Zephyr Duo Is. ADL-E42ASX Bedienungsanleitung

ARC COLLECTION

DUOISLAND

Ideal for those who welcome the warmth of wood into their contemporary home,

Duo is an island range hood that marries natural wood with the cool factor of stainless

steel. Envision a steel structure topped with poplar wood in a charcoal or wenge ﬁnish

to complement your cabinetry. Or you can perfectly match your kitchen’s modern

stainless surroundings with the low-proﬁle steel-only option. Dual pairs of halogen

lights work together to underscore the cantilevered design, while optional duct cover

extensions can accommodate contemporary ceilings of up to 12 feet.

RF Remote Control

SIZE

ADL-M90ASX

ADL-E42ASX

36”

42”

35 7/16”

42”

Stainless Steel

COLOR NET WIDTH

ARC COLLECTION

1.888.880.VENT

www.zephyronline.com nov08.0101

Zephyr Corporation

2277 Harbor Bay Parkway

Alameda, CA 94502

MODEL

ADL-M90ASX

ADL-E42ASX

FEATURES

Controls

Speed Levels

Auto Delay-Off

CleanAir Function

Remote Control

Lighting

Tri-Level Lighting

Filters

Recirculating

Duct Cover Extension

*PERFORMANCE

Internal Blower - CBI-290A

Internal Blower - CBI-600A

In-Line Blower - PBN-1000A

External Blower - CBE-1000

AC INPUT

**AC POWER

Hood Only

MOUNTING HEIGHTS

Height from the cooking surface

HOOD HEIGHTS

Standard

Minimum Ducted

Minimum Recirculating

Maximum

Short Kit - Z1C-00LL

Minimum Ducted

Minimum Recirculating

Maximum

Long Kit - Z1C-01LL

Minimum Ducted

Minimum Recirculating

Maximum

DUCT SPECIFICATIONS

Vertical - Internal

Vertical - In-Line/External

Horizontal

OPTIONAL ACCESSORIES

Recirculating Kit

Duct Cover Extension Kit, Short

(8 1/2’–9 1/2’ ceiling)

Duct Cover Extension Kit, Long

(9 1/2’–12’ ceiling)

WOOD TRIM

Charcoal - 1 5/8”, 90cm

Charcoal - 1 5/8”, 42”

Wenge (brown) - 1 5/8”, 90cm

Wenge (brown) - 1 5/8”, 42”

36”

42”

Memory Touch Glass

Yes

Yes, RF

Halogen, 20W x 4

Yes

Decorative Mesh x 3

Yes

290 CFM, 3.2 Sones Max.

600 CFM, 6 Sones Max.

1000 CFM, Sones NA

120V - 60Hz

Max. 80W, 0.66 Amps

Min. 24”–Max. 36”

30”

34”

37 1/2”

49”

53 1/2”

79”

6”

10” to 8”***

ZRC-00LL

Z1C-00LL

Z1C-01LL

AUW-00CH

AUW-01CH

AUW-00BR

AUW-01BR

D U O ISLAND

* Requires purchase of Zephyr blower, sold separately. **AC power listed above is for hood

with lights only. See blower specs on our website for more AC power details. ***10” round

duct connects to external and in-line blower. Must transition from 10” to 8” before duct

passes through ceiling. A 10” to 8” adapter is included with the external and in-line blowers.

Top

(blower housing and ceiling bracket)

Front

Side

6”

“8

elec. k/o

ext. blower

connection

9 1/4”

5/8”

6 11/16”

7 1/2”

11 3/16”

blower

housing

min. ducted - 30”

min. recirc. - 30“

max. - 34”

12 15/16”

11 7/8”

35 7/16” or 42”

23 5/8”

3 1/8”
