Zte V817 Bedienungsanleitung
1
ZTE V817
Quick Start Guide
2
LEGAL INFORMATION
Copyright © 2013 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modifications on print
errors or update specifications in this guide without prior notice.
We offer self-service for our smart terminal device users. Please
visit the ZTE official website (at www.ztedevice.com ) for more
information on self-service and supported product models.
Information on the website takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and
damages caused by unauthorized modifications of the software.
Images and screenshots used in this guide may differ from the
actual product. Content in this guide may differ from the actual
product or software.
3
Trademarks
ZTE and the ZTE logos are trademarks of the ZTE
Corporation.
Google and Android are trademarks of Google, Inc.
The Bluetooth®trademark and logos are owned by the
Bluetooth SIG, Inc. and any use of such trademarks by
ZTE Corporation is under license.
microSD logo is a trademark of the SD-3C, LCC.
Other trademarks and trade names are the property of their
respective owners.
Version No.: R1.0
Edition Time: 201307
Manual No.:
4
Getting to Know Your Phone
Earpiece
Front
Camera
Sensor
Indicator
Touchscreen
Charging/
USB Jack
Volume Keys
5
Power Key
Press and hold to power off or reset the phone, turn on or
off Airplane mode, or select phone modes.
Press to turn off or on the screen display.
Volume Keys
Press or hold to turn the volume up or down.
Power Key
Headset Jack
Back Camera
Flash
Back Cover
Speaker
6
Starting Up
Switch off your phone before installing or replacing the battery
or the SIM card. The microSD card is optional and can be
installed and removed while the phone is turned on. Unmount
the microSD card before removing it.
1. Place your finger in the slot at the bottom of the back cover to
lift and remove the cover.
2. Hold the SIM card with its cut corner oriented as shown and
slip it into the card holder.
7
3. Hold your microSD card with the metal contacts facing down
and slide it into the microSD card slot.
NOTE: Your phone may come with a pre-installed microSD
card. Some applications may not function normally after
you remove the card, pre-installed or otherwise.
4. Align the connectors on the phone and the battery and slide
WCDMA/GSM
GSM
8
the battery into the compartment. Then gently press the
battery down until it is secured.
5. Press the cover gently back into place until you hear a click.
Charging the Battery
1. Connect the adapter to the charging jack. Ensure that the
adapter is inserted with the correct orientation. Do not force
the connector into the charging jack.
9
2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully charged.
Powering On/Off Your Phone
Make sure the battery is charged before powering on.
Press and hold the Power Key to turn on your phone.
To turn it off, press and hold the Power Key to open the
options menu. Touch Power off (or Power Off (Fast))>
OK.
Getting to Know the Home Screen
The home screen is the starting point for your phone’s
applications, functions, and menus. You can customize your
10
home screen by adding application shortcuts, folders, widgets,
and more.
NOTE: Your home screen extends beyond the initial screen,
providing more space for shortcuts, widgets, and folders.
Simply swipe left or right to see the extended home screens.
Opening Applications
1. Touch if the current screen is not the home screen.
2. Touch .
3. Slide left or right on the screen and touch an app to open it.
