Acer Aspire Notebook Series Bedienungsanleitung

Aspire Notebook Series

Quick Guide

Product registration

When using your product for the first time, it is recommended that you immediately

•Faster service from our trained representatives.

•Membership in the Acer community: receive promotions and participate in customer

surveys.

•The latest news from Acer.

Hurry and register, as other advantages await you!

How to register

To register your Acer product, please visit www.acer.com. Select your country, click

PRODUCT REGISTRATION and follow the simple instructions.

You will also be asked to register your product during the setup process, or you can

double-click the Registration icon on the desktop.

After we receive your product registration, you will be sent a confirmation email with

important data that you should keep in a safe place.

Obtaining Acer accessories

We are happy to inform you that Acer's warranty extension program and Notebook

accessories are available online. Come and visit our online shop and find what you need

at store.acer.com.

The Acer store is being progressively rolled out, and, unfortunately may not be available

in some regions. Please check back regularly to see when it will be available in your

country.

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Aspire Notebook Series Quick Guide

Original Issue: 02/2012

Acer recommends...

Productivity Software

Work Great with Microsoft®Office 2010 - Express your ideas, solve problems and simplify everyday projects

with Office 2010.

Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,

YouTube or Windows Live.

Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more

informed decisions.

English

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your

computer.

The Aspire Generic User Guide contains useful information applying to

all models in the Aspire product series. It covers basic topics such as

using the keyboard and audio, etc. Please understand that due to its

nature, the Generic User Guide will occasionally refer to functions or

features which are only contained in certain models of the series, but not

necessarily in the model you purchased. Such instances are marked in the

text with language such as "only for certain models".

The Quick Guide introduces you to the basic features and functions of

your new computer. For more on how your computer can help you to be

more productive, please refer to the Aspire Generic User Guide. This

guide contains detailed information on such subjects as system utilities,

data recovery, expansion options and troubleshooting. In addition it

contains warranty information and the general regulations and safety

notices for your notebook. It is available in Portable Document Format

(PDF) and comes preloaded on your notebook. Follow these steps to

access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on Aspire Generic User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on Aspire Generic User Guide

will run the Adobe Reader setup program first. Follow the instructions

on the screen to complete the installation. For instructions on how to

use Adobe Reader, access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the poster, let us show you

around your new Acer notebook.

Top cover view

#Icon Item Description

1 Microphone Internal microphone for recording sound.

2Screen Also called Liquid-Crystal Display (LCD),

displays computer output.

3 Webcam Web camera for video communication.

English

Keyboard view

#Icon Item Description

1 Power button Turns the computer on and off.

2 Keyboard For entering data into your computer.

3Touchpad

Touch-sensitive pointing device which

functions like a computer mouse.

4Click buttons (left

and right)

The left and right buttons function like the

left and right mouse buttons.

5 Speakers Left and right speakers deliver stereo audio

output.

English

Hotkeys

The computer employs hotkeys or key combinations to access most of

the computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the

other key in the hotkey combination.

Hotkey Icon Function Description

<Fn> +

<F3>

Communication

key

Enables / disables the computer's

communication devices.

(Communication devices may vary by

configuration.)

<Fn> +

<F4>Sleep Puts the computer in Sleep mode.

<Fn> +

<F5>Display toggle

Switches display output between the

display screen, external monitor

(if connected) and both.

<Fn> +

<F6>Display off

Turns the display screen backlight off

to save power. Press any key to

return.

<Fn> +

<F7>

Touchpad

toggle

Turns the internal touchpad on and

off.

<Fn> +

<F8>Speaker toggle Turns the speakers on and off.

<Fn> +

<> Brightness up Increases the screen brightness.

<Fn> +

Brightness

down Decreases the screen brightness.

<Fn> +

<> Volume up Increases the sound volume.

<Fn> +

<> Volume down Decreases the sound volume.

<Fn> +

<Home>Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>Stop Stop playing the selected media file.

<Fn> +

<Pg Dn>Previous Return to the previous media file.

<Fn> +

<End>Next Jump to the next media file.

English

Closed front view

Left view

#Icon Item Description

Power Indicates the computer's power status.

Battery

Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

HDD Indicates when the hard disk drive is active.

Communication

indicator

Indicates the computer's wireless

connectivity device status.

2Multi-in-1 card

reader

Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory Stick

(MS), Memory Stick PRO (MS PRO),

xD-Picture Card (xD).

Note: Push to remove/install the card. Only

one card can operate at any given time.

#Icon Item Description

1Kensington lock

slot

Connects to a Kensington-compatible

computer security lock.

1 2

21 3 54

English

Information on USB 3.0

•Compatible with USB 3.0 and earlier USB devices.

•For optimal performance, use USB 3.0-certified devices.

•Defined by the USB 3.0 (SuperSpeed USB) specification.

Right view

2Ethernet (RJ-45)

port

Connects to an Ethernet 10/100/1000-

based network.

3External display

(VGA) port

Connects to a display device

(e.g., external monitor, LCD projector).

4HDMIport

Supports high definition digital video

connections.

5USBports

Connect to USB devices.

If a port is black, it is USB 2.0 compatible; if

it is blue it is also USB 3.0 compatible.

#Icon Item Description

Headphones/

speaker/line-out

jack

Connects to audio line-out devices

(e.g., speakers, headphones).

Microphone jack Accepts inputs from external microphones.

2USBports

Connect to USB devices.

If a port is black, it is USB 2.0 compatible; if

it is blue it is also USB 3.0 compatible.

#Icon Item Description

12 6 73 54

English

Base view

3 Optical drive Internal optical drive; accepts CDs or DVDs.

4Optical disk

access indicator Lights up when the optical drive is active.

5Optical drive

eject button Ejects the optical disk from the drive.

6Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the emergency

eject hole to eject the optical drive tray

when the computer is off.

7 DC-in jack Connects to an AC adapter.

#Icon Item Description

1Battery release

latch

Releases the battery for removal.

Insert a suitable tool into the latch and slide

to release.

#Icon Item Description

English

Note: Dual-core computers are fitted with two memory slots; quad-

core computers are fitted with four memory slots. For quad-core

computers with two memory modules, use only the lower slot in each

bank.

Visit www.acer.com to find your specific model and refer to the

detailed specifications to determine which processor your computer

uses. If you’re unsure, please contact an authorized Acer service

center.

Environment

Hard disk bay Houses the computer's hard disk

(secured with screws).

Memory

compartment Houses the computer's main memory.

3 Battery bay Houses the computer's battery pack.

•Temperature:

•Operating: 5 °C to 35 °C

•Non-operating: -20 °C to 65 °C

•Humidity (non-condensing):

•Operating: 20% to 80%

•Non-operating: 20% to 80%

#Icon Item Description
