ZVue Sprit Bedienungsanleitung

User Guide

Contents

Welcome to ZVUE 2

Safety Tips 2

Get To Know Your ZVUE Spirit 3

Main Features 3

Key and Control Interface 3 - 4

Getting Started 5

Main Menu 5

Music Playback 6 - 7

Record 7

Browse 8

System Settings 9

Music 9

Record 10

Display 10

System 10

Power O 11

Language 11

Connecting to Your PC 11 - 12

Notes 13

Need More Help? 14

Welcome to ZVUE

•Use this unit only as intended.

•To prevent re or shock hazard, do not expose this unit

to rain or moisture.

•Do not submerge the unit in any liquid.

•Do not disassemble.

•Do not touch the USB connection port of the player, as

it may become damaged.

Safety Tips:

Congratulations on your purchase of

the ZVUE Spirit MP3 Player. We hope

you enjoy your ZVUE Spirit Player. To

get the most out of your ZVUE Spirit

Player please read this manual as it

provides tips and information about

its various features.

Included in the box:

•ZVUE Spirit MP3 Player •USB Wall Adapter

•ZVUE Sound Headphones •USB Cable

•Protective cover •User Guide

Get To Know Your ZVUE SpiritGet To Know Your ZVUE Spirit

•1 GB of built-in memory.

•Supports MP3, WMA, and WAV audio formats.

•Seven preset equalizer settings, multiple playing modes,

and outstanding sound quality.

• Lyrics le (.lrc) support (3rd party Software needed).

•Microphone for voice recording.

•Multiple language support.

•Supports Windows 2000 or higher.

•High speed USB 2.0 interface.

•ID3 Tag support.

Main Features Key and Control Interface

USB Port

On/O Switch

Play/Pause

Press and hold for 2

seconds to turn unit

on or o, quick press

to play or pause

VOLUME

Activate the volume

control, back out of menus,

and activate le functions.

FAST Forward

Next menu item,

increase volume

and fast forward.

Rewind

Previous menu item,

decrease volume

and rewind

Enter into the main menu, conrm

your selection, press and hold for

2 seconds to return to the main

menu at any time.

Headphone Jack

HOLD Feature – Press and hold the and MENU buttons to activate

and deactivate the Hold feature. While activated this will lock the buttons

and prevent them from being pressed accidently.

Key and Control Interface

Speaker

Microphone

Bottom/Back View

Front View

NOTE

Your ZVUE Spirit includes an

external speaker but for the

best listening experience

plug your ZVUE Sound head-

phones into the headphone

jack on the player.

5 6

Getting StartedGetting Started

Before using your ZVUE Spirit MP3 player, toggle the power

switch into the On position. Next, press and hold the

button for 2 seconds. The player will start with a brief splash

screen and present the main menu.

Connect the ZVUE Spirit MP3 player with the USB cable to

the USB power adapter. Plug the USB power adapter into a

wall socket and let your player charge for at least three hours

Once it’s charged, unplug it from the power adapter.

From the main menu, highlight the Music ( ) option and

press the MENU button to conrm your selection.

plays or resumes the current track.

pauses the music.

To change music tracks:

to play next music track. Press and hold to fast forward

within the current song.

to play previous track. Press and hold to rewind within

the current song.

To adjust the volume:

VOL To activate the volume control. The volume symbol

on the screen will highlight.

to increase volume

to decrease volume

Press VOL to exit the volume control. If you do not press any button,

the volume control will be dismissed after several seconds.

Press MENU once to browse through your music les while listening to the

current track. Use or to browse through the les. Press to play

the highlighted track.

The main menu contains four submenus. Each menu

corresponds to a function of the player.

Music – To play music.

Record – To record from the microphone.

Browse – View the le contents of your player.

System Settings – To change the system settings.

Press or to highlight the desired function.

Press MENU to conrm your selection.

Press and hold the MENU button for 2 seconds to return to the

main menu from any mode or VOL to back out of any menus.

Main Menu

Music Playback

7 8

Getting StartedGetting Started

Music Playback (continued)

Record

While a track is playing, press MENU button twice to go back to the

main menu.

You can also press and hold the MENU button for 2 seconds to return

directly to the main menu. This won’t stop playback of current track.

Your voice recordings made in Record () mode will play from

Music Playback () mode.

From the main menu, highlight the Browse ( ) option

and press the MENU button to conrm your selection.

To select a le or folder:

highlight the next le or folder.

highlight the previous le or folder.

VOL - to activate the delete function. Highlight the le

you wish to delete and press VOL, the player will oer a

conrmation option.

Highlight “Yes” and press MENU to delete a le.

Highlight “No” and press MENU to leave the le alone.

From the main menu, highlight the Record ( ) option

and press the MENU button to conrm your selection.

Press - Start or Pause recording from microphone. The

counter on the screen will run while recording.

Voice recording supports MS-ADPCM WAV (.wav) formats.

There is a maximum of 99 recordings in any folder.

To listen to your recordings, exit to the main menu by pressing and holding

the MENU button for 2 seconds.

Highlight the Music ( ) option and press MENU to conrm your selection.

Press MENU to see all your stored les. Find the “Voice” folder and press

to enter the folder. Highlight the voice track you want and press to play it.

Browse

WARNING

Please use the delete feature carefully. Any les deleted

from the player will be gone forever, so please be sure to

create a backup of the les that come with the player to

be able to enjoy them in the future.

NOTE

910

System Settings

From the main menu, highlight the System Settings ( )

option and press the MENU button to conrm your selection.

Repeat mode –

Once – Plays current track only once.

Repeat 1 – Repeats current track on a loop.

Folder Once – Plays all tracks in folder only once.

All Once – Plays all tracks only once.

All Repeat – Repeats all tracks on a loop.

Intro – Plays only rst seconds of each track.

Play Mode -

Order - Play all tracks in order.

Shue – Play all tracks in a random order.

EQ Select – Oers a variety of preset equalizer settings. Choose a setting

that best compliments your music preference or tastes. This includes the

“User EQ” setting, which is set in the next system setting menu item.

User EQ Set – This option oers your several sound frequency ranges

to adjust. Use the and to adjust the currently highlighted frequency

band. Press VOL to conrm your setting for that frequency band and

continue to the next. Once you have set all of the frequency values to

your liking press the MENU button to return to the main menu.

System Settings

REC Quality – High Quality or General Quality. The higher quality uses

more storage per second of recording.

REC Volume – This sets the sensitivity of the microphone. This may take

some experimentation to determine which setting is best for you in your

recording environment.

Backlight - Set the amount of inactivity in seconds before the backlight

turns o. Settings are: 5, 10, 15, 20, and 30 seconds. This also includes

“Always On”, which will leave the backlight on for the entire time the player

is powered on.

Brightness – This is the brightness setting. This includes settings labeled

1 through 5, with 5 being the brightest setting.

About – Displays the version number of the rmware, the date of the rm-

ware, as well as storage available and total capacity of the player’s storage.

Upgrade – This is a feature to allow you to upgrade the rmware of the

player. This should only be used under the instruction of a ZVUE customer

service agent.

Default Set – This option returns all of the player settings to their default

factory settings. This will not aect the preloaded content of your player.

Music

Record

Display

System

11 12

System Settings/Connecting to Your PC

Power O

This feature allows for the setting of the amount of inactivity before the

player turns o. It includes settings for: 10, 15, 30, 60, and 120 minutes.

The OFF setting ensures the player will remain on regardless of any lack

of button or audio playback activity, until such a time as you turn o the

power manually or the battery runs out.

Language

Allows you to set the menu to a dierent language.

The ZVUE Spirit player can hold a maximum of 99 folders. Each folder

can hold a maximum of 99 audio les each.

Your ZVUE Spirit will work with Windows XP, 2000, and

Vista without any additional drivers.

To connect your ZVUE Spirit MP3 player to your computer:

1. Turn the Spirit player on.

2. Connect the small end of the supplied USB cable to the

Spirit MP3 player.

3. Connect the large end of the USB cable to an available

USB port on your computer

Connecting to your PC

A hard drive icon representing the ZVUE Spirit will appear on your computer’s

“My Computer” window. It will be identied as a “Removable Disk”.

Double-click this icon; it will open up as a new window that shows the card’s

contents. You can copy and delete les just as you would with les on a hard

drive or oppy disk.

Ejecting your player:

When you are nished copying les to the player, “Eject” it from your

computer. First close all the windows that belong to your ZVUE Spirit. In the

“My Computer” window, right-click the icon for the player and select Eject.

Your ZVUE will exit USB mode and display a list of the les and folders you’ve

copied to the player.

Now you can listen to your music.

If you do not properly eject the player from your computer before

disconnecting your ZVUE Spirit, you may corrupt les on the player.

This can be remedied by simply recopying your music les over the

les already on the player.

System (continued)

Connecting to Your PC

NOTE

13 14

Notes

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

 • Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

For additional questions, online tutorials, and step-by-step

instructions, please go to: www.ZVUE.com/support

Additional Help

Toll free number 1.888.553.0967

Email support@zvue.com

WARNING

Changes or modications to this unit not expressly approved

by the party responsible for compliance could void the user’s

authority to operate this equipment.

Need More Help?

ZVUE Spirit, ZVUE Products, and ZVUE are trademarks of the ZVUE Corporation.

NOTE

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ZVue MP3-Player Handbücher

ZVue

ZVue 200 Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Philips

Philips PSA250 Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung
