Zte Tara 3G Bedienungsanleitung

ZTE Tara 3G

User Manual

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or

utilized in any form or by any means, electronic or mechanical,

including photocopying and microfilm, without the prior written

permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to

make modifications on print errors or update specifications without

prior notice.

Version No.: R1.0

Edition Time: 2013.04.03

Key Functions

Earpiece

Headset

Charger interface

Left/Right soft

Key

Send Key

* Key

# Key

End/Power Key

Alpha/Numeric

Keys

4-Way Navigation

Keys and Center

Key

Function Description

Left soft key Performs the function indicated at the left

bottom of the screen.

Right soft key Performs the function indicated at the right

bottom of the screen.

Center key Press to confirm actions and make selections.

4-Way

Navigation keys

These keys (UP, DOWN, LEFT and RIGHT) allow

for navigation through menu options and quick

access to some function menus.

Send key Press to dial a phone number or answer a call,

or view the call history.

End/Power key Press to exit to the idle mode.

Hold to switch on/off the phone.

Alpha/Numeric

keys

Press to enter characters 0-9, the alphabets

from a-z and symbols.

Note: In this User Manual, “press a key” means to press the key

and release it, while “hold a key” means to press the key for at

least two seconds and then release it.

Locking and Unlocking the Keypad

In idle screen, press the Left soft key and then press the * key

within two seconds to lock the keypad. The unlock method is the same.

Locking the keypad can prevent unintentional operations on it. You can

answer an incoming call with the regular operation when the keypad is

locked.

Battery

The lithium ion battery of the mobile phone can be immediately

used after unpacking.

Installing and removing the battery

1. Make sure that your phone is off and remove the battery cover.

2. Insert the battery by aligning the metal contacts with the contacts

in the battery slot. And then push down the upper section of the

battery until it clicks into place.

To remove the battery, pull it up and remove it from the mobile

phone.

3. Replace the battery cover and close it gently until you hear a click.

Remove the battery cover Push down the battery

Replace the battery cover Push up the battery from here

Inserting the SIM/SD card

SIM card (Subscriber Identity Module) is a micro-chip that holds

your personal information such as names and phone numbers. Your

phone won’t work without it. If you already have contacts on your

SIM card, they can be transferred in most cases.

Insert the SIM card and memory card as follows:

1. Make sure that the phone is switched off and the charger is

disconnected from the phone.

2. Turn the phone over and remove the battery cover.

3. Hold your SIM card with the cut corner oriented as shown and then

slide it into the card holder with the metal contacts facing downward.

Insert the SIM card

4. Insert the memory card as shown in the diagram below. Make sure

that insert the card with the metal contacts facing down until it

clicks to the right position.

Notice：This product does not contain SD-card.

Insert the memory card

5. Fix the battery cover till you hear the click sound.

Note: You can use memory card to expand the storage of the phone.

You can store or copy files such as music and so on.

Do not take out the card or switch off the phone while transmitting or

storing data, which may cause data loss or damage to the phone or

the card.

Charging the battery

Your phone is powered by a rechargeable battery. For maximum

battery performance, it is recommended that you first use up the

battery power and then charge it completely. A new battery’s full

performance is achieved only after three complete charge and

discharge cycles.

1. Connect your travel adapter to the left of your mobile phone as

shown in the diagram.

2. Connect the other end of the travel adapter to the mains socket.
