3rd Eye AWTC60WP Bedienungsanleitung

WARNING

Failure to follow all instructions and safety precautions in this

manual, in the vehicle and body manufacturers' manuals and

on the safety decals attached to the vehicle, body and this

product could result in serious injury or death to operators,

service technicians or bystanders and/or damage to property.

DO NOT operate the vehicle or install this product before you

READ and UNDERSTAND the vehicle Operation Manual, this

manual and other applicable manufacturers' manuals, and all

safety decals. This product must be installed by certified

technicians/installers familiar with the vehicles on which they

will be making the installation.

AWTC60WP HD

Camera

USER MANUAL

ISSUED OCTOBER 2018

TABLE OF CONTENTS

Printed in U.S.A.

Issued October 2018

Table of Contents

Camera

........................................................................................................................................................................................3AWTC60WP

...................................................................................................................................................................................4

PrecautionsPrecautionsPrecautions

...................................................................................................................................................................................5

Camera Cable Pin FunctionCamera Cable Pin FunctionCamera Cable Pin Function

...................................................................................................................................................................................6

DIN Pin Waterproof AssuranceDIN Pin Waterproof AssuranceDIN Pin Waterproof Assurance

...................................................................................................................................................................................7

How to Connect the CableHow to Connect the CableHow to Connect the Cable

...................................................................................................................................................................................8

Features and SpecificationFeatures and SpecificationFeatures and Specification

...................................................................................................................................................................................10

InstallationInstallationInstallation

...................................................................................................................................................................................13

DimensionsDimensionsDimensions

...................................................................................................................................................................... 14

Index

USER MANUAL

Printed in U.S.A.

Issued October 2018

SAFETY PRECAUTIONS

Federal Communications Commission (FCC) Statement

This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio / TV technician for help.

You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void

your authority to operate the equipment.

NOTICE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference and,

2. This device must accept any interference received, including interference that may cause undesired operation

USER MANUAL

Printed in U.S.A.

Issued October 2018

PRODUCT DOCUMENTATION UPDATES

Thank you for purchasing our product. Please read this User Manual before using the product. All product documentation is

subject to change without notice. Please go to www.3rdeyecam.com to get the most current documentation for your 3rd Eye

products.

USER MANUAL

AWTC60WP

Printed in U.S.A.

Issued October 2018

AWTC60WP HD CAMERA

COLOR CAMERA

USER MANUAL

ISSUED OCTOBER 2018

3E-AWTC60WP-UM-1018

USER MANUAL

AWTC60WP

Printed in U.S.A.

Issued October 2018

Precautions

PRECAUTIONS

Before attempting to hook up and operate, please read this manual.

1. To reduce the risk of electronic shock, do not remove cover or back. No user serviceable parts inside. Refer servicing to

qualified service personnel.

2. Never point the camera toward the sun. It should not expose the lens directly to sun or strong light as this may damage

the pick-up device.

3. Handle this camera with care. Avoid severe shock or impact to the camera as it contains sensitive parts which can be

damaged by improper handling.

4. The allowance temperature range for operation of this camera is between -20 to 65° (-4 to 146°F) and the allowable

humidity is 85% maximum. If the camera is to be placed in an extremely dusty location, a special housing may be

necessary to protect the camera and lens.

USER MANUAL

AWTC60WP

Printed in U.S.A.

Issued October 2018

Camera Cable Pin Function

CAMERA CABLE PIN FUNCTION

Video

GND (OPTION)

N/A

Power

GND

Shield GND

USER MANUAL

AWTC60WP

Printed in U.S.A.

Issued October 2018

DIN Pin Waterproof Assurance

DIN PIN WATERPROOF ASSURANCE

NOTE: Wrap the whole cable connection from one end to another end with the Weather-Sealer Strip (NOT SUPPLIED) to

ensure adequate insulation against water.

USER MANUAL

AWTC60WP

Printed in U.S.A.

Issued October 2018

How to Connect the Cable

HOW TO CONNECT THE CABLE

Follow the instructions below when connecting the cable and camera.

STEP 1:

Line up the position marks on the male connector and female connector as shown in image below.

STEP 2:

Rotate the ring on the male connector by hand as shown in image below.

STEP 3:

Then screw in securely to the threads on the female connector.

USER MANUAL

AWTC60WP

Printed in U.S.A.

Issued October 2018

Features and Specification

FEATURES AND SPECIFICATIONS

A. Key Features

1/3" color CMOS sensor

Electronic auto iris control

AWB(Auto White Balance)

Back light compensation (BLC on)

IP 69K

10G shock/vibration

G-Force Rating : 30

Isolated ground

Automatic heater

Double window glasses & replaceable outer glass

B. Optical

Lens : F=2.9 H:96° V:72° Diagonal 120°
