 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZDF 501 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DE 6865 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 6280 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 4112 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DE6344 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 6152 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 6161 S Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DE 6754 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DX 6452 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DA 6142 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZDF 411 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 6066 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZDF 131 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZDF 221 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DE6444 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 4123 S Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux DA4143 Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZSF 2420 Bedienungsanleitung

Beliebte Spülmaschine Handbücher anderer Marken

Electrolux

Electrolux ESI5211LOX Bedienungsanleitung

KitchenAid

KitchenAid KUDB230B Bedienungsanleitung

Brandt

Brandt BDJ424DB Bedienungsanleitung

Asko

Asko DSD767UXXL.AU Bedienungsanleitung

Beko

Beko DFN26210W Bedienungsanleitung

NEFF

NEFF S153ITX00E Technisches Datenblatt

Midea

Midea SV 4.45 wi Bedienungsanleitung

LG LDF7932 Bedienungsanleitung

Gorenje

Gorenje GV63214 Bedienungsanleitung

Hotpoint

Hotpoint HDA1100ZWH Service-Handbuch

Blomberg

Blomberg LDFN2240W Bedienungsanleitung

AEG

AEG FFB83836PM Bedienungsanleitung

Cylinda

Cylinda DM3220RFD Bedienungsanleitung

Atag

Atag DW8214MB Bedienungsanleitung

GE GLD8000 Series Bedienungsanleitung

Siemens

Siemens SN23HI02KE Technisches Datenblatt

Omega

Omega ODW717X Bedienungsanleitung

BORETTI

BORETTI BVW-683 Bedienungsanleitung
