ZANUSSI

P R O F E S S I O N A L

GLASSWASHERS

LB-050

727044

RECT.CUTLERY HOLDER(75X180X100H)-2 COMP. 1

BASKET FOR 48 SMALL CUPS/24 CUPS-BLUE 1

BASKET FOR 18 DINNER PLATES 240MM-YELLOW 1

INCLUDED ACCESSORIES

Supply voltage 230 V, 1N, 50

Net weight - kg. 70

Noise level - dBA 58

total power 3.5

Power - kW

Boiler elements - kW 2.8

Boiler capacity - lt. 7.8

water consumption - lt./cycle 2.8

temperature during rinse - °C 80

duration - sec. 16

Hot rinse cycle

electrical elements - kW 2.8

power pump - kW 0.736

tank capacity - lt. 26

temperature -°C 55-65

Washing cycle

height 360

Cell dimensions - mm

height 840

depth 600

width 600

External dimensions - mm

Basket capacity/h 20

Duration cycles - sec. 180

N° of cycles 1

hardness - °f 7-14

temperature - °C 10

Water supply

LB050Q

727044

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION

The model detailed on this technical sheet

has square basket 500x500 mm, offering the

possibility to wash glasses and plates with a

capacity of 1.000 glasses per hour.

FUNCTIONAL AND

CONSTRUCTION

FEATURES

� 120 seconds fixed cycle.

� Glasses, cups and crockery up to a height

of 360 mm can be washed due to the ample

loading height

� Washing temperature 55° to 65°C and

rinse temperature 80° to 90°.

� Double-walled washing chamber and tank.

� Separate washing and rinsing circuits.

� Load bearing frame, front panels, tank

and filter in 304 AISI stainless steel. Wash

arms and jets in polypropylene.

� The washing and rinsing arms rotate.

� This model incorporates a rinse aid

dispenser for connection to an external

container.

� Basket(s) for glasses, plus the insert rack

for cutlery, electric cable and the hose for

water connection supplied as standard.

� All models comply with the standards of

the main international approval bodies and

are H marked.

* Declared actual cycle duration times can extend

when water supply temperature is lower than indicated

EAAA3 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

RECT.CUTLERY HOLDER(75X180X100H)-2 COMP. 860155

BASKET FOR 48 SMALL CUPS/24 CUPS-BLUE 867007

BASKET FOR 18 DINNER PLATES 240MM-YELLOW 867002

LB050Q

727044

ACCESSORIES MODELS

OPTIONAL ACCESSORIES

I - Electrical connection 230 V, 1N, 50

C - Water drain 28mm

B - Cold water inlet G 3/4"

A - Hot water inlet

LB050Q

727044

LEGEND

727044

311

1 POWER SUPPLY

3 OUTLET

2 INLET

727038/39/40

727041/42/43

727044

727036

727037

727035

727034

MODEL

727036

727037

727038/39/40

727041/42/43

727044

727035

727034

SIDE A

165

190

240

315

255

SIDE B SIDE C SIDE D SIDE E SIDE F

200

230

305

375

300

257

282

265

295

365

270

200

110
