Allied Telesis www.alliedtelesis.com

Datasheet | integrated Multiservice Access Platform

ADSL24A

AT-TN121-A 24 Port ADSL2+ Service Module (Annex A)

Allied Telesis’ iMAP family of integrated

Multiservice Access Platforms

Uncompromising ADSL

Performance for Demanding

Applications

The ADSL24 (Annex A) is a 24 port ADSL2+

service module for the Allied Telesis iMAP and

has been designed to meet the most

demanding broadband and

Triple Play

applications.The card’s Gigabit Ethernet

backplane link ensures that all 24 ports will

receivethe maximum of 26Mbps per port

without oversubscription. At the heart of the

card is a wirespeed Ethernet switch that is

designed for the most demanding traffic

applications: IP Multicast Video,Video on

Demand, voice, and data.

Each of the 24 subscriber ports can

simultaneously support any of the standard

ADSL modes - ADSL2+, G.DMT, S=1/2, or

T1.413 - on a per port basis. A powerful DSP

implements all ADSL algorithms and allows

future and emerging ADSL2+ features to be

added through simple software upgrades.

In ADSL2+ mode, a subscriber port can deliver

up to 26Mbps of downstream bandwidth -

enough to supportup to fiveset-top boxes of

standard digital video - plus headroom for VoIP

and data traffic.Traffic priority can be

differentiated by service type so that VoIP,

video, and data can be prioritized from a single

portbased on your business needs.

Performance You Can Depend On

Allied Telesis is the only broadband access

vendor that provides a complete end to end

ADSL solution. Service Providers can maximize

real world downstream rates and DSL reach

when they use the ADSL24 incorporating our

patent pending optimized interconnect system.

This unique system maximizes both revenue

and subscriber satisfaction.

Acomplete set of management counters

monitor ADSL performance at each end of the

link. Every performance monitor counter can be

assigned a threshold that will generate an alarm

if the threshold is exceeded.

Part of Allied Telesis’ IP Broadband

Access Family

Whether it is broadband ADSL2+, FTTH, POTS

or T1/E1 circuits, the iMAP family is the ideal

platform for last mile service delivery.The

ADSL24 (Annex A) line card can be used with

any of the iMAP family of carrier grade, IP

Multiservice Access platforms:

•iMAP 9700 (9RU, 17 service slots)

•iMAP 9400 (3RU, 7 service slots)

•MiniMAP 9100 (1RU, 3 service slots)

Provisioning, management, and diagnostics of

subscriber ports of subscriber ports can be

accomplished from either the iMAP command

line interface or the NMS.

The ADSL24 (Annex A) has been designed to

survivethe most rugged environmental

conditions. It can be confidently deployed in

either a central office or in outdoor enclosures

withstanding extremes of heat, cold, and light

exposure.

Allied T

elesis provides a large portfolio of FTTx,

Ethernet and xDSL transport and access

equipment. In addition, Allied Telesis provides a

complete set of xDSL and FTTx CPE solutions

in the form of Multi-Service Gateways, Layer 2/

Layer 3 switches, routers or media converters

to terminate the broadband link.

Key Features

•24 ADSL2+ ports

•ADSL Annex A

•1Gbps backplane link

•Automatic or manual selection of ADSL2+,

G.DMT, S=1/2, or T1.413 modes

•Flexible control of traffic priorities for voice,

video, data applications

•Video-optimized

QoS

•Four Queues

•Priority scheduling

•VC to VLAN Mapping

Security

•MAC limiting (up to 64)

•MAC flooding – VLAN-based

Services Supported

•High Speed Internet

•VoIP

•IPTV

•Business VPN

•Gaming

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000048 Rev. D

ADSL24A |AT-TN121-A 24 Port ADSL2+ Service Module (Annex A)

ADSL24A

Model Description Part #

ADSL24A 24 ports, ADSL2+ Service Module, Annex A AT-TN-121-A

Ordering Information

Interface Specifications

Number of ports: 24

Backplane capacity: 1Gbps

Physical design: Front Access

RJ-21 (Female)

ADSL Standards

ITU-T G.992.1 (ADSL, G.DMT, T1.413)

ITU-T G.992.5 (ADSL2+)

S=1/2

Annex A (ONLY)

Port Specifications

Number of VCs per port: 4

Priority queues per VC: 8

Dropped packet counter

Full traffic classifier support

Full traffic classifier action support

ARP Filtering

Ingress Metering: 1Mbps increment

Peak Cell Rate Limiting per VC

Ingress Max Burst Size: 64kbps

Egress Max Burst Size: 64kbps

Protocols and Specifications

IEEE 802.1Q VLAN Bridging

IEEE 802.1p Prioritization

IETF RFC 1112 IP Multicasting/IGMP Snooping v1

IETF RFC 2236 IP Multicasting/IGMP Snooping v2

DHCP RelayAgent option 82 (RFC 3046)

Power Requirements

Maximum Power: 45W

Environmental Specifications

Operating Temp: -40C to 65C

Storage Temp: -40C to 75C

Relative Humidity: 5% to 95%, non-condensing

Regulatory Approvals

FCC Part 15 Class A/ANSI C63.4

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

VCCI Class A; ITE/ CISPR 22:1997 Class A

EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A

EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998

EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996

EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995

EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999

UL/cUL 60950: IEC60950

NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2

USDA RUS

iMAP 9x00 Chassis

Model Description Part #

iMAP 9700 17-slot chassis with DC power with faceplates AT-TN-250GF

iMAP 9700 17-slot chassis with DC power without faceplates AT-TN-250G

iMAP 9400 7-slot chassis with DC power with faceplates AT-TN-251GF

iMAP 9400 7-slot chassis with DC power without faceplates AT-TN-251G

MiniMAP 9101 3-slot mini chassis with DC power AT-TN-9101-A-80

MiniMAP 9102 3-slot mini chassis with AC power AT-TN-9102-A-XX*

iMAP Common Control

Model Description Part #

CFC24 24GbE switch controller card AT-TN-401-B

GE3 3x GbE WAN interface card AT-TN-301-A

CFC12 12GbE switch controller card AT-TN-408-A

Related ADSL2+ CPE

Model Description Part #

RG624 ADSL2+ intelligent Multiservice Gateway,

4xLAN (AnnexA) intelligent

AT-RG624A

RG634 ADSL2+ intelligent Multiservice Gateway,

4xLAN, 2 x FXS (Annex A)

AT-RG634A

RG644 ADSL2+ intelligent Multiservice Gateway,

4xLAN, 1 x ISDN BRI (Annex A)

AT-RG644A

ADSL2+ Modem ADSL2+ Modem, 1 x LAN (Annex A) COR-DSL200A

*Where XX = 10 for U.S. power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord
