The Zoom CableModem Model 5031 has a USB interface to support a

wide range of operating systems, and applications. The modem is easily

installed using the software provided. In addition, Zoom's unique Cable

Modem Monitor Software provides user-friendly troubleshooting if

problems are encountered on the network.

The Model 5031 has been CableLabs®certified and is approved as fully

compliant with the Data Over Cable System Interface Specification 1.0

(DOCSIS 1.0), ensuring interoperability and a high level of performance

with industry-standard cable systems. It is software upgradeable to

DOCSIS 1.1, with the necessary hardware, software and Digital Certifi-

cates built into the modem to support 1.1 enhancements. Data over

cable service providers are supported further with remote and local

diagnostic capability, remote firmware downloads and SNMP support.

The cable modem supports up to fifteen PCs and a data rate of up to 42

Mbps downstream from the service provider and 10.2 Mbps upstream.

The package includes ZoneLabs' ZoneAlarm™personal firewall software,

AdSubtract™ ad blocker/cookie filter software, a user's manual and

Ethernet cable.

Model 5031

■Access the Internet at speeds

up to 100 times faster than

dial-up modems

■Provides an always-on Internet

connection for instant access

■Eliminates Internet traffic on

your phone line

■DOCSIS 1.0 tested and certi-

fied for operation with industry

-standard cable networks

■Can be upgraded to DOCSIS

1.1 automatically by your cable

service provider

■Easy-to-read status display

■Stylish, design with vertical and

horizontal options

■Easy installation with USB

support for Windows XP, Me,

2000 and 98

■Unique Zoom Cable Modem

Monitor provides network

troubleshooting software

■Includes ZoneAlarm™ personal

firewall and AdSubtract™ad

blocker software

■Includes USB cable

External Cable Modem

with USB Connection

Zoom®CableModem™

Cable Modem Operating ParametersDownstream Upstream

Frequency 91 to 857 MHz 5 to 42 MHz

Data Rate Up to 42 Mbps Up to 10.2 Mbps

Modulation 64QAM / 256 QAM QPSK / 16QAM

Error Correction Reed-Solomon decoding Reed-Solomon encoding

(ITU J.38 Annex B)

Channel Bandwidth 6 MHz 200/400/800/1600/3200 KHz

Signal Level -15 to +15 dBmV +8 t0 +58 dBmV (QPSK)

+8 to +55 dBmV (16QAM)

Features

•Easy installation USB connection

•Support for Windows 98, 2000, Me and

XP operatinng systems

•CableLabs Certified

•56 bit encryption provides privacy

and security

•Highly integrated design for

superior reliability

External Cable Modem

with USB Connection

Model 5031

Technical Specifications

•Experienced technical support

for both consumers and service

providers

•SNMP and DOCSIS MIB support

allowing remote software upgrades

•Includes encrypted security key for

DOCSIS 1.1 field upgrades

•Advanced diagnostic software and

firmware

•Backed by over twenty years of

experience in computer

communications

Operating and Environmental Parameters

Power Requirements 12V, 600mA nominal

Power Consumption 7W nominal

Operating Temperature 0˚ to 40˚ C

Dimensions 8.9”” (22.6 cm) Width x 1.6” (4.1 cm) Height x 6.5” (16.5 cm) Depth

Weight 1.8 lb (0.81 Kg)

Regulatory FCC Part 15, Class B; UL, C-UL; EN 55022, Class B; EN 55024; EN 60950

System Requirements • DOCSIS cable data service and coaxial cable connection

• Computer with USB port

Supplied with • 4’ USB Cable

• Power Supply and Cord (110VAC / 60 Hz or 230VAC / 50 Hz)

• User’s Manual

• CD-ROM with software including ZoneLabs ZoneAlarm personal firewall,

AdSubtract ad blocker / cookie filter, and Zoom Cable Modem Monitor installation

and troubleshooting software tool

International

Headquarters

Zoom Telephonics, Inc.

207 South Street

Boston, MA 02111

USA

Tel: 617 423-1072

Fax: 617 423-3923

email: [email protected]

www.zoom.com

Nasdaq: ZOOM

European

Sales/Support

Zoom/Hayes

430 Frimley Business Park

Frimley, Camberley

Surrey, GU16 5SG UK

Tel: +44 (0) 1276 704400

Fax +44 (0) 1276 704500

Made in U.S.A.

Zoom and Zoom CableModem are registered trademarks of Zoom Telephonics, Inc.

Windows 98, Windows Me, and Windows 2000 are registered trademarks of Microsoft Corporation.

All other registered trademarks and trademarks used herein are the property of their respective holders.

5031 010002
