Quick Start Guide

Vodafone Mobile Connect

USB Stick

QSG_VMCLite_v9.3_0708_K2525_en-G1 1QSG_VMCLite_v9.3_0708_K2525_en-G1 1 10/7/08 14:29:0610/7/08 14:29:06

Welcome

to the world of mobile communications

1 Welcome

2 Set up your USB Stick

3 Start the software

4 Software overview

5 Connect

6 SMS text messaging

7 SMS contacts

9 USB Stick LED light

9 Signal strength

10 Hints and tips

12 Glossary

QSG_VMCLite_v9.3_0708_K2525_en-G2 2QSG_VMCLite_v9.3_0708_K2525_en-G2 2 10/7/08 14:29:0810/7/08 14:29:08

Your new Vodafone Mobile Connect USB Stick lets you connect your

computer to the internet over the Vodafone high-speed mobile phone

network.

Browse the web

You can now access the web and any other internet service wherever

there’s a mobile phone network .

Pick up emails

Keep up to date with your emails, wherever you are. You can also access

your personal email accounts – even web-based accounts like Hotmail.

Send and receive SMS text messages*

You can send and receive SMS text messages straight from your

computer. Vodafone SMS provides an easy way to view messages, write

new ones, and manage contact details.

System Requirements

To use this USB Stick and the Vodafone Mobile Connect software, you

need:

–A computer running Microsoft®Windows Vista™, Windows®XP SP2

or Windows®2000 SP4, or an Apple Mac running Mac OS®X 10.3.9 or

above

–At least 100 MB free disk space and 256 MB RAM memory

–A USB 2.0 socket

– Administrator rights on your computer.

Welcome

* SMS is currently only supported on computers running Microsoft Windows.

QSG_VMCLite_v9.3_0708_K2525_en-G1 1QSG_VMCLite_v9.3_0708_K2525_en-G1 1 10/7/08 14:29:1710/7/08 14:29:17

• Remove the cap from the end of the USB Stick.

• Pull out the SIM holder from its slot, and insert your SIM as shown.

• Re-insert the SIM holder into the USB Stick.

• Plug the USB Stick ﬁrmly into your computer’s USB port.

Set up your

USB Stick

Your SIM (Subscriber

Identity Module) is the

small, postage-stamp–

sized chip that you

received together with

your mobile subscriber

contract.

In areas of low

network coverage we

recommend you use

the USB extension

cable to improve your

reception.

QSG_VMCLite_v9.3_0708_K2525_en-G2 2QSG_VMCLite_v9.3_0708_K2525_en-G2 2 10/7/08 14:29:1810/7/08 14:29:18

On Microsoft Windows computers

The software setup should start automatically, and proceed to set up

your USB Stick. If for some reason the setup does not start, double-click

the ﬁle called setup_vmc_lite.exe on the USB Stick. Follow the on-

screen instructions.

Setting up your USB Stick may take a few minutes, but once the setup

is ﬁnished, the Vodafone Mobile Connect Lite software should start

automatically. If for some reason the program does not start, select

Vodafone Mobile Connect from the Windows Start menu.

On Mac OS X computers

The ﬁrst time you plug in your USB Stick, it will show up on your desktop

like a standard USB memory stick. Insert the Vodafone Mobile Connect

Mac software CD into the CD drive, double-click the ﬁle called Vodafone

MC Installer, and follow the on-screen instructions.

Once your Mac has restarted, the USB Stick will no longer appear, but

you will see the Vodafone Mobile Connect software in your Applications

folder. Double-click the program to set up a mobile connection.

Start the

software

QSG_VMCLite_v9.3_0708_K2525_en-G3 3QSG_VMCLite_v9.3_0708_K2525_en-G3 3 10/7/08 14:29:2110/7/08 14:29:21

Connect/Disconnect

Connect via the mobile phone network

Views

View data usage, and additional software settings

Start SMS program

Send, receive and manage SMS messages and contacts

Status

Check the status of your connection

Help

Help Topics, plus internet and hotline support.

The first time you run

the software, your USB

Stick will usually be set

as the default device. If

it is not, click ‘Manage

Devices’ and select

your USB Stick there.

Software

overview

QSG_VMCLite_v9.3_0708_K2525_en-G4 4QSG_VMCLite_v9.3_0708_K2525_en-G4 4 10/7/08 14:29:2210/7/08 14:29:22

The radio waves on the

Mobile Connections icon

are animated whenever

data is being transferred

over the connection.

No radio waves are

shown when nothing is

being transferred.

The radio waves are

shown static when no

connection is open.

If a mobile network has been found, the Connect button in the Mobile

Connections panel will be enabled. Clicking Connect connects to the

internet across the mobile phone network. Now you can browse the web

or use email.

When connected, the Connect button text changes to Disconnect and a

green ‘Connected’ indicator appears below the button.

Clicking the Disconnect button will close the connection – and the text

on the button will revert to Connect.

To open a mobile connection, you need to be within coverage of a

mobile network. As a rule, anywhere you can make a call on your mobile

phone, you should be able connect.

Connect

QSG_VMCLite_v9.3_0708_K2525_en-G5 5QSG_VMCLite_v9.3_0708_K2525_en-G5 5 10/7/08 14:29:2410/7/08 14:29:24

Click Vodafone SMS on the navigation bar in the main window of the

Vodafone Mobile Connect Lite software to open the SMS program.

To send an SMS

Click New at the left-hand end of the SMS toolbar to create a new SMS

text message.

1 Address

Enter the recipients here, or choose them from Contacts

2 Message

Write your message here

3 Send

Click on the Send button to send your message.

After your SMS has been sent, it will be stored in the Sent list.

SMS Text

Messaging

The number displayed

to the person who

receives your message

will be from your data

SIM, not your mobile

phone. Use a short

‘signature’ to make

sure people know you

sent them a message:

Settings/Messages/

Signature.

QSG_VMCLite_v9.3_0708_K2525_en-G6 6QSG_VMCLite_v9.3_0708_K2525_en-G6 6 10/7/08 14:29:2510/7/08 14:29:25

Receiving SMS

When you receive a new message, an SMS Notiﬁcation is shown brieﬂy

so you can respond to it directly.

The received message can also be read from the Inbox in the main

Vodafone SMS window.

The Vodafone SMS

software will receive

text messages

whenever you have

mobile network

coverage.

QSG_VMCLite_v9.3_0708_K2525_en-G7 7QSG_VMCLite_v9.3_0708_K2525_en-G7 7 10/7/08 14:29:2610/7/08 14:29:26

SMS Contacts Click Contacts on the SMS navigation bar to open the Contacts list, in

which you can save SMS numbers that you use frequently as contacts

with names.

New SMS Contact

Clicking the New button on the SMS toolbar opens a new contact

window.

Enter the name and

number of your contact

using the international

format for the number,

eg. +447774477000.
