Aspire E1-572 / E1-570 /

E1-532 / E1-530

Quick Guide

Product registration

When using your product for the first time, it is recommended that you immediately

•Faster service from our trained representatives.

•Membership in the Acer community: receive promotions and participate in customer

surveys.

•The latest news from Acer.

Hurry and register, as other advantages await you!

How to register

To register your Acer product, please visit www.acer.com. Select your country, click

PRODUCT REGISTRATION and follow the simple instructions.

You will also be asked to register your product during the setup process, or you can

double-click the Registration icon on the desktop.

After we receive your product registration, you will be sent a confirmation email with

important data that you should keep in a safe place.

Obtaining Acer accessories

We are happy to inform you that Acer's warranty extension program and Notebook

accessories are available online. Come and visit our online shop and find what you need

at store.acer.com.

The Acer store is being progressively rolled out, and, unfortunately may not be available

in some regions. Please check back regularly to see when it will be available in your

country.

Aspire E1-572 / E1-570 / E1-532 / E1-530 Quick Guide

This revision: 06/2013

Model number:

Serial number:

Date of purchase:

Place of purchase:

ENVIRONMENT

Temperature:

- Operating: 5 °C to 35 °C

- Non-operating: -20 °C to 65 °C

Humidity (non-condensing):

- Operating: 20% to 80%

- Non-operating: 20% to 80%

English

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the Setup Poster helps you get started with setting up your

computer.

The Quick Guide introduces you to the basic features and functions of your

new computer.

For more on how your computer can help you to be more productive, please

refer to the User’s Manual. The User’s Manual contains useful information

applying to your new computer. It covers basic topics such as using the

keyboard and audio, etc.

This guide contains detailed information on such subjects as system utilities,

data recovery, expansion options and troubleshooting. In addition it contains

warranty information and the general regulations and safety notices for your

notebook.

Follow these steps to access it:

1 Type ‘User’ from Start.

2 Click on Acer User’s Manual.

Your Acer notebook tour

English

Your Acer notebook tour

After setting up your computer as illustrated in the setup poster, let us show

you around your new Acer computer.

Screen view

#Icon Item Description

1Webcam

Web camera for video communication.

A light next to the webcam indicates that the

webcam is active.

2Screen Displays computer output.

3 Microphone Internal microphone for sound recording.

4SD card reader

Accepts one Secure Digital (SD or SDHC)

card.

Note: Push to remove/install the card.

English

Keyboard view

#Icon Item Description

1Power button Turns the computer on and off.

2Keyboard For entering data into your computer.

See "Using the keyboard" on page 8.

3Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

4Click buttons (left

and right)

The left and right side of the button function as

left and right selection buttons.

Power indicator Indicates the computer's power status.

Battery indicator

Indicates the computer's battery status.

Charging: The light is amber when the battery

is charging.

Fully charged: The light is blue when plugged

in.

HDD indicator Indicates when the hard disk drive is active.

Communication

indicator

Indicates the computer’s wireless connectivity

device status.

#Icon Item Description

Your Acer notebook tour

English

Left view

1 2 3 4 5 6

#Icon Item Description

Kensington lock slot Connects to a Kensington-compatible

computer security lock.

Wrap the computer security lock cable around

an immovable object such as a table or

handle of a locked drawer.

Insert the lock into the notch and turn the key

to secure the lock.

Keyless models are also available.

2External display (VGA)

port

Connects to a display device (e.g., external

monitor, LCD projector).

3Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-based

network.

4HDMI port Supports high-definition digital video

connections.

5USB port Connects to USB devices.

6Headset/speaker jack Connects to audio devices (e.g., speakers,

headphones) or a headset with microphone.

Information on USB 3.0

• USB 3.0 compatible ports are blue.

• Compatible with USB 3.0 and earlier devices.

• For optimal performance, use USB 3.0-certified devices.

• Defined by the USB 3.0 specification (SuperSpeed USB).

English

Right view

Note: Depending on configuration, your system may not be equipped with

an optical (CD/DVD) drive.

#Icon Item Description

1 USB ports Connect to USB devices.

2 Optical drive Internal optical drive; accepts CDs or

DVDs.

3Optical disk access

indicator Lights up when the optical drive is active.

4Optical drive eject

button Ejects the optical disk from the drive.

5 Emergency eject hole

Ejects the optical drive tray when the

computer is turned off.

Carefully insert a straightened paper clip

to eject the optical drive tray.

6 DC-in jack Connects to an AC adapter.

123 4 5 6

Using the keyboard

English

Base view

#Icon Item Description

1Battery release latch Releases the battery for removal. Insert a

suitable tool and slide to release.

Memory compartment Houses the computer's main memory.

HDD compartment Houses the computer's hard disk drive

memory.

3Speakers Deliver stereo audio output.

4Ventilation and cooling

fan

Allows the computer to stay cool.

Do not cover or obstruct the openings.

5Battery bay Houses the computer's battery pack.

Note: For models with an AMD processor and a single memory module:

If you replace the memory module, the new module must go into the same

slot occupied by the module that was removed.

Using the keyboard

The keyboard has full-sized keys and a numeric keypad, separate cursor, lock,

Windows, function and special keys.

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the

other key in the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Airplane mode

Turns on / off the computer's

network devices.

(Network devices vary by

configuration.)

<Fn> + <F4>SleepPuts the computer in Sleep

mode.

<Fn> + <F5> Display toggle

Switches display output between

the display screen, external

monitor (if connected) and both.

<Fn> + <F6> Display off

Turns the display screen

backlight off to save power.

Press any key to return.

<Fn> + <F7> Touchpad toggle Turns the built-in touchpad on

and off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + <F12> Scr Lk Scroll Lock Turns Scroll Lock on or off.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness down Decreases the screen

brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> + <Home> Play/Pause Play or pause a selected media

file.

<Fn> + <Pg Up>Stop Stop playing the selected media

file.

<Fn> + <Pg Dn> Previous Return to the previous media file.

<Fn> + <End> Next Jump to the next media file.

Ver.: 01.01.03
