Zenaji Aeon A48-40-01 Bedienungsanleitung
Aeon Battery
A48-40-01
A48-40-02
Installation Manual
Pty. Ltd.
Aeon Battery Installation Manual V1.2 JAN 2020 | pg. 3
• Information within this guide is accurate at the time of
publication and is subject to change without notice.
• Illustrations and images are only for the purpose of
assisting with installation and system conguration and
for illustration purposes only.
• Read this documentation in its entirety before
installation.
• Retain this document for reference purposes.
pg. 4 | Zenaji Australia Pty Ltd
Contents
1 Information about this document......................................................................6
1.1 Target group...............................................................................................6
1.2 Designation..................................................................................................6
1.3 Glossary of Terms........................................................................................6
1.4 TermsandConditions..................................................................................7
1.4.1 Installation.......................................................................................7
1.4.2 Standards.........................................................................................7
1.4.3 VoltageLimits...................................................................................7
2 Safety......................................................................................................................8
2.1 Intended use...............................................................................................8
2.2 Installer Requirements...............................................................................8
2.3 Safety information......................................................................................8
2.3.1 General Safety Precautions...........................................................8
2.3.2 Battery Handling.............................................................................9
2.3.3 Hazards............................................................................................9
2.3.4 Emergency Response...................................................................10
3 Product Overview................................................................................................11
3.1 Dimensions and Weight...........................................................................11
3.2 Technical information..............................................................................13
3.3 Features.....................................................................................................14
3.3.1 Circuit breaker..............................................................................15
3.3.2 Connection Cable.........................................................................16
3.3.3 Mounting Points...........................................................................16
3.4 Additional Devices and Accessories.......................................................17
3.4.1 Additional Devices........................................................................17
3.4.2 Mounting Accessories..................................................................17
Aeon Battery Installation Manual V1.2 JAN 2020 | pg. 5
4 Installation...........................................................................................................18
4.1 Ambient Conditions..................................................................................18
4.2 Minimum distances..................................................................................18
4.3 Mounting the Battery...............................................................................19
4.4 Connecting and commissioning the battery.........................................21
4.4.1 Inverter Settings.................. ........................................................21
4.4.2 Connecting a single battery........................................................21
4.4.3 Multiple Batteries.........................................................................21
4.4.4 Adding a battery to an existing Zenaji battery system............21
4.5 Battery Registration..................................................................................22
5 Uninstallation & Return.....................................................................................23
5.1 Uninstallation for Repair or Return........................................................23
5.2 Disposal.....................................................................................................23
6 Troubleshooting.................................................................................................24
7 Commissioning Report......................................................................................26
7.1 Commissioning Details.............................................................................27
7.2 Customer Details.......................................................................................28
7.3 Qualied Personnel Details......................................................................28
7.4 Installer Details..........................................................................................29
7.5 Qualied Personnel Agreement...............................................................29
8 Contact................................................................................................................30
pg. 6 | Zenaji Australia Pty Ltd
1
INFO
1 Information about this document
1.1 Target group
This document is intended for qualied personnel and any action described in this document
must be carried out by qualied personnel.
1.2 Designation
This document designated for the following Zenaji Products.
A48-40-01
A48-40-02
1.3 Glossary of Terms
Read this summary of terms before reading the remainder of the manual.
Power Equipment: This refers to an electronic device an Aeon battery can be connected to
that can charge and/or discharge the battery. Most commonly this will be a Battery Charger/
Inverter or Hybrid Solar Inverter used with a solar photovoltaic power system for a house.
Battery: In this document refers to one 1.93kWh Aeon Battery.
Battery System: A battery or group of batteries connected to a single piece of power
equipment or multiple power equipment that is connected together.
Installed Battery: A battery that is part of a battery system, already installed, commissioned
and in use.
Additional Battery: A battery that is to be added to a previously commissioned battery
System.
Commission: To begin the use of a battery system, after installing the batteries and the
circuit breakers have been switched to ON.
Qualied Personnel: Personnel who have completed the required training and are certied
to undertake electrical works in their state.
Load weight: The total weight of a battery system on the supporting wall.
Self-managed battery: A battery which contains its own cell balancing and protection
equipment.
LTO: Lithium Titanate, the cell chemistry used in Zenaji Aeon Batteries
Aeon Battery Installation Manual V1.2 JAN 2020 | pg. 7
1
INFO
1.4 Terms & Conditions
When installing and operating the Aeon battery the following Terms & Conditions must be
met. Failure to comply will void any warranty provided by Zenaji.
1.4.1 Installation
Installation must be carried out by qualied personnel.
1.4.2 Standards
The Aeon battery must be installed according to current local authority standards. In
Australia and New Zealand these include but are not exclusive to:
AS/NZS 5139:2019
AS/NZS 3000
1.4.3 Voltage & Current Limits
The Power Equipment which charges and discharges the Aeon Battery must not bring the
voltage of the battery above 55.5V or below 42V. The maximum allowable continuous current
should not be set above 50A per battery connected to the Power Equipment.
pg. 8 | Zenaji Australia Pty Ltd
2
SAFETY
2 Safety
2.1 Intended use
The Aeon Battery is a nominal 48V LTO self-managed battery intended for use with power
equipment to store and provide electrical energy. Improper use or handling poses risk of
death or injury to the user or third parties as well as damage to the battery or other items of
value, especially power equipment the battery is connected to.
The following must be observed to comply with use of this product:
• The battery must be installed according to the installation instructions.
• The battery must be installed by qualied personnel.
• The battery must be used in a suitable location.
Failure to comply to these conditions or warranty conditions invalidates any warranty claims.
2.2 Installer Requirements
The battery must be installed by qualied personnel. Qualied personnel must meet the
following criteria.
• The company for which the personnel works for must be certied by Zenaji to use
Zenaji products.
• The personnel must be a qualied electrician and considered competent and
registered to work to the AU/NZS 3000:2018 safety standard.
• The personnel must have successfully completed Zenaji certication training for this
product.
2.3 Safety information
Installers are responsible for reading and understanding this document before installation
2.3.1 General Safety Precautions
• Over-voltages or incorrect wiring can damage the battery or connected equipment.
• Avoid installing the battery in locations where ammable materials are present.
• Do not install in locations where explosive chemicals or gasses are present.
• Installation must be carried out by Qualied Personnel.
• Battery is not user serviceable.
• Inspect battery for any damage prior to installation.
Aeon Battery Installation Manual V1.2 JAN 2020 | pg. 9
2
SAFETY
2.3.2 Battery Handling
• Ensure circuit breaker on the base of the battery is set to OFF when handling,
transporting, connecting or disconnecting the battery.
• Two person lift, 36kg (39kg net packaged), ensure any lifting calculations are carried
out as according to state regulations.
• Do not expose battery to open ame.
• Do not expose battery to temperatures over 60°C
• Do not damage the unit in any ways physical such as crushing, dropping, piercing
with a sharp object, impacting. This may cause leakage of electrolyte or short circuit
with the risk of re.
• Do not connect positive and negative wires to each other causing a short circuit.
• Do not charge or discharge damaged battery.
• Do not place the battery with the connection cable on the ground.
• Unqualied personnel are not to disconnect, disassemble or repair the battery.
Services must be made by Qualied Personnel only.
• Ensure Connection cables ends are not exposed prior to nal connection to power
equipment.
• Keep out of reach of children and animals
• All wiring must be protected from intrusion and cutting.
• Store the battery in a dry place.
• Ensure temperature is maintained between -5°C to 35°C when handling or
transporting the battery (recommended 20°C to 30°C).
• No foreign object is to be placed on top of the battery.
• Only use battery with Zenaji authorised power equipment.
• Do not immerse in water.
2.3.3 Hazards
Leaking electrolyte and gases can cause irritation and harm.
• Skin: On contact, the electrolyte solution contained in the battery causes irritation
to skin. Symptoms include irritation and burns.
• Eyes: On contact, the electrolyte solution contained in the battery or gases released
due to battery damage cause irritation to ocular tissue and skin around the eyes.
Symptoms include irritation, redness, tearing and burns. The electrolyte is corrosive
to all ocular tissues.
• Inhalation: Gases due to high heat or abundance of leaking batteries cause burns
of the respiratory system. Symptoms include coughing, wheezing, and shortness of
breath.
• Ingestion: The ingestion of the battery is harmful. Content of the battery can cause
serious chemical burns to the mouth, oesophagus and gastrointestinal tract.
pg. 10 | Zenaji Australia Pty Ltd
2
SAFETY
2.3.4 Emergency Response
If exposed to leaking electrolyte from ruptured or leaking battery the following actions are
recommended
• Skin Contact: If the battery is leaking and the contained material contacts skin,
ush with copious amounts of clear water for at least 15 minutes.
• Eye Contact: If the battery is leaking and the contained material contacts eyes,
ush with copious amounts of clear water for at least 15 minutes. Seek medical
attention immediately.
• Inhalation: If the battery is leaking, leave the contaminated area to fresh air. If
irritation persists, seek medical attention.
• Ingestion: If the battery is leaking and the contained material is ingested, rinse
the mouth and surrounding area with clear water at once. Seek medical Attention
immediately.
Fire Fighting Measures
• If re occurs when charging or discharging the batteries, if it is safe to do so, shut
o the power to the battery.
• Extinguishing Media – Dry chemical type extinguishers are the most eective means
to extinguish a battery re. A CO2 extinguisher will also work eectively.
• Fire Fighting Procedures – Use a positive pressure self-contained breathing
apparatus batteries are involve in a re. Full protective clothing is necessary. During
water application, caution is advised as burning pieces of ammable particles may
be ejected from the re.
Accidental release
• In the event of rupture and leakage, collect all released material that are not
burning or hot in an appropriate waste disposal container while wearing proper
protective equipment and ventilate the area. Dispose according to local regulations.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Zenaji Kamerazubehör Handbücher
