Android Mobile Phone

User Manual

The manual is applicable for the ZTE V6500 mobile phone.

-1-

第1页

No part of this publication may be quoted, reproduced, translated

or used in any form or by any means, electronic or mechanical,

including photocopying and microfilm, without the prior written

permission of ZTE Corporation.

ZTE Corporation reserves the right to make modifications on print

errors or update specifications in this manual without prior notice.

Third-party Software Statement

When you install the software from a third-party, the phone might

be restarted repeatedly or the software might not be used

normally due to the incompatibility of the software itself. It is not

the fault of the phone itself. Version 1.0 in may. 2012

-2-

Using your phone

Thanks for choosing ZTE Corporation’s digital mobile phone,

which we’ll simply call ‘phone’ from now on. Under Android

operating system, the phone supports 3G high-speed Internet

access, which brings you brandnew experiences.

And don’t worry if the pictures we use to demonstrate your

phone’s functions look a little different from what you see on its

screen. It’s the functions they show that matter.

This quick start guide is designed to help you familiarise yourself

with the phone’s basic functions. For details, please refer to the

User Manual.

For more information about how to use your phone, refer to the

User manual on the phone.

To read the user manual, do as follows:

1. Hold the power key to turn on your phone.

2. Click to enter the Launcher, select Settings >

About phone > User manual.

-3-

第3页

Key

Touch screen

Back key

Home key

Menu key

Earpiece

Speaker

Camera

Power key

Headset jack

Side keys

USB port

Getting to know your phone

-4-

Descriptions of Keys

Keys

Functions

Power key

Long press: open the “Phone options”

menu. You can select “Silent mode”,

“Airplane mode”or “Power off”.

Press: switch to the sleep mode or wake up

the phone from the sleep mode.

Home key

Long press: open the list of applications

which have been used recently.

Press: return to the home screen from any

menu;

Menu key

Open the menu on the current interface.

Back key

Return to the previous menu.

Search key

Open the Google searching interface.

Side keys

Adjust the volume. Long press the UP key to

adjust to the maximum volume, and long

press the DOWN key to adjust to the silence

mode.

-5-

第5页

Onscreen icons

Icons

Descriptions

Icons

Descriptions

Signal strength

No signal

Full battery

Charging

Low battery

In a call

Connected on

You have an unread

message.

Speakerphone

You have an unheard

voicemail.

Call forwarding

You have an unread

E-mail.

No memory card

You have an unread

G-mail.

Call held

Connected to a PC

Vibration mode

Music playing

Silent mode

New calendar reminder

Flight mode

Alarm clock on

Missed calls

Wi-Fi function on

Bluetooth®

function is on

Receiving location data

from GPS

Roaming

-6-

Before getting started

Inserting and removing the SIM

Insert the SIM card as follows:

1. Switch off your phone and disconnect any

external power.

2. Remove the back cover and then the battery.

3. Hold your SIM on the cut corner, and slide it

face down into the card holder.

4. Insert the battery.

5. Replace the back cover.

Inserting a memory card

1. Open the battery cover on the back of your phone

2. Push tightly until the card is installed in the right position and

close the cover.

Using the battery

-7-

第7页

Inserting the battery

1. Open the battery cover on the back of your phone.

2. Align the battery's contact points with those of the phone and

gently press the battery down into place.

3. Replace the battery cover clicking it back into position.

Removing the battery

1. Switch off your phone.

2. Open the battery cover.

3. Lift the battery up and out of your phone.

Charging the battery

The battery is not fully charged when you unpack it for the first

time. Please exhaust the capacity of the battery before you

recharge it for the first time.To ensure the

battery is always in its best condition, please

charge the battery 8 hours for the first time

-8-

and recharge it later at least 2 hours each time.

1. Connect the charger to the mobile phone, and insert the

charger to the standard power socket.

2. Please disconnect the charger from the power socket after

the charging is completed.

Tips:

To charge the battery, you can also connect the phone to the

PC through the USB cable.

During charging, the phone and charger may normally

become hot.

Power on/off

Powering on

Long press the Power key until the power-on animation appears.

Long press the Power key to display the menu Phone options

and select Power off.

Tips:

PIN is the password provided by your operator. If PIN is enable,

you need input the correct PIN to use the UIM card.After

receiving the PIN, the phone will automatically search for the

designated networks. The searching process might last for a few

seconds.

Use the SD card as USB storage device

-9-

第9页

1. Insert the SD card into the card slot on the phone.

2. Connect the phone to the PC through the USB cable. The PC

will automatically recognize the SD card as removable storage

device.

3. Touch “Open USB storage device”.

Now you can exchange data between the PC and the SD card.
