HIVE

ASSEMBLY INSTRUCTIONS

HIVE

ASSEMBLY INSTRUCTIONS

COMPONENTS

Strut

Connector

Hexagonal insert

HIVE

ASSEMBLY INSTRUCTIONS

STEP 1 STEP 2

•Begin by assembling 1 complete hexagon using the struts

and connectors as shown above.

•Assemble additional hexagons as shown in step 2, 3 and 4 using

struts and connectors.

HIVE

ASSEMBLY INSTRUCTIONS

STEP 3 STEP 4

HIVE

ASSEMBLY INSTRUCTIONS

STEP 5 STEP 6

•Continue building your structure as per your design layout

by simply assembling additional hexagons onto the system.

•The hexagonal inserts can be added in at any time during your build

from either side or even from both sides.

•Inserts placed in from the bottom my need a small bead of adhesive

to ensure they remain secure.

•The inserts will also make the system more rigid.

HIVE

ASSEMBLY INSTRUCTIONS

Suggested suspension points

HIVE

ASSEMBLY INSTRUCTIONS

Option 3: 12mm Aluminium U channel with

Activity code and barrel end ﬁxing.

Suggested Fixings

Option 2: Activity code with Round single hole Aluminium clip.

Activity code Round single hole Aluminum clip

Option 1: Direct hanging code (Clamp needs to be 12mm)

with Round single hole Aluminium clip.

Round single hole Aluminum clip

Direct hanging code

Sheet Thickness

12mm

Dimensions

Each hexagon 908 (w) x 807 (h) x 240 (w)

Telephone

Francois: +44 7305 349443

Daniel: +27 82 331 8319

[email protected]

Website

www.14six8.com

Address

71-75, Shelton Street, Covent Garden,

London, WC2H 9JQ, United Kingdom

HIVE

ASSEMBLY INSTRUCTIONS
