Acer AcerPower 6200 Montageanleitung

9;6\VWHP

User’s Guide

&RS\ULJKW

this publication may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language or computer

language, in any form or by any means, electronic, mechanical,

magnetic, optical, chemical, manual or otherwise, without the prior

written permission of this company.

'LVFODLPHU

This company makes no representations or warranties, either

expressed or implied, with respect to the contents hereof and

specifically disclaims any warranties, merchantability or fitness for any

particular purpose. Any software described in this manual is sold or

licensed "as is". Should the programs prove defective following their

purchase, the buyer (and not this company, its distributor, or its dealer)

assumes the entire cost of all necessary servicing, repair, and any

incidental or consequential damages resulting from any defect in the

software. Further, this company reserves the right to revise this

publication and to make changes from time to time in the contents

hereof without obligation to notify any person of such revision or

changes.

Intel is a registered trademark of Intel Corporation.

Pentium is a trademark of Intel Corporation.

Other brand and product names are trademarks and/or registered trademarks of their

respective holders.

iii

,03257$176$)(7<

,16758&7,216

1. Read these instructions carefully. Save these instructions for

future reference.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not

use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning.

4. Do not use this product near water.

5. Do not place this product on an unstable cart, stand, or table.

The product may fall, causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are

provided for ventilation; to ensure reliable operation of the product

and to protect it from overheating, these openings must not be

blocked or covered. The openings should never be blocked by

placing the product on a bed, sofa, rug, or other similar surface.

This product should never be placed near or over a radiator or

heat register, or in a built-in installation unless proper ventilation is

provided.

7. This product should be operated from the type of power indicated

on the marking label. If you are not sure of the type of power

available, consult your dealer or local power company.

8. This product is equipped with a 3-wire grounding-type plug, a plug

having a third (grounding) pin. This plug will only fit into a

grounding-type power outlet. This is a safety feature. If you are

unable to insert the plug into the outlet, contact your electrician to

replace your obsolete outlet. Do not defeat the purpose of the

grounding-type plug.

9. Do not allow anything to rest on the power cord. Do not locate

this product where persons will walk on the cord.

10. If an extension cord is used with this product, make sure that the

total ampere rating of the equipment plugged into the extension

cord does not exceed the extension cord ampere rating. Also,

make sure that the total rating of all products plugged into the wall

outlet does not exceed 15 amperes.

11. Never push objects of any kind into this product through cabinet

slots as they may touch dangerous voltage points or short out

parts that could result in a fire or electric shock. Never spill liquid

of any kind on the product.

12. Do not attempt to service this product yourself, as opening or

removing covers may expose you to dangerous voltage points or

other risks. Refer all servicing to qualified service personnel.

13. Unplug this product from the wall outlet and refer servicing to

qualified service personnel under the following conditions:

a. When the power cord or plug is damaged or frayed

b. If liquid has been spilled into the product

c. If the product has been exposed to rain or water

d. If the product does not operate normally when the operating

instructions are followed. Adjust only those controls that are

covered by the operating instructions since improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the product to normal condition.

e. If the product has been dropped or the cabinet has been

damaged

f. If the product exhibits a distinct change in performance,

indicating a need for service

14. Replace battery with the same type as the product's battery we

recommend. Use of another battery may present a risk of fire or

explosion. Refer battery replacement to a qualified serviceman.

15. Warning! Battery may explode if not handled properly. Do not

recharge, disassemble or dispose of in fire. Keep away from

children and dispose of used battery promptly.

16. Use only the proper type of power supply cord set (provided in

your keyboard/manual accessories box) for this unit. It should be

a detachable type: UL listed/CSA certified, type SVT/SJT, rated

6A 125V minimum, VDE approved or its equivalent. Maximum

length is 15 feet (4.6 meters).

&'5206DIHW\:DUQLQJ

DANGER

INVISIBLE RADIATION WHEN OPEN.

AVOID EXPOSURE TO BEAM.

VORSICHT

UNSICHTBARE LASERSTRAHLUNG WENN GEÖFFNET.

NICHT IN DEN STRAHL SEHEN.

ATTENTION

RADIATION DU FAISCEAU LASER INVISIBLE. EN CAS

D’OUVERTURE. EVITER TOUTE EXPOSITION AUX RAYONS.

VARO

AVATTAESSA OLET ALTTIINA NÄKYMÄTTÖMÄLLE

LASERSÄTEILYLLE ÄLÄ KATSO SÄTEESEEN.

VARNING!

OSYNLING LASERSTRÄLNING NÄR DENNA DEL ÄR ÖPPNAD.

BETRAKTA EJ STRÄLEN.

VARNING

OSYNLING LASERSTRÄLNING NÄR DENNA DEL ÄR ÖPPNAD.

STIRRA EJ IN I STRÄLEN.

ADVARSEL

LASERSTRÄLING VED ÄBNING. SE IKKE IND I STRÄLEN.

CLASS 1 LASER PRODUCT

APPAREIL A LASER DE CLASSE 1

LASER KLASSE 1

LOUKAN 1 LASERLAITE

PRODUIT LASER

CATEGORIE 1

vii

&DXWLRQRQ/LWKLXP%DWWHULHV

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only

with the same or equivalent type recommended by the manufacturer.

Discard used batteries according to the manufacturer’s instructions.

ADVARSEL!

Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.

Udskiftning må kun ske med batteri af samme fabrikat og type.

Léver det brugte batteri tilbage til leverandøren.

ADVARSEL

Eksplosjonsfare ved feilaktig skifte av batteri.

Benytt samme batteritype eller en tilsvarende

type anbefalt av apparatfabrikanten.

Brukte batterier kasseres i henhold til fabrikantens instruksjoner.

VARNING

Explosionsfara vid felaktigt batteribyte.

Anvãnd samma batterityp eller en ekvivalent typ som

rekommenderas av apparattillverkaren.

Kassera anvãnt batteri enligt fabrikantens instruktion.

VAROITUS

Päristo voi räjähtää, jos se on virheellisesti asennettu.

Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin.

Hävitä käytetty paristo valmistajan ohjeiden mukaisesti.

VORSICHT!

Explosionsgefahr bei unsachgemäßen Austausch der Batterie Ersatz

nur durch denselben oder einem vom Hersteller empfohlenem

ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des

Herstellers.

viii

)&&&ODVV%5DGLR)UHTXHQF\

,QWHUIHUHQFH6WDWHPHQW

Note:

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

4. Consult the dealer or an experienced radio/television technician

for help.

Notice 1:

The changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to operate

the equipment.

Notice 2:

Shielded interface cables, if any, must be used in order to comply with

the emission limits.

$ERXWWKLV0DQXDO

Purpose

This user’s guide aims to give you all the necessary information to

enable you to operate the system properly.

Manual Structure

This user’s guide consists of two chapters.

Chapter 1 System Board

This chapter describes the system board and all its major

components. It contains the system board layout, jumper

settings, cache and memory configurations, and information on

other internal devices.

Chapter 2 BIOS Utility

This chapter gives information about the system BIOS and tells

how to configure the system by changing the settings of the

BIOS parameters.

Conventions

The following are the conventions used in this manual:

Text entered by user Represents text input by the user.

Screen messages Denotes actual messages that

appear on the screen.

, etc. Represent the actual keys that you

have to press on the keyboard.

NOTE

Gives bits and pieces of additional

information related to the current

topic.

WARNING

Alerts you to any damage that

might result from doing or not doing

specific actions.

CAUTION

Gives precautionary measures to

avoid possible hardware or

software problems.

IMPORTANT

Reminds you to do specific actions

relevant to the accomplishment of

procedures.

TIP

Tells how to accomplish a

procedure with minimum steps

through little shortcuts.
