ASSEMBLY
INSTRUCTIONS ZP19024
WWW.ZIPPITY-OUTDOOR.COM
VER. 012021
ZP19024
ASSEMBLY
INSTRUCTIONS
6 HRS
Approximate assembly and installaon me
Want to see a video on how to
assemble this product?
Scan the QR code
OCEANSIDE
OUTDOOR VINYL
SHOWER KIT
WWW.ZIPPITY-OUTDOOR.COM
2
ASSEMBLY
INSTRUCTIONS
ZP19024
kCheck the inside of the larger pieces in your box for other
materials packed inside.
kWhen assembling components, place on a non-abrasive
surface (i.e. shipping box) to avoid scratching.
k
unobstructed assembling.
kYou should not need to use excessive force when assembling
components.
VISIT OUR WEBSITE FIRST,
SO WE CAN HELP YOU RIGHT AWAY!
Although great care has been taken to ensure proper packaging
and handling of this product, occasionally problems occur. If you
our website to order replacement parts. If you experience any
further trouble with your product, please contact our customer
service department.
nychgroup.com/parts
support@zippity-outdoor.com
704-892-5222 /877-234-6196
Customer service agents are available to take calls weekdays from 9am-
5pm EST. If you call outside of business hours, please leave a voicemail.
To help you quickly and accurately, please have reference item
number ZP19024
found on the next page. It is helpful if you can provide the batch
lot which is a stamped number inside the box.
this product, we are happy to assist you with the process, so
please give us a call at 704-892-5222 / 877-234-6196.
If for some reason you need to return this product, please
return the product, you will need to iniate the return from the
company you originally purchased from.
GENERAL
INFORMATION
MISSING
OR
DAMAGED
PARTS?
NEED
ASSEMBLY
HELP?
NEED TO
RETURN?
IMPORTANT
WWW.ZIPPITY-OUTDOOR.COM
3
ASSEMBLY
INSTRUCTIONS ZP19024
STEP 1:
LAY OUT MATERIALS
Post A (1)
Post B (1)
Post C (1)
Post D (1)
Rail Bracket (12)
Post Cap (4) Decorave
End Cap (4)
1¼” Steel
Screw (46)
¾” Steel
Screw
Shade Slat (9) Vinyl Weld
Glue (1)
O
P
N
MA
E
I
B
F
J
C
G
K
D
H
L
Privacy Board (1)
Horizontal Rail (4)
Beam (2)
U-Channel (6)
Shower Rod (2)
A
A
B
B
C
C
D
D
WWW.ZIPPITY-OUTDOOR.COM
4
ASSEMBLY
INSTRUCTIONS
ZP19024
NOT INCLUDED WITH PURCHASE:
Sold Separately
For wood or concrete
surface mounng
For in-ground mounng Only needed if installed
on concrete
Only needed if installed
on wood
Only needed if installed
in ground
Sold Separately
(ZP19011) Zippity
Surface Mount
2-pack (2)
(ZP19012)
Zippity Post
Extension (1)
¼” x 3” Concrete
Wedge Anchor (16)
¼” x 4” Hex Head
Bolt w/ Nut and
Washer (16)
80 lb Concrete
Mix (2)
STEP 2:
INSTALLING MOUNTING ACCESSORIES
Concrete or wood surface mounng: Insert (4) Surface Mounts
(ZP19011)
Mounts will be secured in the next step.
In-ground installaon: Insert (4) Post Extensions (ZP19012) into
secured in the next step.
STEP 2.1A
STEP 2.1B
WWW.ZIPPITY-OUTDOOR.COM
5
ASSEMBLY
INSTRUCTIONS ZP19024
Note:z
STEP 3:
INSTALL BRACKETS
STEP 3.1
STEP 3.2
Lay out Post A (A)(M) with the
(O).
(B), C (C), and D (D).
Ensure that surface mount
(or post extension) is fully
installed prior to securing
brackets to post A.
A
B
C
D
O
M
WWW.ZIPPITY-OUTDOOR.COM
6
ASSEMBLY
INSTRUCTIONS
ZP19024
(H) between
the two Rail Brackets. Ensure the
groove of the U-Channel is centered
Steel Screws (N) through the pre-drilled
holes in the U-Channel.
(K) into Rail Brackets with the
Repeat step 4.1 for the rest of
the Posts.
STEP 4:
INSTALL
STEP 4.1
STEP 5.1
STEP 4.2
STEP 5:
ASSEMBLE SIDE PANELS
H
N
Note: Push the Horizontal
Rail Bracket. The screw head
but with enough force, the
Horizontal Rail should pop
into the Rail Bracket.
Note: Angle the screw
either slightly down or
internal rail rib.
Post B
Post A
K
WWW.ZIPPITY-OUTDOOR.COM
7
ASSEMBLY
INSTRUCTIONS ZP19024
(G) into
Horizontal Rail then insert the Privacy
Board into the U-Channel. Angle the
Privacy Board as illustrated. This will
make it easier to get the Privacy Board
into the U-Channel. Insert the last
Privacy Board in the same fashion.
Repeat steps 5.1 through 5.4 to assemble the other wall panel.
Slide the middle Privacy Board in
STEP 5.2 STEP 5.3
Note: Make sure
the Horizontal Rail
is inserted fully
over the Privacy
Boards and rests
inside the Rail
Brackets.
Tip:
to slip together more easily if necessary.
G
STEP 5.4
WWW.ZIPPITY-OUTDOOR.COM
8
ASSEMBLY
INSTRUCTIONS
ZP19024
STEP 6:
INSTALL SHOWER RODS AND BEAMS
(E) onto each
Post as shown.
Slide (2) Shower Rods (L) into the
they hit the back wall of the Posts.
STEP 7.1
STEP 6.1
STEP 7:
INSTALL POST CAPS
Slide (2) Beams (I) into the larger routed holes in the
Posts. Align the pre-drilled holes in the Beams and
STEP 6.2
Apply a small amount of Vinyl Weld Glue (P) to the
(F)
STEP 7.2
L
E
I
Align
side of Beam with
holes faces up
F
P
WWW.ZIPPITY-OUTDOOR.COM
9
ASSEMBLY
INSTRUCTIONS ZP19024
9” diameter
36” deep
Hammer drill will be needed for this step
STEP 8:
SQUARE AND SECURE POSTS
Square the unit in the space where you plan to install your shower. The diagonal distance
between your posts must be equal for your unit to be square.
STEP 8.1
Surface Mount install:
concrete wedge anchors (NOT INCLUDED),
or similar sized lag screws (NOT INCLUDED) if
STEP 8.2A
Post Extension install: Mark the post
INCLUDED). Use support blocks to hold the
unit while the concrete cures.
STEP 8.2B
y
x
Note: If your concrete is not level, insert
galvanized steel washers under the lower
side of the Surface Mount unl it is level.
Then, secure with wedge anchors.
WWW.ZIPPITY-OUTDOOR.COM
10
ASSEMBLY
INSTRUCTIONS
ZP19024
(J)
Repeat this process for all 9 Shade Slats.
STEP 9:
INSTALL SHADE SLATS
STEP 9.1
STEP 9.2
