Zte Q200 Bedienungsanleitung

Q200

CDMA 1X Digital Mobile Phone

User Guide

ZTE CORPORATION

NO. 55, Hi-tech Road South, ShenZhen, P.R.China

Postcode: 518057

Tel: +86-755-26779999

URL: http://www.zte.com.cn

E-mail: mobile@zte.com.cn

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by

any means, electronic or mechanical, including photocopying and microfilm, without the prior

written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print

errors or update specifications without prior notice.

Version No. : R1.0

Edition Time : June.2011

Manual No. :

C h a p t e r 1

Phone Overview

C h a p t e r 2

Key Functions

Key Function Description

•Make or answer a call.

•Press Send key in standby mode to enter Call History list.

•End an active call or reject a call.

•Long press to Power on/Power off.

•Exit from any interface to standby mode.

•Enter main Menu in standby mode.

•Switch to the options of left bottom submenu.

•Enter Radio in standby mode.

•Switch to the options of right bottom submenu.

•Cancel the current operation; go back to the previous window.

•Confirm the commands and options selected.

Up/Down key

•Scroll the cursor up and down.

•Used as selection key to scroll cursor up and down for keying in commands and selecting

options shown on the display.

•In standby mode, press Up key or Down key to active pre-set functions.

•Used as direction key in games.

•Adjust volume when listening radio or in conversation.

Left/Right key

•Scroll the cursor left and right.

•Used as selection key to scroll cursor left and right for keying in commands and selecting

options shown on the display.

•In standby mode, press Left key or Right key to active pre-set functions.

•Used as direction key in games.

•Select the stored radio channel when listening radio.

~ Use to enter characters, numbers and symbols.

Key Function Description

Press to enter the message menu in standby mode.

Press to display all stored contacts in standby mode.

Press to erase the characters.

•Press Alt key to switch superscript and subscript.

•Press Alt key twice to keep the keys to input superscript numbers or symbols. Press Alt key

again to back to normal status.

Press Enter key to enter the next line when entering text.

•Use to enter space in editing text.

•Long press to lock the keyboard in standby mode.

•Press Shift key to switch between uppercase and lowercase.

•Press Shift key once to enter one uppercase character; press twice to lock uppercase status; and

press the shift key again to back to normal status.

In standby mode, press MP3 Key to play music.

•Press and hold Silence key to active/deactivate vibrate mode in standby mode.

•Press to open the symbols panel when entering text.

C h a p t e r 3

Open the Back Cover

Remove the back cover as shown below.

ZTE-C Q200 User Guide

Confidential and Proprietary Information of ZTE CORPORATION 5

C h a p t e r 4

Remove and Install the Battery

The attached Li-ion battery along with the phone can be used after unpacking. For the first three times,

please use up the power and charge it fully for a new battery to perform well.

Remove the Battery

Put finger on the finger grips, and then lift up the battery to remove the battery.

Install the Battery

1. Install the battery as shown below. Replace the battery into the battery slot, to be noted that the side of

the battery firstly inserted.

2. Put the back cover of the phone flatly upon the body of phone. Direct the back cover towards the

locking catches on the each side of the phone and press the back cover of the phone to lock the cover

into its place.

ZTE-C Q200 User Guide

Confidential and Proprietary Information of ZTE CORPORATION 7

C h a p t e r 5

Insert and Remove the UIM card

Insert the UIM Card

1. Power off the phone, remove the battery and other external power.

2. Insert the UIM card into UIM card slot, as shown in the picture.

Remove the UIM Card

1. Power off the phone, remove the battery and other external power.

2. Remove the UIM card from the UIM card slot, as shown in the picture.

C h a p t e r 6

Charging Your Phone

1. Connect the charger to the phone as shown below.

2. Connect the charger to a standard wall AC socket.

3. When the charging animation on the screen stops, the charging is completed. The charging takes usually

up to 2～3 hours. During charging, it is a normal phenomenon that the battery, phone and charger may

get hot.

4. After the completion of charging, disconnect the charger from the phone and AC socket.
