ZTE AD226

WiMAX EVDO USB Modem

User Manual

ZTE CORPORATION

ZTE Plaza, Keji Road South,

Hi-Tech Industrial Park,

Nanshan District, Shenzhen,

P. R. China

518057

Tel: (86) 755 26779999

URL: http://www.zte.com.cn

E-mail: [email protected]

LEGAL INFORMATION

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by

any means, electronic or mechanical, including photocopying and microfilm, without the prior

written permission of ZTE Corporation.

The manual is published by ZTE Corporation. We reserve the right to make modifications on print

errors or update specifications without prior notice.

Version No. : RV1.0

Edition Time : Jan 13 2010

Manual No. :

Content

General.................................................................................................................................. 1

Welcome to ZTE AD226 WiMAX EVDO USB Modem................................................. 1

Safety Warning and Notice............................................................................................... 1

Cleaning and Maintenance................................................................................................ 2

Limit Warranty.................................................................................................................. 2

Declaration........................................................................................................................ 3

RF Exposure Information (SAR)...................................................................................... 3

Limitation of Liability....................................................................................................... 4

Getting Started ...................................................................................................................... 5

Functions........................................................................................................................... 5

Specification...................................................................................................................... 5

Modem View..................................................................................................................... 6

LED Indications................................................................................................................ 6

Working Condition ........................................................................................................... 6

Installing Modem.................................................................................................................. 7

System Requirements........................................................................................................ 7

Inserting Modem............................................................................................................... 7

Install Join Air................................................................................................................... 7

About Join Air............................................................................................................... 7

Installing Join Air.......................................................................................................... 7

Remove the modem safely.............................................................................................. 10

Uninstalling Join Air....................................................................................................... 10

Basic Operation................................................................................................................... 11

Main Panel ...................................................................................................................... 11

Ras Panel......................................................................................................................... 11

Ndis Panel....................................................................................................................... 12

Diagnose Panel................................................................................................................ 12

OMA Panel ..................................................................................................................... 13

Security Panel ................................................................................................................. 13

WiMAX Panel................................................................................................................. 14

Debug panel .................................................................................................................... 15

GPS Panel ....................................................................................................................... 15

MIP Panel........................................................................................................................ 16

FAQs and Troubleshooting................................................................................................. 17

Confidential and Proprietary Information of ZTE CORPORATION 1

C h a p t e r 1

General

Welcome to ZTE AD226 WiMAX EVDO USB

Modem

Thank you for choosing ZTE AD226 WiMAX EVDO USB Modem (hereinafter referred to as Modem).

AD226 is a high-speed, broadband wireless dual-mode USB modem with two work modes of WiMAX

and EVDO to enable users enjoy internet anywhere and anytime.

AD226 can support smart switch between WiMAX and EVDO. It can offer the maximum download

speed of 3.1Mbps and upload 1.8Mbps based on EVDO Rev.A, and even makes the data download speeds

up to 30 Mbps and upload 6 Mbps when user access to the next generation WiMAX service. AD226 also

supports GPS for location-based services right on your laptop.

Getting started with ZTE AD226 WiMAX EVDO USB Modem is simple: no wires means no service calls.

Just connect your ZTE AD226 WiMAX EVDO USB Modem to your computer, install Join Air, and

activate your account, and you have broadband on the go.

To guarantee your modem always in its best condition, please read this manual carefully and keep it for

future use.

The pictures, symbols and contents in this manual are just for your reference. They might not be

completely identical with your modem. Please subject to the real object. ZTE operates a policy of

continuous development and reserves the right to update and modify the technical specifications in this

document at any time without prior notice.

Safety Warning and Notice

To the owner

•Some electronic devices are susceptible to electromagnetic interference sent by modem if inadequately

shielded, such as electronic system of vehicles. Please consult the manufacturer of the device before

using the modem if necessary.

•Operating notebook computer and Modem may interfere with medical devices like hearing aids and

pacemakers. Please always keep the modem more than 20 centimeters away from such medical devices

when they are in use. Take off modem if it is necessary. Consult a physician or the manufacturer of the

medical device before using the Modem.

•Be aware of the usage limitation when using a Modem at places such as oil warehouses or chemical

factories, where there are explosive gases or explosive products being processed. Do not use Modem if

necessary.

•Don‟t touch the antenna area unnecessarily while connected. This can affect your Modem‟s performance

and reduce the signal quality.

•Do not use Modem at gas station.

•The Modem contains sensitive electronic circuitry. Do not expose the Modem to any liquids, high

temperatures or shock.

•Store the Modem out of the reach of small children. The Modem may cause injury if used as a toy.

•Only use original accessories or accessories that are authorized by the manufacturer. Using unauthorized

accessories may affect your Modem‟s performance, damage your Modem and violate related national

ZTE AD226 User Manual

2 Confidential and Proprietary Information of ZTE CORPORATION

regulations.

•Always handle the Modem with care. Be careful not to drop or bend the Modem.

•There are no user serviceable parts inside the Modem. Unauthorized dismantling or repair of the modem

will void the warranty.

•This Modem generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

•There is no guarantee that interference will not occur in a particular installation. If this modem does

cause harmful interference to radio or television reception, which can be determined by turning the

modem off and on.

•This Modem must be installed and operated in accordance with provided instructions and must be used

to provide a separation distance of at least 5 mm from all persons and must not be co-located or

operating in conjunction with any other transmitter.

Modem

•Please use original accessories or accessories that are authorized by the manufacturer. Using any

unauthorized accessories may affect your Modem‟s performance, and violate related national

regulations about telecom terminals.

•Avoid using the Modem near metallic structure device or establishment that can emit electromagnet

wave. Otherwise it may influence receiving of signals.

•The Modem is non-waterproof, please keep it dry and store in shady and cool place.

•Don‟t use the Modem immediately after a sudden temperature change e.g. from an air conditioned

environment to high temperature and humidity outside. In such cases there could be condensing

moisture inside the Modem which can cause internal damage. Unplug the Modem and leave it for 30

minutes before use.

•Take the Modem carefully. Don‟t drop, bend, knock or harshly treat it to avoid destructive damage.

•Do not attempt to disassemble the Modem by yourself. Changes and modifications made to the Modem

without the approval of manufacturer could void your authority to operate this Modem.

In Aircraft

•Please power off the modem before the airplane takes off. In order to protect airplane‟s communication

system from interference, it is never allowed to use the modem when it is in flight. Using it before the

airplane taking off should get aircrew‟s permission according to safety regulations.

Cleaning and Maintenance

•ZTE AD226 WiMAX USB Modem is non-waterproof, please keep it dry and store in shady and cool

place.

•Do not use or store the device in dusty or dirty areas, since its moving parts and electronic components

can be damaged in such environment.

•If you want to clean your modem, please use clean fabric that is a bit wet or anti-static. Do not use harsh

chemical cleaning solvents or strong detergents to clean your modem, such as alcohol, dilution agent

and benzene. Power-off your modem before you clean it.

•Use modem within a temperature range of -10℃~55℃and a humidity range of 5%~95%.

Limit Warranty

The warranty does not apply to defects or errors in the product caused by:

1. Reasonable abrasion.

ZTE AD226 User Manual

Confidential and Proprietary Information of ZTE CORPORATION 3

2. Misuse including mishandling, physical damage, improper installation, unauthorized disassembly of the

product.

3. Water or any other liquid damage.

4. Any unauthorized repair or modification.

5. Power surges, lightning damage, fire, flood or other events outside ZTE‟s reasonable control.

6. Use of the product with any unauthorized third party products such as generic chargers.

7. Any other cause beyond the range of normal usage for products.

End User shall have no right to reject, return, or receive a refund for any product from ZTE under the

above-mentioned situations.

This warranty is end user‟s sole remedy and ZTE‟s sole liability for defective or nonconforming items,

and is in lieu of all other warranties, expressed, implied or statutory, including but not limited to the

implied warranties of merchantability and fitness for a particular purpose, unless otherwise required under

the mandatory provisions of the law.

Declaration

We, ZTE Corporation, declared that:

The user is cautioned that changes or modifications not expressly approved by the manufacturer could

void the user‟s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device

does not cause harmful interference.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

—Reorient or relocate the receiving antenna.

—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

—Consult the dealer or an experienced radio/ TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the

user„s authority to operate the equipment.

RF Exposure Information (SAR)

This device meets the government‟s requirements for exposure to radio waves.

This USB Dongle is designed and manufactured not to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal Communications Commission of the U.S.

Government.

ZTE AD226 User Manual

4 Confidential and Proprietary Information of ZTE CORPORATION

The exposure standard for wireless device employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are

conducted using standard operating positions accepted by the FCC with the device transmitting at

its highest certified power level in all tested frequency bands. Although the SAR is determined

at the highest certified power level, the actual SAR level of the USB Dongle while operating can

be well below the maximum value. This is because the device is designed to operate at multiple

power levels so as to use only the poser required to reach the network. In general, the closer

you are to a wireless base station antenna, the lower the power output.

The highest SAR value for the device as reported to the FCC when tested for body, as described

in this user guide, is 1.45 W/kg for CDMA band, 0.604 W/kg for WIMAX band.

While there may be differences between the SAR levels of various USB Dongles and at various

positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this device with all reported SAR levels

evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this

device is on file with the FCC and can be found under the Display Grant section of

http://www.fcc.gov/oet/fccid after searching on FCC ID: Q78-ZTEAD226.

For body operation, this device has been tested and meets the FCC RF exposure guidelines for

use the positions the device a minimum of 0.5 cm from the body. Use of other enhancements

may not ensure compliance with FCC RF exposure guidelines.

This USB dongle transmitter is approved for use in typical laptop computers. To comply with

FCC RF exposure requirements, this USB dongle should not be used in other devices or certain

laptop and tablet computer configurations where the USB connectors on the host computer are

unable to provide or ensure the necessary operating configurations intended for the device and its

users or bystanders to satisfy RF exposure compliance requirements. This transmitter must not be

collocated or operating in conjunction with any other antenna or transmitter.

Limitation of Liability

ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential damages

resulting from or arising out of or in connection with using this product, whether or not ZTE had been

advised, knew or should have known the possibility of such damages.

ZTE AD226 User Manual

Confidential and Proprietary Information of ZTE CORPORATION 5

C h a p t e r 2

Getting Started

Functions

Functions: Data service, Connection management, etc.

Specification

Port

USB2.0

Mode of Access

WiMAX (Worldwide Interoperability for Microwave Access)

CDMA 2000 1X/EVDO Release 0/EVDO Release A

Protocol

WiMAX

802.16e (IEEE 802.16-2005)

CDMA

CDMA 2000 1x / EVDO Release 0 / EVDO Release A

Frequency

Allocation

WiMAX

2496MHz~2690MHz

CDMA

CDMA Cellular (UL 824MHz~849MHz,DL 869MHz~894MHz)

CDMA PCS (UL 1850MHz~1910MHz,DL 1930MHz~1990MHz)

Data Rate

WiMAX High Speed Data

Peak downlink data rate of 30Mbps

Peak uplink data rate of 6Mbps

Average downlink data rate of

18Mbps

Average uplink rate of 4Mbps

CDMA 1X Packet Data (Release

*Peak data rate is as remark

Reverse Link 153kbps

Forward Link 153kbps

CDMA 1X-EVDO Packet Data

(Rev. 0)

*Peak data rate is as remark

Reverse Link 153kbps

Forward Link 2.4Mbps

CDMA 1X-EVDO Packet Data

(Rev. A)

*Peak data rate is as remark

Reverse Link 1.8Mbps

Forward Link 3.1Mbps

OS Compatibility

Win XP, Win Vista, Win 7, Mac OS,

Dimension

82mm*32.6mm*17.8mm

Weight

TBD

ZTE AD226 User Manual

6 Confidential and Proprietary Information of ZTE CORPORATION

Modem View

1. USB connector

2. LED indicator

LED Indications

Your Modem gives you at-a-glance status information via its LED indicator bar. Here‟s a list of indicators

and meanings:

Item

Description

Device Initiating

LED Solid Amber

Firmware Downloading

LED Solid Amber

Firmware Download finished

LED Solid Amber

No Network/searching for Network

LED Solid Red

Network Entry
