2-Wire 802.11g USB Wireless Adapter Bedienungsanleitung
Installation Guide
802.11g USB Wireless Adapter
Notice to Users
©2005 2Wire, Inc. All rights reserved. This manual in whole or in part, may not be reproduced,
translated, or reduced to any machine-readable form without prior written approval.
2WIRE PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE
SOFTWARE, OR SUCH OTHER INFORMATION, IN NO EVENT SHALL 2WIRE, INC. BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR
OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE, OR OTHER
INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
2Wire, Inc. reserves the right to make any modification to this manual or the information contained
herein at any time without notice. The software described herein is governed by the terms of a separate
user license agreement.
2Wire, and the 2Wire logo are registered trademarks of 2Wire, Inc. All other trademarks are trademarks
of their respective owners.
5100-000245-001 Rev B
1
2Wire 802.11g Wireless USB Adapter
2Wire’s 802.11g Wireless USB Adapter is a wireless networking device that is
connected to a USB port on your computer using a USB cable. Wireless networking
provides the same connectivity as Ethernet without the wires. Expanding or
redesigning your network is easy, and unlike cabled Ethernet, the 2Wire 802.11g
Wireless USB Adapter allows users to roam throughout the home or office while
remaining connected to the local area network (LAN).
Follow these steps to complete the adapter installation:
Step 1 - Install the 2Wire 802.11g Wireless USB Adapter.
Step 2 - Install the adapter driver from your 2Wire Wireless Installation CD.
The following sections give you detailed instructions for completing each step.
2
Step 1: Install the 2Wire 802.11g Wireless USB Adapter
The supplied USB cable has a different type of USB connector on each end.
Series A connector. The Series A USB connector plugs into the
USB port on your computer.
Mini Series B connector. The Series B USB connector plugs into a
USB device.
To install the 2Wire 802.11g Wireless USB Adapter, simply
connect the adapter to an available USB port on your computer using the supplied
USB cable.
3
STEP 2: Install the 2Wire 802.11g Wireless USB Adapter
Driver
Installing Drivers For Windows XP
1. Power on your computer. Insert your 2Wire
Wireless Installation CD into your CD-ROM
drive.
2. When the Found New Hardware Wizard
window opens, select Install the software
automatically (Recommended) and click Next
to continue.
4
3. The driver installs.
4. When the Completing the Found New Hardware
Wizard opens, click Finish.
5. Continue to “Appendix A: Wireless Adapter
Configuration” on page 12 to configure the
adapter to work with your 2Wire gateway.
5
Installing Drivers for Windows 2000
1. Power on your computer. Insert your 2Wire
Wireless Installation CD into the CD-ROM
drive.
2. When the Found New Hardware Wizard window
opens, click Next to continue.
3. The next window prompts you to install device
drivers. Select Search for a suitable driver for my
device (recommended), and click Next.
6
4. When the Locate Driver Files window opens,
deselect the Floppy disk drives checkbox, select
the CD-ROM drives checkbox, and click Next.
5. When the Driver Files Search Results window
opens, click Next.
7
6. When the Completing the Found New Hardware
Wizard opens, click Finish. Your installation is
complete.
7. Continue to “Appendix A: Wireless Adapter
Configuration” on page 12 to configure the
adapter to work with your 2Wire gateway.
Installing Drivers for Windows ME
1. Power on your computer. Insert your 2Wire
Wireless Installation CD into your CD-ROM
drive.
2. When the Add New Hardware Wizard window
opens, select Automatic search for a better
driver (Recommended), and click Next.
8
3. After the driver files are copied, click Finish.
4. If the System Settings Change window opens,
click Yes to restart your computer. Your
installation is complete.
5. Continue to “Appendix A: Wireless Adapter
Configuration” on page 12 to configure the
adapter to work with your 2Wire gateway.
