Ace Bayou X Rocker Bedienungsanleitung
0717901
9.84ft/3m
FEATURES
A-Control Panel
A1-Power On/Off Button Switch
A2-Power Indicator Light
A3-Volume Adjustment
A4-Bass Volume Adjustment
A5-9V DC Power Input Jack
A6-Headphone Plug in Jack
A7-Audio Input Jack
A8-Audio Output for linking multiple chairs
0.492ft/0.15m
A5 A6 A7 A8
B3
B4
B2
B1
3062.969.668:enohP:beWmoc.uoyabeca@ecivres:liamE?pleHdeeN www.thexrocker.com
B1-3m RCA Stereo to 3.5mm stereo plug cable(1 PC)
B2-INPUT:100-240V AC 50/60Hz
OUTPUT:9V DC 1.0A 12.6W Main POWER Adapter
(EFFICIENCY LEVEL: 115V )
B3-RCA female to female barrel adapter (2 PCS )
B4-0.15m RCA stereo female to 3.5mm stereo male cable (1PC)
Signal-to-Noise Rate(Amplifier): Subwoofer :>50dB
Satellite :>60dB
Frequency Response: 60Hz~20kHz
Distortion: Subwoofer: <2%(F=100Hz)
Satellite: <1%(F=1kHz)
Input: DC 9V/1.0A
B-Accessories Supplied
C-Audio Specification
*SOME PARTS MAY VARY SLIGHTLY
A1 A3 A4A2
READ BEFORE USAGE:
PICTURE OUT OF BOX
SET UP:
FUNCTIONS:
.
Ergonomi
Have the storage function while pull seat out.
c design with full back support.
Foldable construction for ease of storage and portability
Side control panel with volume, bass control, and input/output jacks.
3062.969.668:enohP:beWmoc.uoyabeca@ecivres:liamE?pleHdeeN www.thexrocker.com
Excessive sound pressure from earphones and headphones can cause hearing loss
Do not attempt to remove the cover or any components. Removal of the cover or tampering with components puts you
at risk for injury or death from electrical shock.
Excessive use of audio equipment could lead to hearing loss.
Children under the age of 13 should not use this product without adult supervision.
Strictly for indoor use. Do not expose to direct sunlight, moisture or extreme temperatures.
If cover becomes wet disconnect power immediately and don't use until completely dry.
1. Lift X Rocker out of box.
2. Open the backrest.
3. Unpack the power adapter and connect it to the main power outlet, then to the power jack on the control panel (A5).
4. Press the power button and confirm that the power indicator light (A2) is on.
5. Follow the connection diagrams. They show how to connect the X Rocker to the audio source of your choice .
6. Adjust the bass and volume levels to your preference
STORAGE POSITION
SITTING POSITION
MP3 / CD / DVD / GAMES / PSP
X Rocker
XBOX , XBOX 360 , PLAYSTATION 3 & WII
MTMTMT
red
white
red
white
red
white
red
white
3062.969.668:enohP:beWmoc.uoyabeca@ecivres:liamE?pleHdeeN www.thexrocker.com
white
red
green
X Rocker X Rocker
rekcoRXrekcoRX
To next chair
Most gamingconsolesareshipped fromthemanufacturerwithanAudio/VideoRCAcable.TheA/VRCAcablehasthreeRCA
plugs:avideoplug(yellow)andtwoaudioplugs(redand white). If yourgamingconsolecame withanA/VRCAcable,please
followtheinstructionssupplied by thegameconsolemanufacturerforsetting up your gamingconsoleandconnecting it to the
television. Pleasenotethat you mustleavetheredand whiteaudiojacks on theA/VcableUNCONNECTED.Oncetheconsole is
properlyconnected to yourTV,please followthediagramintheRocker Set-upguide to connectthe gaming
consoletotheXRocker.
illustrated X
If yourgamingconsole was shipped withacoaxialcable,insteadofanA/VRCAcable, you mustfollow an alternateset-up
procedure(coaxialcable is thesametype of cablethatisusedtoconnectaVCRtotheTV).Youwillquicklyrecognize if your gaming
consoleusesthistype of cable. It connectsthegamingconsoledirectly to thetelevisionandcarriesboththeaudioandvideosignal
overasinglecable. If your gamingconsoleusesacoaxialcable, you CANNOTconnectitdirectly to theXRocker.Instead, you must
UseanintermediaryA/Vdevice(such asaTV,VCR,DVD,TiVO,etc)Pleasefollowthesesteps:
a. ConnectyourgamingconsoletotheintermediaryA/Vdevice via thecoaxialcable.
b. ConnecttheXRocker to the'AudioOut'jackontheintermediaryA/Vdevice.
c. Followdiagram2in theXRocker Set-upguide to connecttheXRocker to theintermediaryA/Vdeviceand
finalizethesetup.
If yourgamingconsoleisattached to an HD TV withanHDMIcable.Youwillneedtoconnectthechairusingeithertheaudiooutjacks
on thebackofthe TV or by pluggingintotheheadphonejackonthefront of theTV.
- Unable to hear any sound fromtheXRocker -
1. Check to ensurethatthepoweradapter is properlyconnected. Whenproperlyconnected,theindicatorlightonthe
controlpanelshouldlightup. If theindicatorlightdoes not lightup,try to useanotherpoweroutlet in your home.
2. Makesurethepowerunitisturned on andindicatorlightonthecontrolpanel is lit. If it is not,pleasepressthepower
switchonthecontrolpanel.
3. Onceyou havesuccessfullycompleted 1. and2.pleasereviewtheXRockerillustratedset-upguide.Doublecheck
allaudioconnections.Finally,checkthatthe volume on the handremote is turned to an audiblelevel on boththe TV
andthechair.
4. If you havecompleted 1- 3 andstilldonot hearsound,tryconnectinganotheraudiosource(CDplayer,television,
VCRorgameconsole)and go throughthestepsagain.Stillnot working?Help is as easyas1,2,3:
.srewsnaQAFrofotoG.1
3. Callourcustomer servicedepartment at 866.969.2603 or 931.359.2603.Officehoursare8:30amto5:00pm
centralstandardtime.
www.thexrocker.com
3062.969.668:enohP:beWmoc.uoyabeca@ecivres:liamE?pleHdeeN www.thexrocker.com
