Ableconn USB3HD4KB Bedienungsanleitung

USB 3.0 to 4K HDMI Adapter



User's Manual



i

Table of Contents



SAFETYINSTRUCTIONS..........................................1

TRADEMARKS......................................................1

REGULATORYCOMPLIANCE.............................2

FCCCONDITIONS................................................2

CE....................................................................2

WEEEINFORMATION...........................................2

INTRODUCTION...............................................3

FEATURES...........................................................3

PACKAGECONTENTS............................................4

SYSTEMREQUIREMENTS.......................................4

PRODUCTOVERVIEW......................................5

SPECIFICATION....................................................6

CONNECTION..................................................8

INSTALLATION.................................................9

VERIFYINGTHEINSTALLATION...............................11

DISPLAYCONFIGURATION..............................13

DESCRIPTIONOFTHESETTINGS.............................14



ii

MULTI‐MONITORCONFIGURATION........................16

EXTENDEDMODE...............................................17

MIRRORMODE.................................................18

SETTHEPRIMARYMONITOR.................................19

WINDOWSSHORTCUT........................................19

UNINSTALLINGTHEDRIVER............................20

TECHNICALSUPPORT.....................................22



1

Beforeattemptingtoconnect,operateoradjustthisproduct,

pleasesaveandreadtheUser'sManualcompletely.Thestyle

oftheproductshowninthisUser'sManualmaybedifferent

fromtheactualunitduetovariousmodels.

Safety Instructions

Alwaysreadthesafetyinstructionscarefully:

KeepthisUser’sManualforfuturereference

Keepthisequipmentawayfromhumidity

Ifanyofthefollowingsituationarises,getthe

equipmentcheckedbyaservicetechnician:

- Theequipmenthasbeenexposedtomoisture.

- Theequipmenthasbeendroppedanddamaged.

- Theequipmenthasobvioussignofbreakage.

- Theequipmenthasnotbeenworkingwellor

cannotgetittoworkaccordingtotheUser’s

Manual.

Thisdocumentcontainsproprietaryinformation

protectedbycopyright.Allrightarereserved.Nopartof

thismanualmaybereproducedbyanymechanical,

electronicorothermeans,inanyform,withoutprior

writtenpermissionofthemanufacturer.

Trademarks

Alltrademarksandregisteredtrademarksarethe

propertyoftheirrespectiveownersorcompanies.



2

Regulatory Compliance

FCC Conditions

Thisequipmenthasbeentestedandfoundtocomply

withPart15ClassBoftheFCCRules.Operationis

subjecttothefollowingtwoconditions:(1)Thisdevice

maynotcauseharmfulinterference.(2)Thisdevice

mustacceptanyinterferencereceivedandinclude

interferencethatmaycauseundesiredoperation.

Thisequipmentisincompliancewiththerequirements

ofthefollowingregulations:EN55022:CLASSB

WEEE Information

For EU (European Union) member users: According to the

WEEE (Waste electrical and electronic equipment)

Directive, do not dispose of this product as household

waste or commercial waste. Waste electrical and electronic

equipment should be appropriately collected and recycled

as required by practices established for your country. For

information on recycling of this product, please contact

your local authorities, your household waste disposal

service or the shop where you purchased the product.



3

Introduction

TheUSB3.0to4KHDMIAdapterisadevicewhichenables

connectionto4KUltraHDdisplaydevicetoacomputer

usingUSB3.0port.ItwillmakeyourlegacyPCwithold

graphicscardtosupport4Kresolutioneasily.Besides,with

thisconvenientdesign,itcanconnectupto6display

devicestoacomputerwithoutinstallingextravideocards.

Simplyinstallthedriver,andplugintheUSBadapter,the

connectedmonitorwillbeenabledwithouttheneedto

reboottheoperatingsystem.



Systemperformanceisanimportantissuewhenusing

multiplemonitors.Anotherbenefitofthisadapteristhatit

occupieslittlecomputerresource;ensuringusersgetquality

displaywithoutcomprisingcomputerperformance.



IncorporatesHDMI®technology.

Features

SupportsHighResolutionupto3840x2160Pixels

BackwardscompatiblewithHD/Legacymonitors

Accessto4KUltraHDdisplaysforlegacyPCs

Supportsupto6USBdisplaysimultaneously

SupportsExtendandMirrormode

USBbus‐powered



4

Package Contents

USB3.0to4KHDMIAdapterx1

USBCable  x1

CD(DriverandUser’sManual)x1

QuickInstallationGuide x1



System Requirements

OperatingSystems:

Windows®

7/Windows®8/Windows®8.1



5

Product Overview

MicroUSBconnector:ConnecttoanavailableUSB

connectoronacomputer.



HDMIconnector:ConnecttoadesiredHDMIdevice,

including4KUltraHDdisplaymonitor.Toconnect

differenttypesofmonitors,youmayneeda

converter.

MicroUSB

Connector

HDMI

Connector



6

Specification

ConnectorHost

Interface

USB3.0

VideoOutputHDMIConnector

Host

Upstream

Link

USB3.0MicroBTypeConnector

ConnectivityUpto6adaptersonacomputer

PowerPowerModeBus‐powered

Power

Consumption

OperatingMode:370mAapprox.

Video Resolution640x480 720x400 720x480

768x576 800x600 832x624

800x480 848x480 1024x600

1024x768 1152x864 1152x870

1280x720 1280x768 1280x800

1280x960 1280x1024 1360x768

1366x768 1368x768 1400x1050

1440x900 1600x900 1600x1200

1680x1050 1920x1080 1920x1200

2048x1080 2048x1152 2048x1280

2048x1536 2560x1440 2560x1600

3840x2160

Notethatinterlacedmodesand

reducedblankingmodesarenot

supported.



7

Supported

DisplayMode

ExtendedDesktop(Default),

MirroredDesktop,PrimaryDisplay

Supported

Operating

System

Windows®7,Windows®8,

Windows®8.1

Physical

Properties

HousingABS(Plastic)

ColorBlack

Dimension75.5(L)x44(W)x13.9(H)mm

Weight30.2g

Working

Environment

Operation

Temperature

10~40degree

Storage

Temperature

‐20~70degree

ComplianceCE,FCC
