3D Systems Allevi 3 Bedienungsanleitung

Allevi 3

User Guide - 1.1.2

BUILD WITH LIFE

SETTING UP YOUR PRINTER 11

Table of Contents

WELCOME

SPECIFICATIONS

WARNINGS

GETTING STARTED

WHAT`S IN THE BOX

PRINT BED DIMENSIONS

ALLEVI 3 DIAGRAM

SETTING UP YOUR SOFTWARE

CONNECTING TO YOUR PRINTER

START PRINTING

YOUR FIRST BIOPRINT

MAINTENANCE & TROUBLESHOOTING

TROUBLESHOOTING AND CONTACT US

WELCOME

SPECIFICATIONS

MECHANICAL

Construction:Aluminum Frame

Build Surface: Tissue Culture Plates

XYZ Position Precision: 1 micron

Weight: 40 lbs (18.1 kg)

Dimensions: 18.4 x 15.2 x 14.2 in

46.7 x 38.8 x 36.0 cm

ELECTRICAL

Power/Voltage Requirements: 6 Amp/

AC 110V - 220V

Desktop Adaptor

Supply Voltage: 24V DC, 16.7A

SOFTWARE

Bundle: Allevi Bioprint Online

Connectivity: WiFi, Ethernet,

Allevi Wireless Adapter

Supported File Types: STL, gcode

Operating System: Windows, MacOSX, Linux

PRINTING

Print Technology: Extrusion Printing

Pressure Range: 1- 120 PSI (7- 827 kPa)

Pressure Variance: +/- 0.1 PSI

Build Volume: 3.5 x 2.4 x 5.1 in (42.8 in³)

9 x 6 x 13 cm (702 cm³)

CORE PRINTHEAD

Max Temp (E1): 160ºC

Min Temp: 4ºC

LED Range: 365 nm and 405 nm

BUILD PLATE

Max Temp: 60ºC

Min Temp: Room temperature

Allevi 3 | User Guide

HOT SURFACE WARNING

This symbol indicates potential hot surfaces. The Allevi 3 and its extruder(s)

can become hot during the printing process, whether heating or cooling.

Always allow time for the extruder to cool before handling.

WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol indicates that when the end-user wishes to discard this product, it

must be sent to separate collection facilities for recovery and recycling.

UV WARNING

This symbol indicates potential ultraviolet light exposure. The Allevi 3’s extru-

der(s) can emit wavelengths of 365-405nm. Wear UV glasses when operating

and avoid eye and skin exposure to unshielded product.

CE MARKING

This mark indicates conformity with health, safety, and environmental protec-

tion standards for products sold within the European Economic Area.

SGS MARKING

This mark means a product has been independently tested and certiﬁed to

meet recognized standards for safety or performance.

WARNINGS

Allevi 3 | User Guide

•Indoor use

•Altitude ofoperation: <2000m

•Operating temperature: 5- 40ºC

•Relative humidity: 20-80% (up to 31ºC), decreasing linearly to 50% at 40ºC

•Pollution degree of the environment: Pollution degree 2

The Allevi 3 should be stored in the following conditions:

•Temperature: 5- 40ºC

•Humidity: 20- 80% (up to 31ºC), decreasing linearly to 50% at 40ºC

•WARNINGS

•The Allevi3includes moving parts that can cause injury.Never reach inside theprinter while it is

in operation.

•Do not leave the printer unattended while it is in operation.

•Always wear safety goggles when using the printer.

•Do not mount the Allevi 3 on or near a surface of ﬂammable material.

•There are possible hazards of explosion, implosion, or the release of toxic or ﬂammable gases

arising from materials being heated.

•If you are working with hazardous materials, you should set up theappropriate extraction system

and/or ventilation requirements.

•You are responsible for appropriate decontamination in case of spillage of hazardous materials

on or inside ofthe equipment.

•If the equipment is used in amanner not speciﬁed by Allevi, the protection provided by the equip-

mentmay beimpaired.

Allevi 3 | User Guide

ENVIRONMENTAL CONDITIONS

The Allevi 3 should be operated in the following conditions:

MAINTENANCE AND CLEANING INSTRUCTIONS

•Recommended decontamination is spraying with 70% ethanol while the printer is powered down,

turning your hood fan on for 30 minutes, and wiping down the printer after at least 10 minutes.

Additionally, 30 minutes of UV decontamination may be used to supplement the ethanol wipe down.

•Do not over-spray ethanol directly into the electronics of the Allevi 3. Spray a towel, then wipe the

printer down with the towel. Do not use decontamination or cleaning agents which could cause a

hazard as a result of a reaction with parts of the equipment or with material contained in it.

SERVICE INSTRUCTIONS

Allevi bioprinters should be serviced by Allevi or Allevi-certified personnel.

To request servicing, email support.all[email protected]

GETTING STARTED

Allevi 3 | User Guide

WHAT’S IN THE BOX

Allevi 3 bioprinter

1Starter bioink kit

Power supply

3Air compressor*4Compressor hose5

*Air compressor arrives separately

28mm

77.50mm

Diameter

88.30mm

Allevi 3 | User Guide

PRINT BED DIMENSIONS
