4gon ENH202 Bedienungsanleitung

WIRELESS ACCESS POINT / CLIENT BRIDGE

Model: ENH202

User Manual

Version: 1.0

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

Table of Contents

1 PRODUCT OVERVIEW ......................................................................................................................................................... 6

1.1 FEATURES.......................................................................................................................................................................... 6

1.2 BENEFITS .......................................................................................................................................................................... 8

1.3 PACKAGE CONTENTS ......................................................................................................................................................... 9

1.4 SYSTEM REQUIREMENT...................................................................................................................................................... 9

1.5 HARDWARE OVERVIEW ..................................................................................................................................................... 9

1.6 UNDERSTANDING THE ENH202 LEDS............................................................................................................................ 10

2 INSTALLATION.....................................................................................................................................................................11

2.1 PRE-INSTALLATION GUIDELINES........................................................................................................................................11

2.2 INSTALLING THE ENH202................................................................................................................................................11

3 WIRELESS NETWORK MODES ........................................................................................................................................ 12

3.1 ACCESS POINT MODE ..................................................................................................................................................... 12

3.2 ACCESS POINT WITH WDS FUNCTION MODE.................................................................................................................. 13

3.3 CLIENT BRIDGE MODE .................................................................................................................................................... 14

3.4 WDS BRIDGE MODE ...................................................................................................................................................... 15

3.5 CLIENT ROUTER MODE ................................................................................................................................................... 16

4 CONFIGURING YOUR COMPUTER FOR TCP/IP.......................................................................................................... 18

4.1 CONFIGURING MICROSOFT WINDOWS 7......................................................................................................................... 18

4.2 CONFIGURING MICROSOFT WINDOWS VISTA .................................................................................................................. 20

4.3 CONFIGURING MICROSOFT WINDOWS XP ...................................................................................................................... 21

4.4 CONFIGURING APPLE MAC OS X.................................................................................................................................... 22

4.5 LOGGING INTO THE ENH202.......................................................................................................................................... 23

5 STATUS.................................................................................................................................................................................. 25

5.1 SAVE /LOAD................................................................................................................................................................... 25

5.2 MAIN ............................................................................................................................................................................. 26

5.3 WIRELESS CLIENT LIST..................................................................................................................................................... 27

5.4 SYSTEM LOG ................................................................................................................................................................... 27

5.5 CONNECTION STATUS ..................................................................................................................................................... 28

5.6 DHCP CLIENT TABLE ...................................................................................................................................................... 28

6 SYSTEM................................................................................................................................................................................. 29

6.1 SWITCHING THE OPERATION MODE................................................................................................................................. 29

7 WIRELESS CONFIGURATION........................................................................................................................................... 30

7.1 WIRELESS SETTINGS........................................................................................................................................................ 30

7.1.1 Access Point Mode ........................................................................................................................................... 30

7.1.2 Client Bridge Mode .......................................................................................................................................... 33

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

7.1.3 WDS Bridge Mode............................................................................................................................................ 35

7.1.4 Client Router Mode.......................................................................................................................................... 37

7.2 WIRELESS SECURITY SETTINGS......................................................................................................................................... 39

7.2.1 WEP.................................................................................................................................................................... 39

7.2.2 WPA-PSK........................................................................................................................................................... 40

7.2.3 WPA2-PSK......................................................................................................................................................... 41

7.2.4 WPA-PSK Mixed ............................................................................................................................................... 42

7.2.5 WPA ................................................................................................................................................................... 43

7.2.6 WPA2 ................................................................................................................................................................. 44

7.2.7 WPA Mixed........................................................................................................................................................ 45

7.3 WIRELESS ADVANCED SETTINGS...................................................................................................................................... 46

7.4 WIRELESS MAC FILTER ................................................................................................................................................... 48

7.5 WDS LINK SETTINGS ...................................................................................................................................................... 49

8 LAN SETUP........................................................................................................................................................................... 50

8.1 IP SETTINGS ................................................................................................................................................................... 50

8.2 SPANNING TREE SETTINGS .............................................................................................................................................. 51

9 ROUTER SETTINGS ............................................................................................................................................................ 52

9.1 WAN SETTINGS.............................................................................................................................................................. 52

9.1.1 Static IP ............................................................................................................................................................. 52

9.1.2 DHCP (Dynamic IP) ......................................................................................................................................... 54

9.1.3 PPPoE (Point-to-Point Protocol over Ethernet) ............................................................................................ 56

9.1.4 PPTP (Point-to-Point Tunneling Protocol) .................................................................................................... 58

9.2 LAN SETTINGS (ROUTER MODE)..................................................................................................................................... 60

9.3 VPN PASS THROUGH...................................................................................................................................................... 61

9.4 PORT FORWARDING........................................................................................................................................................ 62

9.5 DMZ ............................................................................................................................................................................. 63

10 MANAGEMENT SETTINGS ............................................................................................................................................ 64

10.1 ADMINISTRATION ......................................................................................................................................................... 64

10.2 MANAGEMENT VLAN .................................................................................................................................................. 65

10.3 SNMP SETTINGS.......................................................................................................................................................... 66

10.4 BACKUP/RESTORE SETTINGS ......................................................................................................................................... 67

10.5 FIRMWARE UPGRADE .................................................................................................................................................... 67

10.6 TIME SETTINGS ............................................................................................................................................................. 68

10.7 LOG.............................................................................................................................................................................. 69

10.8 DIAGNOSTICS ............................................................................................................................................................... 70

11 NETWORK CONFIGURATION EXAMPLES.................................................................................................................. 71

11.1 ACCESS POINT.............................................................................................................................................................. 71

11.2 CLIENT BRIDGE MODE .................................................................................................................................................. 72

11.3 WDS BRIDGE MODE .................................................................................................................................................... 73

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

11.4 CLIENT ROUTER MODE ................................................................................................................................................. 74

APPENDIX A – TROUBLESHOOTING ................................................................................................................................75

A.1 PROBLEM SOLVING......................................................................................................................................................... 75

A.2 CONTACTING TECHNICAL SUPPORT................................................................................................................................. 76

APPENDIX B – SPECIFICATIONS ........................................................................................................................................ 77

APPENDIX C – GLOSSARY ................................................................................................................................................... 78

APPENDIX D – STATEMENTS OF CONFORMITY............................................................................................................ 84

D.1 –FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT........................................................................... 84

D.2 –INDUSTRY CANADA STATEMENT ................................................................................................................................... 85

D.3 –EUROPE DECLARATION OF CONFORMITY ...................................................................................................................... 86

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

About This Document

This document is written by EnGenius Inc. EnGenius Inc. the reserves the right to change this

document without notice and all rights are reserved. This document can only be used for the

configuration of EnGenius products.

This document is to characterize the EnGenius ENH202 Wireless Access Point & Client

Bridge. Please read the document carefully before setting up the ENH202. Any damage which

is caused by inappropriate use will not be covered under the warranty.

Formats

This document uses following symbols to indicate and highlight special messages.

Caution: This symbol represents a vital message and it is critical for the device

or settings.

Note: This symbol represents an important message for the settings.

Tip: This symbol represents an alternative choice that can save time or

resources.

Before you start__________________________________________________

The following equipment is required to setup the ENH202:

1. (1) Computer/Notebook and Internet access.

2. (2) Ethernet cables.

3. (1) EnGenius ENH202.

The equipment listed above is only for configuration of the ENH202, you will

need additional equipment to connect to the Internet and configuration will depend on your

current network infrastructure. Please refer to Chapter 2 for more information.

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

1 Product Overview

Thank you for using the ENH202. It is a powerful and enhanced business-class product with 4

multi-functions: Access Point, Client Bridge, WDS, and Client Router.

EnGenius’ ENH202 uses the latest wireless standard, 802.11n, which allows for faster wireless

throughput. The ENH202 affords a great advantage to minimize the time and cost which is

required to expand your network. It operates at 2.4GHz and is also backwards compatible with

802.11a networking equipment.

The ENH202 is easy to install almost anywhere with included proprietary Power over Ethernet

adapter for quick outdoor installation. In addition, the ENH202 can manage power level

control, and it features narrow bandwidth selection, traffic shaping and real-time RSSI

indication. The ENH202 fully supports wireless encryption including Wi-Fi Protected Access

(WPA-PSK/WPA2-PSK), (64/128/152)-bit WEP Encryption, and IEEE 802.1x with RADIUS.

Additionally, the ENH202 is an ideal choice to pair with the ENH202 in a Access Point – Client

Bridge or WDS Bridge – WDS Bridge topology.

The ENH202 utilizes a proprietary PoE adapter. Only use the supplied PoE

adapter. Damage may occur if another PoE adapter is used.

1.1 Features

The following list describes the design and scope of the ENH202 made possible through the

power and flexibility of wireless LANs:

a) Difficult-to-wire environments

There are many situations where wires cannot be laid easily. For example, historic

and older buildings as well as open areas and cross-street architectures make the

installation of LANs either impossible or very expensive.

b) Temporary workgroups

Consider situations in parks, athletic arenas, exhibition centers, disaster-recovery,

temporary offices and construction sites where one wants a temporary WLAN

established and removed at a future date. The ENH202 is easy to place into and

remove from production.

c) The ability to access real-time information

Doctors and nurses, point-of-sale employees, and warehouse workers can access

real-time information while dealing with patients, serving customers, and

processing information.

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

d) Frequently altered environments

Show rooms, meeting rooms, retail stores, and manufacturing sites are prime

examples where frequently rearranged workplaces are suited for wireless LANs.

e) Wireless extensions of Ethernet networks

Network managers in dynamic environments can minimize the overhead caused by

moves, extensions to networks, and other changes by utilizing wireless LANs.

f) Wired LAN backup

Network managers may implement wireless LANs to provide redundancy for

mission-critical applications which are implemented on wired networks.

g) Training and educational facilities

Training sites at corporations and students at universities use wireless connectivity

to afford access to information, information exchanges, and learning.

Features

High Speed Data Rate

Up to 300 Mbps

Capable of handling heavy data payloads such as HD video

streaming

High Output Power up

to 29 dBm Extended range and excellent coverage

IEEE 802.11a/n

Compliant Fully interoperable with IEEE 802.11 a/n compliant devices

Multi-Function Users can use different modes in various environments

Support RSSI

Indicator (CB mode) Users can select the best signal to connect with AP efficiently

Power-over-Ethernet Flexible Access Point locations and cost savings (Note: The

ENH202 includes a proprietary PoE adapter.)

Support Multi-SSID

function (4 SSID) in

AP mode

Allow clients to access different networks through a single

access point and assign different policies and functions for each

SSID

WPA2/WPA/ WEP/

IEEE 802.1x support Full support for all types of current wireless security standards

MAC address filtering

in AP mode Ensure secure network by enforcing network access control lists

PPPoE/PPTP function

support (AP

Router/CR mode)

Easy to access Internet via ISP service authentication

SNMP Remote

Configuration

Management

Allow administrators to remotely configure or manage the

Access Point.

QoS (WMM) support Enhance user performance and density

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

1.2 Benefits

Access Point Mode Use this feature to setup the access point’s configuration

information. It supports transmit power and channel adjustments.

Clients can access the network with different regulatory settings

and automatically change to the local regulations.

Client Bridge Mode Use this feature to connect to an Access Point, enabling WAN

sharing.

WDS Mode Use this feature to link multiple APs in a network; All associated

clients from any AP can communicate with each other like in

ad-hoc mode.

Client Router Mode Clients connect wirelessly to an AP and transmit data through AP

to access the Internet.

Multiple SSIDs ENH202 supports up to 4 SSIDs on your access point. The

following options can be set to each SSID:

-Public or private SSID

-Authentication

-VLAN identifier

-RADIUS accounting identifier

-Profile isolation for infrastructure network

VLAN Specify a VLAN number for each SSID to separate the services

among clients.

QoS Use this feature to limit the incoming or outgoing throughput.

Wi-Fi Protected Access Wi-Fi Protect Access is a standard-based interoperable security

enhancement that increases the level of data protection and

access control for existing and future wireless LAN systems. It is

compatible with IEEE 802.11i standard. WPA leverages TKIP and

802.1X for authenticated key management.

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

1.3 Package Contents

Open the package carefully, and make sure that none of the items listed below are missing.

Do not discard the packing materials; in case of return, the unit must be shipped in its original

packaging.

(1) Wireless Access Point / Client Bridge (ENH202)

(1) 24V/1.0A Power Adapter

(1) PoE Injector (EPE-24R)

(1) Mounting Kit with Mast-Mount Strap Special Screw Set

(1) QIG

(1) CD (User Manual)

Using a power adapter other than the one included with the ENH202 may

cause damage to the device.

1.4 System Requirement

The following conditions are the minimum system requirements.

A computer with an Ethernet interface and operating under Windows XP, Vista, 7 or

Linux.

An Internet browser that supports HTTP and JavaScript.

1.5 Hardware Overview

Physical Interface - 1 x 10/100 LAN Port with PoE support

- 1 x 10/100 LAN port

- 1 x Reset button

Maximum Wireless Data rate - 300 Mbps

LEDs status - Power Status

- LAN (10/100Mbps)

- WLAN (Wireless is enabled)

- 3 x Link Quality (Client Bridge mode)

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

1.6 Understanding the ENH202 LEDs

The rear of the ENH202 has two groups of LEDs. One group, labeled INDICATORS, shows the

status of the device. The second group, LINK QUALITY, shows the strength of the link

between the ENH202 and the network. The following table describes the ENH202 LEDs.

LED Color Mode Status

Power Green OFF= ENH202 is not receiving power.

ON= ENH202 is receiving power.

LAN Green OFF = ENH202 is not connected to the network.

ON = ENH202 is connected to the network, but not sending or

receiving data.

Blink = ENH202 is sending or receiving data.

WLAN Green Access Point

or Client

Bridge

Mode

OFF = ENH202 radio is off and the device is not

sending or receiving data over the wireless LAN.

ON = ENH202 radio is on, and the device is not

sending or receiving data over the wireless LAN.

Blink = ENH202 radio is on, and the device is

sending or receiving data over the wireless LAN.

Link Quality See Status column Access Point

or Client

Bridge

Mode

Shows the strength of the link between the

ENH202 and the network.

G = good quality (green).

Y = medium quality (yellow).

R = poor or no link (red).

4Gon www.4Gon.co.uk [email protected] Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299

Inhaltsverzeichnis

Andere 4gon Drahtloser Zugangspunkt Handbücher

4gon

4gon ECB9500 Bedienungsanleitung

Beliebte Drahtloser Zugangspunkt Handbücher anderer Marken

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Bedienungsanleitung

Ubiquiti

Ubiquiti NanoStation NSM2 Bedienungsanleitung

Cisco

Cisco Aironet 1550 Series Bedienungsanleitung

Aruba

Aruba IAP-335 Bedienungsanleitung

Advantek Networks

Advantek Networks AWN-AP-54MR Bedienungsanleitung

IP-COM

IP-COM AP355 Bedienungsanleitung

Buffalo

Buffalo AirStation WLA-L11G Bedienungsanleitung

EnGenius

EnGenius EnStationACv2 Bedienungsanleitung

D-Link

D-Link DAP-3662 Bedienungsanleitung

xG Technology

xG Technology xMax CN1300 Bedienungsanleitung

Widelink

Widelink ezWave WAP-1100 Series Bedienungsanleitung

Edimax

Edimax CAP1200 Bedienungsanleitung

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Bedienungsanleitung

Aruba

Aruba AP-203R Bedienungsanleitung

LuXout Shades

LuXout Shades LUXSHADE MOTION Bedienungsanleitung

CreatComm

CreatComm TB5F Bedienungsanleitung

SineDigital

SineDigital MW-1500AP(H) Bedienungsanleitung

TP-Link

TP-Link AP9650 V1 Bedienungsanleitung
