Zte Vodafone 553 Bedienungsanleitung
LEGAL INFORMATION
Copyright© 2010 ZTE CORPORATION.
All Rights Reserved
Your Vodafone 553 is made exclusively for Vodafone by ZTE
CORPORATION.
No part of this manual may be reproduced or transmitted in any form or
by any means without prior written consent of ZTE CORPORATION.
Trademarks
VODAFONE and the Vodafone logos are trademarks of the Vodafone
Group.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by ZTE Corporation is under license. Other
trademarks and trade names are the property of their respective owners.
Notice
The information in this manual is subject to change without notice. Every
effort has been made in the preparation of this manual to ensure accuracy
of the contents, but all statements, information, and recommendations in
this manual do not constitute a warranty of any kind, expressed or implied.
Please read the Product Safety Information carefully to ensure the correct
and safe use of your mobile phone.
ZTE CORPORATION Address:
ZTE Deutschland GmbH, Am Seestern 18, 40547 Düsseldorf, Germany
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Website: http://www.zte.com.cn
3
Product Safety Information
Read the Safety Information
section of this user guide on
page 37 Do not use while re-fuelling
Do not use hand-held while
driving
This device may produce a
bright or flashing light
For body-worn operation
maintain a separation of
1.5 cm Do not dispose of it in a fire
Small parts may cause a
choking hazard
Avoid contact with magnetic
media
This device may produce a
loud sound Avoid Extreme Temperatures
Keep away from pacemakers
and other personal medical
devices
Avoid any contact with liquid,
keep it dry
Switch off when instructed in
hospitals and medical
facilities
Do not attempt to
disassemble
Switch off when instructed in
aircrafts and airports
Do not rely on this device for
emergency communications
Switch off in explosive
environments
Only use approved
accessories
4
Contents
1 Getting Started.....................................................................................................5
2 Using the Phone ............................................................................................... 14
3 Messaging........................................................................................................... 17
4 E-mail ................................................................................................................... 20
5 Personal Information...................................................................................... 21
6 Settings................................................................................................................ 23
7 Experiencing Multimedia .............................................................................. 26
8 Getting Connected........................................................................................... 30
9 More Applications............................................................................................ 32
10 Specifications.................................................................................................. 35
11 Troubleshooting ............................................................................................ 36
12 Product Safety Information ....................................................................... 37
13 Attachment...................................................................................................... 46
5
1 Getting Started
Note: Some features described in this document are dependant of your
operator and may differ from what you have.
1.1 Starting Up
Battery
The lithium ion battery of the mobile phone can be immediately used
after unpacking. A new battery performs best after perfoming a full
charge/discharge 3 times.
Installing the battery
1. Align the battery's contact points in the direction of the arrow shown
and insert the battery into the slot.
2. Put on the battery cover and press it gently until you hear a click.
Removing the battery
1. Make sure that your mobile phone is switched off.
2. Remove the battery cover.
3. Pull the battery up and remove it from the mobile phone.
6
How to insert the SIM card
Insert the SIM card as follows:
1. Make sure that the phone is switched off and the charger is
disconnected from the phone.
2. Turn the phone over and remove the battery cover.
3. Remove the battery if it is already installed.
4. Hold your SIM card with the cut corner oriented as shown and then
slide it into the card holder with the gold-coloured contacts facing
downward.
5. Replace the battery first.
6. Replace the battery cover.
Caution:
•Do not bend, scratch the SIM card, or unnecessarily touch its metal
surface. It may damage the information stored.
•Do not force the cover down by pressing on it. This may damage the
cover.
How to charge the battery
The battery needs to be charged for at least 6-8 hours when you charge it
for the first time.
1. Connect your travel adapter to the side of your mobile phone as shown
in the diagram next page.
7
2. Connect the other end of the travel adapter to the mains socket.
3. When you charge the battery, the battery charging indicator appears.
4. When the battery is fully charged, the battery indicator is full and
doesn’t flicker any longer, disconnect the charger.
Inserting and Removing a Memory Card
Vodafone 553 supports microSD memory cards up to 8Gbyte. Please
follow the instructions from your microSD card vendor.
To insert a card,
1. Remove the battery cover.
2. Insert the memory card into the slot.
Before you take out the card, please open the battery cover and press the
card inward to unlock.
Powering On/Off
Make sure that your SIM card is inserted and the battery is charged.
Hold the Power key 2 or 3 seconds to turn your phone on or off.
Notes: You may need to enter the Personal Identification Number (PIN) or
phone password if you have enabled phone lock or PIN LOCK (See Section
6).
8
1.2 My Phone
Receiver
Send key
End/Power key
Space Key
Enter key
Backspace key
Function key
Navigation keys
Menu key
Shift/Caps lock key
Switch input method
Left soft key/Right
soft key
Symbol key
Camera
Volume keys
USB port
In idle screen, press
and hold this key to
switch profiles mode
between normal and
silent.
Loudspeaker
9
1.3 Idle screen
When you turn on the phone, it enters the idle screen. The following
indicators notify you with the phone status and alerts.
Indicator What it means Indicator What it means
Shows the phone’s
network signal strength Shows the phone’s
battery capacity
Call diverting The alarm clock is active
The phone is under
roaming status The alert type is set to
ring
You have unread
message The alert type is set to
vibration
Silent mode is activated The alert type is set to
vibration then ring tone
You have unheard voice
mail The alert type is set to
vibration and ring tone
A headset is connected
to the phone GPRS connection is active
EDGE connection is
active Audio player is on
The stopwatch is active Bluetooth®connectivity is
on
You have unread E-mail
10
1.4 Text Input
Using Virtual keyboard
As the slide is not opened, you could use the virtual keyboard to input.
•Show virtual keyboard: Click any place in the
text input area to show the virtual keyboard.
•Hide virtual keyboard: Click icon.
•Change input method: Click icon to
change the input method.
•Input Letters: In abc method, click the
corresponding letters to input your desired letter.
Each key is used to input multiple letters. Click the key quickly and
repeatedly until your desired letter appears.
•Input Words: In Smart abc method, click each key only once for every
letter. The word changes after each key stroke. When you finish
writing the word correctly, click the word to confirm. If the word
displayed on the screen is not what you want, click the arrow to view
other matching words, and then click the word to confirm. Predictive
text input is based on a built-in dictionary.
•Switch caps lock : Click icon.
•Input numbers: In 123 method, click the corresponding numbers on
the screen to input your desired numbers.
•Input symbols: Click icon to open the virtual keypad and
select the corresponding symbols to input.
•Insert a space: Click to input the space. It does not work in 123
method.
