vs-vx24 VESA Adapter

Assembly instructions

The VESA adapter is compatible with the following products from VIEWSONIC

(viewsonic.com): VX2458-C-MHD Curved Gaming Monitor.

The VESA adapter allows you to conveniently mount your VIEWSONIC brand

monitor to a monitor arm with a VESA hole pattern (75 x 75mm). Use the included

screws and nuts.

If you want to mount your VESA adapter directly to the wall, use suitable screws

and dowels. (not included in the scope of delivery).

Assembly instructions

Assembly instruction

Step 1

Place your monitor flat on a soft and safe surface. Now

remove the base by unscrewing the screw underneath the

base. (Figure 1)

Figure 1

Step 2

Now move the foot to the upper stop, this is important so

that the monitor later hangs straight on your monitor arm /

VESA arm. (Figure 2)

Figure 2

Step 3

Now plug the 3idee VESA adapter onto your monitor. (Figure

Make sure the black plastic piece is properly seated on the

monitor base.

Figure 3

Step 4

This is how the correct position of the VESA adapter looks on

the base. (Figure 4)

Figure 4

3Assembly instructions

Step 5

Now it is important that all holes of the VESA adapter are

aligned with the hole in the monitor base. (Figure 5)

Hold the VESA adapter in this position to proceed to the next

step.

Figure 5

Step 6

Now take the M6x25 + washer (largest screw in the

package) and screw it into the VESA adapter as shown.

(Figure 6)

Figure 6

Step 7

We recommend you to do this step with a second

person.

Now take the monitor + VESA adapter and screw it to your

VESA arm. (Figure 7)

Figure 7

Step 8

Please make sure that all 4 screws are tight. (Figure 8)

Figure 8

Assembly instructions

Safety instructions

General notes

Make sure that all screws are tight and that the monitor audibly clicks into place during installation (if

available).

The material of the adapter is not heat resistant. Avoid direct heat around the adapter such as PC

exhaust or direct sunlight in summer.

PLA is UV resistant but not suitable for high temperatures.

Avoid jerky movements (pulling, tearing) on the PC monitor. This can affect the performance of the

VESA adapter.

Do not subject the PC monitor to excessive loads such as leaning or pushing. This can impair the

performance of the VESA adapter.

Material Notes

The adapter is made of high-quality polylactide (PLA) plastic. PLA is both a colorfast and UV-resistant

material and has low flammability. Polylactide has a low temperature resistance of approx. 45°C-55°C

and is therefore not suitable for use in the vicinity of direct heat and heat sources.

We wish you a lot of fun with your product.

Your 3idee Team

Responsible for this content:

3idee Technologies S.à r.l

5, ZA Um Lenster Bierg

L-6125 Junglinster

Luxembourg
