3Com 486 Bedienungsanleitung

486 Network Management

Card

Network Application Card

Getting Started Guide

Part No. 1.024.1280-00

http://www.3com.com/

486 Network Management

Card

Network Application Card

Getting Started Guide

Part No. 1.024.1280-00

3Com Corporation

5400 Bayfront Plaza

Santa Clara, California

95052-8145

in any form or by any means or used to make any derivative work (such as translation, transformation, or

adaptation) without written permission from 3Com Corporation.

3Com Corporation reserves the right to revise this documentation and to make changes in content from time

to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.

3Com Corporation provides this documentation without warranty of any kind, either implied or expressed,

including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

3Com may make improvements or changes in the product(s) and/or the program(s) described in this

documentation at any time.

UNITED STATES GOVERNMENT LEGENDS:

If you are a United States government agency, then this documentation and the software described herein are

provided to you subject to the following:

United States Government Legend: All technical data and computer software is commercial in nature and

developed solely at private expense. Software is delivered as Commercial Computer Software as defined in

DFARS 252.227-7014 (June 1995) or as a commercial item as defined in FAR 2.101(a) and as such is provided

with only such rights as are provided in 3Com’s standard commercial license for the Software. Technical data is

provided with limited rights only as provided in DFAR 252.227-7015 (Nov 1995) or FAR 52.227-14

(June 1987), whichever is applicable. You agree not to remove or deface any portion of any legend provided

on any licensed program or documentation contained in, or delivered to you in conjunction with, this

User Guide.

Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may

not be registered in other countries.

3Com and the 3Com logo are registered trademarks of 3Com Corporation.

Microsoft, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation.

Other brand and product names may be registered trademarks or trademarks of their respective holders.

YEAR 2000 INFORMATION:

For information on Year 2000 compliance and 3Com products, visit the 3Com Year 2000 web page:

http://www.3Com.com/products/yr2000.html

CONTENTS

1OVERVIEW

Contacting 3Com............................................................................. 1-1

Document Conventions....................................................................1-2

Product Description ..........................................................................1-3

Product Compatibility ....................................................................... 1-3

2INSTALLATION

Installation Tools............................................................................... 2-1

Installation Procedure ....................................................................... 2-1

ATROUBLE CLEARING AND TECHNICAL SPECIFICATIONS

Trouble Clearing ...............................................................................A-1

NMC LEDs...................................................................................A-1

RN/FL LED Diagnostics .................................................................A-2

Critical Failure Debug Procedure..................................................A-2

Technical Specifications ....................................................................A-3

Certification ................................................................................A-3

Regulatory Compliance Statements .............................................A-3

United States .........................................................................A-3

FCC Part 15 Compliance Statement .......................................A-3

Processor.....................................................................................A-3

Operational Memory ...................................................................A-3

Data Retention Method...............................................................A-3

Current Draw ..............................................................................A-4

Environment................................................................................A-4

Shipping and Storage.............................................................A-4

Operating ..............................................................................A-4

Physical Dimensions ....................................................................A-4

BDRAM OR FLASHROM UPGRADE INSTALLATION

DRAM OR FLASHROM UPGRADE INSTALLATION...............................B-1

1OVERVIEW

This chapter provides an overview of:

■Contacting 3Com

■Document conventions

■Product description

■Product compatibility

Contacting 3Com Call the appropriate toll free number listed below for technical support.

For European countries that do not have a toll free number listed,

call +31 30 602 9900.

Country Toll Free Number Country Toll Free Number

Austria 06 607468 Netherlands 0800 0227788

Belgium 0800 71429 Norway 800 11376

Canada 1800 2318770 Poland 00800 3111206

Denmark 800 17309 Portugal 0800 831416

Finland 0800 113153 South Africa 0800 995014

France 0800 917959 Spain 900 983125

Germany 0800 1821502 Sweden 020 795482

Hungary 00800 12813 Switzerland 0800 553072

Ireland 1800 553117 UK 0800 966197

Israel 0800 9453794 United States 1800 2318770

Italy 1678 79489 All Other Locations

(Outside Europe)

1847 7976600

1-2 CHAPTER 1: OVERVIEW

Refer to the Total Control Hub Documentation CD-ROM for more

information regarding product warranty.

For information about Customer Service, including support, training,

contracts, and documentation, visit our website at

http://totalservice.3com.com

Document

Conventions

These tables list conventions used throughout this guide.

Icon Notice Type Description

Information note Information that contains important features or

instructions.

Caution Information to alert you to potential damage to a

program, system, or device.

Warning Information to alert you to potential personal injury

or fatality. May also alert you to potential electrical

hazard.

ESD Information to alert you to take proper grounding

precautions before handling a product.

Convention Description

Text represented as a

screen display This typeface represents displays that appear on your

terminal screen, for example:

Netlogin:

Text represented as

commands This typeface represents commands that you enter for

example:

setenv TCMHOME directory

This guide always gives the full form of a command in

uppercase and lowercase letters. However, you can

abbreviate commands by entering only the uppercase letters

and the appropriate value. Commands are not case-sensitive.

Text represented as

menu or sub-menu

names.

This typeface represents all menu and sub-menu names

within procedures, for example:

On the File menu, click New.

Product Description 1-3

Product

Description

The Network Management Card (NMC) has the ability to manage all of

the devices in the Total Control chassis under the direction of any

computer running the console software. This computer is referred to as

the management station (MS).

Two protocols are involved in the implementation of these management

functions:

■Simple Network Management Protocol (SNMP)

■Allows the NMC to communicate with the MS.

■The NMC acts as a proxy agent to the chassis Network Application

Cards (NACs) not running SNMP software directly.

■Management Bus Protocol (MBP)

■Allows the NMC to communicate with and provide configuration

management for the installed devices.

■Supports automatic configuration, status queries, software

upgrades, and event management via the NMC.

Product

Compatibility

Two versions of the 486 NMC NAC are available.

■The 4meg NMC NAC — Support for all non-HiPer applications.

■The 16meg NMC NAC — Support for all standard applications as well

as HiPer Arc and HiPer DSP.

For information on upgrading an existing 4meg NMC, see Appendix B.

2INSTALLATION

This chapter contains Network Management Card (NMC) Network

Application Card (NAC) installation information.

Installation Tools To install this NAC in the Total Control chassis, you need a #2 Phillips and

flat-head screwdriver.

Installation

Procedure

To install this NAC:

ESD: To reduce the risk of electrostatic discharge (ESD), take proper

grounding precautions before handling the NAC.

1Install the Network Interface Card (NIC) corresponding to this NAC. Refer

to the NIC’s Getting Started Guide for more information.

2-2 CHAPTER 2: INSTALLATION

2Configure the NAC via the DIP switches.

DIP Switch Number Function

1,2 NMC NIC CH1 Port Rate

DIP 1 DIP2 Selects

OFF OFF 9600bps

OFF ON 19200bps

ON OFF 38400bps

ON ON 57600bps

3,4 NMC NIC CH2 Port Rate

DIP 1 DIP2 Selects

OFF OFF 9600bps

OFF ON 19200bps

ON OFF 38400bps

ON ON 57600bps

5OFF: NMC reads chassis configuration from NVRAM on

power up.

ON: NMC reads factory default chassis configuration

from EEPROM.

6OFF: Password feature is disabled and CH1 acts as UI

port only.

ON: Password feature is enabled and CH1 can be

configured to act as UI or second SLIP port.

7–10 Reserved

Installation Procedure 2-3

Install the NAC with or without power applied to the chassis.

3Select a slot at the front of the Total Control chassis for installing the

NAC.

Install this NAC in slot(s): 1–17

For managed chassis, slot 17 is reserved for the Network Management

Card (NMC) NAC.

4Use a #2 Phillips screwdriver to remove the safety panel covering this slot.
