Zanussi ZOF3220 Bedienungsanleitung

Electric Oven

User’s Manual

Please read this manual carefully before use and keep it properly.

The pictures are for reference only. Please refer to the actual product.

Model：ZOF3220

Important safety instructions

These warnings are provided for safety reasons. Please read

carefully before installing or using this product.

This product is for home users only and must not be used for any

other purpose, such as in non-domestic or commercial

environments.

- The temperature of the accessible surface will be very high when

the product is working.

- You must pay attention to safety to get the best results.

- This product must use the voltage marked on the nameplate of

the product. Incorrect voltage will invalidate the warranty.

- Be sure to disconnect the power supply when the product is not

in use.

- This product can’t be operated with external timer or remote

control system.

- Do not expose this product to rain or moisture.

- This product can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

- Children younger than 8 years old are not allowed to use this

product.

- Cleaning and user maintenance shall not be made by children

unless they are over 8 years old and are supervised.

- This product is for indoor use only.

- Please keep the product and its power cord out of the reach of

children under 8 years old.

- Do not use this product for other purposes.

- To prevent electric shock, do not immerse the power cord, plug

or product in water or other liquids.

Please read all instructions carefully before using your electric

oven for the first time.

- Unplug the plug from the socket when the product is not in use

and before cleaning. Clean it after the temperature drops to room

temperature.

- Do not operate when the power cord or plug is damaged, the

product is malfunctioning, or the product is damaged in any way.

Please consult the salesperson of the retail store where you

purchased the product for relevant advice.

- Do not allow wires to hang on the product surface or contact hot

surfaces.

- Do not place this product on or near hot gas or electric burner, or

in heating furnace.

- Be sure to connect the plug to the power cord.

- To disconnect the power, pull the plug from the wall socket.

- Do not disconnect the power source by pulling the power cord.

Hold the plug and pull it out.

- Do not immerse the product, power cord or plug in water.

- This product is equipped with a short-circuit power cord to reduce

the risk of tripping.

- Do not put items wrapped in aluminum foil into the oven.

- Before putting the bread in the oven, remove all protective packaging.

- If the power cord is damaged, it must be replaced by the

manufacturer, its service agent or similar personnel to avoid danger.

- Do not use this product in a bathtub or sink or any container that

contains water or liquid.

- If the product falls into water, do not touch the product. Before

taking it out, disconnect the power supply and drain the water.

Do not use the product again until it is checked by a qualified

service agent.

- The back surface of the product should be placed close to the wall.

- For detailed information on how to clean food-contact surfaces,

please refer to the “Cleaning” section.

The surface of the product tends to become hot during use.

Electric Oven

Electric

Oven

• Use the electric oven on a heat-insulated surface and keep a distance of at least

10-15cm around the electric oven.

• The electric oven should be placed in a dry environment and should not be used

outdoors.

• In order to avoid oil fumes from contaminating furniture or causing fires, keep a certain

distance from the product to the walls and cabinets.

• It is strictly forbidden to use the electric oven near flammable materials or heat

sources. Keep away from curtains and the like to prevent fire.

Precautions for placement

Open spaceFront

> 10cm

Wall

> 20cm

Top

Left and

right

There are safety barriers on the back of the oven

to prevent the oven from contacting walls and

other objects and to maintain a safe distance.

Note: hot surfaces

Top, back, and glass door

Back

ZOF3220

Quick Start Guide

Please read this manual carefully before use and keep it properly.

Product Overview

Note

• As the product is subject to upgrade, please refer to the actual product if

it has any difference from the picture below

• Please refer to the safety distances marked in the picture to place the

product

• When using the rotating grill function (chicken), the lower tube does not

work. Please put the oil pan on the lower heating tube to collect the oil;

when using functions that the lower tube works, do not put the oil pan

directly on the heating tube

• When picking up the chip tray assembly, please use the plastic handle.

Do not touch the metal part in order to prevent burns

Note: hot surfaces

Top, back, and glass door

Left and right >10cm Back >10cm

Top >20cm

Bakeware

Pick-up clamp Rotating fork Pick-up bracket

Chip tray assembly

(in the body)

Grill Oil pan

Control panel introduction

Upper tube

temperature

adjustment knob

When heating food, please turn to more

than 70°C

When heating food, please turn to

more than 70°C

During use, the working status indicator is

always on

The indicator light is off when the task is over

If the timer is <10 minutes, turn the time

knob to >10 minutes, and then turn the

time knob back to the desired time

position

Function

selection knob

Lower tube

temperature

adjustment knob

Working status

indicator

Time adjustment

knob

Lower tube works

Upper tube works

The upper and lower tubes work

simultaneously

Hot air convection

Rotating grill

Low temperature fermentation

溫度

時間(分)

電源

功能

關閉

连续

Upper Temp.

Off

Lower Temp.

Stay On

Off

ZOF3220

First use

Note

Method of operation

A layer of anti-corrosion coating is applied on the heating tube. It is normal

if there is strange smell or smoke when it is used for the first time.

It needs to be operated for 15 minutes for the first time to remove the

anti-corrosion protective coating in the heating tube and cavity

1. With the power off, wipe

the inside of the oven

with a damp cloth; do not

wipe the heating tube

2. Put the baking tray and

grill into the oven and

plug in the power

supply

3. Use the upper and lower tube

function, adjust the temperature

to the highest and operate for

15 minutes

4. Unplug the power supply,

and use it normally after

complete heat dissipation

關閉

Off

Operation flow

Note

• When the [Stay On] position is selected, the electric oven is always on,

manually turn the time knob back to the [OFF] position, or else the oven

will continue to work, which may cause a fire

• The product of the enamel furnace cavity may make a slight noise during

use, which is normal

• When the fermentation function is selected, turn the time knob to start

working. The temperature knob doesn’t have adjustment function

1. Insert the power supply,

220V AC

2. Select the function

3. Adjust the temperature 4. Adjust the time and start

working

and the working status indicator turns on. To stop the work, you need to

關閉

Off

關閉

连续

Stay On

Off
