Hardware Specifications and Configurations 1-5

Hardware Specifications and Configurations

Features 0

The following is a brief summary of the computer’s many features:

Operating System 0

 Genuine Windows®7 Home Premium 64bit

Platform 0

 Intel®Core™ i3-370M/i3-380M/i3-390M processor (3 MB L3 cache, 2.40/2.53/2.66

GHz, DDR3 1066MHZ, 35W), supporting Intel®64 architecture, Intel®Smart Cache)

 Intel®Pentium®P6000/P6100P6200/P6300 processor (3 MB L3 cache,

1.86/2/2.13/2.27 GHz, DDR3 1066MHZ, 35W), supporting Intel®64 architecture, Intel®

Smart Cache)

 Intel®Celeron®P4600 processor (2 MB L3 cache, 2 GHz, DDR3 1066MHZ, 35W),

supporting Intel®64 architecture, Intel®Smart Cache)

 Mobile Intel®HM55 Express Chipset

System Memory 0

 Dual-channel DDR3 SDRAM support:

 Up to 4 GB of DDR3 system memory, upgradable to 8 GB using Two soDIMM

modules

Display 0

 17.3" HD+ 1600 x 900 resolution, high-brightness (220-nit) Acer CineCrystal™

LED-backlit TFT LCD

 Mercury-free, environment-friendly

 16:9 aspect ratio

Graphics 0

Intel®HD Graphics with 128 MB of dedicated system memory, supporting Microsoft®

DirectX®10

Dual independent display support

16.7 million colors

External resolution / refresh rates:

 VGA port up to 2560 x 1600: 60Hz

 HDMI®port up to 1920 x 1080: 60 Hz

1-6 Hardware Specifications and Configurations

NVIDIA®GeForce®GT 520M with NVIDIA®Optimus™ technology, up to 4095 MB of

TurboCache™ (1024 MB of dedicated DDR3 VRAM, up to 3071 MB of shared system

memory), supporting NVIDIA®CUBA™, PhysX™, PureVideo®HD technology, OpenEXR

High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft®DirectX®11

MPEG-2/DVD decoding

WMV9 (VC1) and H.264 (AVC) decoding

HDMI®(High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content

Protection) support

Storage Subsystem 0

Hard disk drive 0

 320/500/640/750 GB or larger

2-in-1 card reader (Realtek-RTS5209-GR), supporting: 0

 Secure Digital™ (SD™) Card, MultiMediaCard™ (MMC)

Audio Subsystem 0

 Realtek ALC271X-VB3-GR

 High-definition audio support

 Two built-in stereo speaker

 MS-Sound compatible

 Built-in microphone

Optical Media Drive 0

 8X DVD Super-Multi double-layer drive:

 Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X

DVD+R, 8X DVD-ROM DL, 8X DVD-R DL, 8X DVD+R DL, 8X DVD-RW, 8X

DVD+RW, 5X DVD-RAM

 Write: 24X CD-R, 24X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-R DL, 6X DVD+R

DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM

Communication 0

Webcam 0

 0.3M pixels UVC CAM

 1.3M pixels UVC CAM

 Acer Video Conference, featuring:

Hardware Specifications and Configurations 1-7

Acer Crystal Eye webcam

Wireless and networking 0

 WLAN:

 Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™

 Supporting Acer signalUp™ wireless technology

 LAN:

 Atheros/ AR8151 PCI-E Fast Ethernet, Wake-on-LAN ready

Privacy Control 0

 BIOS user, supervisor, HDD passwords

 Kensington lock slot

Dimensions and Weight 0

Dimensions 0

 414.75 (W) x 275(D) x 27.1/34.3(H) mm (16.3 x 10.8 x 1.07/1.35 inches)

Weight 0

 2.7 kg (5.95 lbs.) with 6-cell battery pack

Power Adapter and Battery 0

ACPI 3.0 CPU power management standard: supports Standby and Hibernation

power-saving modes

Power adapter 0

 3-pin 65W AC Adapter

95 (W) x 50 (D) x 25.4 (H) mm (3.74 x 1.96 x 1 inches)

216 g (0.47 lbs) with 180 cm DC cable

Battery 0

 48Wh 4400 mAh 6-cell Li-ion standard battery pack

 Battery life: 4 hours

 ENERGY STAR®

Special Keys and Controls 0

Keyboard 0

 103-/104-/107-key Acer FineTip keyboard with independent standard numeric keypad,

international language support

1-8 Hardware Specifications and Configurations

Touchpad 0

 Multi-gesture function, supporting two-finger scroll, pinch, rotate, flip

Media keys 0

 Media control keys (printed on keyboard): play/pause, stop, previous, next, volume up,

volume down

I/O Ports 0

 2-in-1 card reader (SD™, MMC)

 Three USB 2.0 ports

 HDMI®port with HDCP support

 External display (VGA) port

 Headphone/speaker

 Microphone-in jack

 Ethernet (RJ-45) port

 DC-in jack for AC adapter

Hardware Specifications and Configurations 1-9

Optional Items 0

 1/2/4 GB DDR3 1066MHz soDIMM module

 6 cell Li-ion battery pack

 3-pin 65 W AC adapter

Software 0

Productivity 0

 Acer Backup Manager (V3.0.0)

 Acer ePower Management

 Acer eRecovery Management

 Adobe®Reader®v9.1

 Adobe®Flash®Player 10.1

 Bing™ Bar

 eSobi™ (Acer v2.0.4)

 Microsoft®Office 2010 preloaded (purchase a product key to activate)

 Microsoft®Office Starter 2010

 Norton™ Online Backup

Security 0

 MyWinLocker®(except China, Hong Kong)

 McAfee®Internet Security Suite Trial

Multimedia 0

 Acer Acade™ Deluxe

 NTI Media Maker™

Gaming 0

 Oberon Game Zone (except US, Canada, Hong Kong, Korea)

 Wild Tangent®(US, Canada only)

Communication and ISP 0

 Acer Crystal Eye

 Microsoft®Silverlight™

 Skype™

 Windows Live™ Essentials 2011

1-10 Hardware Specifications and Configurations

Web links and utilities 0

 Acer Accessory Store (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden,

UK only)

 Acer Identity Card

 Acer Registration

 Acer Updater

 Netflix Shortcut (US only)

 eBay®shortcut 2009 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)

Environment 0

 Temperature:

 Operating: 0 °C to 40 °C

 Non-operating: -20 °C to 60°C

 Humidity (non-condensing):

 Operating: 20% to 80%

 Non-operating: 20% to 80%

Hardware Specifications and Configurations 1-11

Notebook Tour 0

This section provides an overview of the features and functions of the notebook.

Top View 0

Figure 1-1. Top View

Table 1-1. Top View

No Icon Item Description

1Microphone Internal microphone for sound recording.

2 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output(congiguration may

vary by model).

3Speakers Deliver stereo audio output.

4Power button Turns the computer on ad off.

5Keyboard For entering data into your computer

6Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

1-12 Hardware Specifications and Configurations

7Power indicator Indicates the computer’s power status.

Power on: Blue

Standby: Breeze mode Blue(1sec on/3 sec off)

Entering Hibernation: Blinking mode Blue(1

sec on/1 sec off)

Hibernation/Power off: N/A

Battery Indicator INdicates the computer’s battery status.

1. Charge: The light shows amber when the

battery is charging.

2. Fully charged: The light shows blue when

in AC mode.

Full Charged: Blue

Under Charging: Orange

Battery low: Breeze mode Orange(1 sec on/3

sec off)

Battery situation: Blinking mode Orange(1

sec on/1 sec off)

Using battery or not connected to AC

power:N/A.

8Click buttons (left,

and right)

The left and right buttons function like the

left and right mouse buttons.

9 Integrated webcam Web camera for video communication.

Table 1-1. Top View (Continued)

No Icon Item Description

Hardware Specifications and Configurations 1-13

Left View 0

Figure 1-2. Left View

Table 1-2. Left View

No Icon Item Description

1 Kensington lock slot Connects to a Kensington-compatible computer

security lock.

NOTE:

Wrap the computer security lock cable around

an immovable object such as a table or handle

of a locked drawer. Insert the lock into the

notch and turn the key to secure the lock.

Some keyless models are also available.

2 External display (VGA)

port

Connects to a display device (e.g. external

monitor, LCD projector).

3 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-based

network.

4 HDMI port Supports high-definition digital video connections.

5 USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse,

USB camera).

6 2-in-1 card reader Accepts Secure Digital (SD 3.0), MultiMediaCard

(MMC).

NOTE:

Push to remove/install the card. Only one card

can operate at any given time.

1-14 Hardware Specifications and Configurations

Right View 0

Figure 1-3. Right View

Table 1-3. Right View

No Icon Item Description

1 Microphone Jack Accepts inputs from external microphones.

Headphone/speaker

Jack

Connects to audio devices(eg., speakers,

headphones).

2 USB 2.0 port Connects to USB 2.0 devices (e.g., USB mouse, USB

camera).

3 Optical drive Internal optical drive; accepts CDs or DVDs.

4 Optical disk access

indicator

Lights up when the optical drive is active.

5 Optical disk eject

button

Eject the otical disk from the drive.

6 Emergency eject hole Eject the optical drive tray when the computer is

turned off.

NOTE:

Insert a paper clip to the emergency eject hole to

eject the optical drive tray when the computer is

off.

7 DC-In Jack Connects to AC adapter.
