Zte T230 Bedienungsanleitung

ZTE T230

Quick Start Guide

See ztemobiles.com.au for more help

Follow ZTE Australia on Facebook,

Google+ Twitter and Instagram

V1.0 © ZTE Sept 2015

Getting to Know Your Phone

Install the SIM Card(s)

For Dual SIMs the 3G SIM is Standard or 2FF size.

The 2G SIM is micro or 3FF size.

Remove the back cover.

1. Insert your SIM card into the slot as shown and

push it fully into the SIM slot.

2. Replace the battery and back cover.

GSM

WCDMA

Key Functions

Key

Function

Power Key

•

Press to wake up your phone.

•

Press and hold to select Silent,

Vibrate or Flight mode, or to

power on and off.

•

Press to switch your phone to

Sleep mode.

Back

•

Touch to go to the previous

screen.

Home

•

Touch to return to the Home

Screen from any application or

screen.

•

Press and hold for Google

Options

•

Press for Options on the current

screen

•

Press and hold to view recent

apps.

Volume Keys

•

Press or hold to turn the volume

up or down.

Apps

•

Access the device Applications

and Widgets menu.

LEDStatus indicator

Red

Less than 10% battery charge

Orange

Between 10 – 70% charge

Green

More than 70% charge

LED Flashing

Message, Missed Call or

Notification. The colour

represents the charge level

shown above.

Install a microSD Card (optional)

A microSD card can be installed or removed while

the phone is turned on. You need to unmount the

microSD card before removing it. The device

supports microSD(HC) cards up to 32GB.

1. Remove the back cover.

2. Hold your microSD card with the metal contacts

facing down and slide it in.

3. Press the cover gently to click back into place.

Charge the Battery

WARNING! Use only ZTE approved chargers and

cables. The use of unapproved accessories could

damage your phone and battery or present a fire

risk.

1. Check the orientation of the charging jack and

gently insert into the handset charging port.

2. Connect the charger to a standard AC wall

outlet.

3. Disconnect the charger when the battery is fully

charged.

4. Battery life will improve after a few charge

cycles.

Power Your Phone On or Off

●Hold the Power Key to switch on your phone.

●To switch it off, hold the Power Key to view the

options. Touch Power off, and then touch OK.

Wake Up Your Phone

1. Press the Power Key to activate your screen

display.

2. Press and hold the lock icon to unlock the

screen.

NOTE: If you have set an ‘unlock pattern’, or a

PIN/password for your phone, you’ll need to draw

the pattern or enter the PIN/password to unlock

your screen.

Restarting Your Phone

If the screen freezes or takes too long to respond,

remove the battery. Press the power key to restart

your device.

First time power up, Google Account

It is recommended that you create or log in with a

Google account. Creating an account gives you

access to the Google Play Store to update,

download and manage your applications, and can

protect your account by backing up Contacts and

other data. If you lock your device and forget your

unlock code (PIN or pattern) then you can unlock

the device using your Google account password.

Follow the steps in the first time wizard to set up or

log into a Google account.

Factory Reset if you have forgotten your PIN,

password or unlock pattern

Press the Emergency Call button on any locked

screen to open the dialler. Enter *983*987# to reset

How to get to Settings

There are a few ways to get to the Settings menu:

1. Go to Apps > Settings

2. Press Options > Settings on the Home Screen

3. Pull down the Notifications panel and press

From Settings you can customise all your phone

settings to suit your needs.

Using the Touch Screen

You can use the touch screen in various ways:

•Touch text entry fields to bring up the keyboard.

Touch buttons, or icons to use them

•Touch and Hold. A long press on some icons

brings up further options. Ie In Messaging,

press and hold a message to Forward.

•Swipe horizontally or vertically on screens to

move between screens.

•Drag, press and hold on an icon to move it on

the screen. Release at the target position.

•Pinch Zoom, on the Camera, Maps, Browser

and Gallery you can zoom in and out by

placing two fingers on the screen at once and

pinching together or spreading apart.

•Auto rotation when enabled will automatically

rotate from portrait to landscape.

Making Calls

1. Touch Home Key > >

2. Enter the phone number using the keypad.

Touch to delete wrong digits.

3. Press Options to add a Pause or Wait if

required

4. Press and hold the 0 key to enter the plus (+)

symbol for international dialling.

5. Touch the Phone icon below the keypad

to dial.

Options during a call

Press to open the number pad

Press to use loudspeaker (Handsfree) mode

Press to mute the microphone

Press to put the current call on hold

Press to dial in another party (Conference)

Press to End the call

When you receive a phone call

The display shows the caller ID and any additional

information about the caller saved in Contacts.

swipe right to to answer the call,

swipe left to to reject the call,

swipe up to to reject the call and send

an SMS which is displayed on screen.

Set this at Dialler > Options > Settings > Other

Settings > Quick responses

TIP: You can silence the incoming ring by pressing

either of the Volume keys.

Adjusting Volumes

The side volume keys work in three different ways:

1. When you are on a call use the volume keys to

adjust the in call volume.

2. When you are using a media application, such as

music, video or games, the volume keys adjust the

media volume.

3. At other times when you are not in either of the

above states, the volume keys set the ringtone

volume or enable vibrate mode at minimum

volume.

Enable Silent or Vibrate mode

Press and hold the Power Key and then touch

to enable silent mode, touch to enable vibrate

mode, or touch to disable silent mode.

Go to Apps > Settings > Audio Profiles > >

Vibrate to enable Vibrate on Ring.

Access the Quick Settings Panel

Swipe down from the top of the screen and touch

the Quick Setting icon. Tap to enable or disable the

features. Some icons can be configured with a long

press (press and hold).

Connect to a local Wi-Fi network

1. Touch Home > Apps > Settings > Wi-Fi, switch to

On.

2. Tap Wi-Fi to view available networks.

3. Touch a network name to connect to it.

Previously connected networks will connect

automatically. If the network is secured enter the

password.

Messaging

You can use Messaging to exchange text

messages (SMS) and multimedia messages

(MMS).

Open the Messaging Screen

Touch in the Home Screen or from Apps

The Messaging screen opens, where you can

create a new message, search for messages, or

open an ongoing message thread.

1. Touch the write icon to write a new message.

2. Touch to search within messages

3. Touch an existing message to open the thread.

Send a Text Message

On the Messaging screen, touch the write icon at

the top of the screen to create a new message.

Enter the recipient’s number or, if the recipient is

stored in Contacts the first letters of their name. As

matching contacts appear, you can touch a

suggested recipient.

Touch the Type text message field, and enter your

message using the keypad.

Touch to Send.

Reply to a Message

Messages you receive are appended to existing

threads of the same number. A new thread is

created for new numbers.

1. On the Messaging screen, touch the thread

that has the message you want to reply to.

2. Type your reply in the text box at the bottom.

You can touch the attach icon +if you want to

reply with an MMS.

3. Touch to Send.

View Message Details

1. Touch and hold a message in a thread.

2. Touch View message details to see the

message type, sender or receiver, time and

date .

Send a Multimedia Message

On the Messaging screen, touch the write icon at

the top of the screen to create a new message.

Enter the recipient and the text of the message, as

you do when sending a text message.

Touch the icon to add an attachment:

Capture


Take a photo and add to your

message.

Capture video

Shoot a video clip and add to

your message.

Record audio

Record an audio file and add to

your message.

Contact

Select a contact to add to your

message as an attachment.

Pictures

Select a picture to add to your

message.

Videos

Select a video clip to attach to your

message.

Audio

Select an audio file to add to your

message.

Calendar

Add a Calendar event such as an

appointment or meeting (VCS).

Slideshow

Add a series of pictures

Touch to Send.

TIPS: The maximum MMS size is 300KB. Large

images are automatically re-sized but video files

may be too large to send. Send large Video files by

email instead or share using Social Media.

Forward a Message

In Messaging touch the thread to open the SMS.

1. Touch and hold the message.

2. Touch Forward in the menu that opens.

3. Enter a recipient for the message and edit the

content if you want.

4. Touch to Send.

Delete messages:

1. On the Messaging screen, touch a thread.
