Aspire One
Quick Guide
Product registration
When using your product for the first time, it is recommended that you immediately
register it. This will give you access to some useful benefits, such as:
•Faster service from our trained representatives.
•Membership in the Acer community: receive promotions and participate in customer
surveys.
•The latest news from Acer.
Hurry and register, as other advantages await you!
How to register
To register your Acer product, please visit www.acer.com. Select your country, click
PRODUCT REGISTRATION and follow the simple instructions.
You will also be asked to register your product during the setup process, or you can
double-click the Registration icon on the desktop.
After we receive your product registration, you will be sent a confirmation email with
important data that you should keep in a safe place.
Obtaining Acer accessories
We are happy to inform you that Acer's warranty extension program and Notebook
accessories are available online. Come and visit our online shop and find what you need
at store.acer.com.
The Acer store is being progressively rolled out, and, unfortunately may not be available in
some regions. Please check back regularly to see when it will be available in your country.
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
© 2012. All Rights Reserved.
Aspire One Quick Guide
This revision: 07/2012
Acer recommends...
Productivity Software
Work Great with Microsoft®Office 2010 - Express your ideas, solve problems and simplify everyday projects with
Office 2010.
Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,
YouTube or Windows Live.
Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more
informed decisions.
3
First things first
We would like to thank you for making an Acer notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of guides:
First off, the setup poster helps you get started with setting up your
computer.
The User’s Manual contains useful information applying to your notebook.
It covers basic topics such as using the keyboard and audio, etc.
The Quick Guide introduces the basic features and functions of your new
computer. For more on how your computer can help you to be more
productive, please refer to the User’s Manual. This guide contains detailed
information on such subjects as system utilities, data recovery, expansion
options and troubleshooting. In addition it contains warranty information
and the general regulations and safety notices for your notebook. It is
available in Portable Document Format (PDF) and comes preloaded on
your notebook. Follow these steps to access it:
1Type "User" from Start.
2Click on Acer User’s Manual.
4
English
Your Acer notebook tour
After setting up your computer as illustrated in the setup poster, let us
show you around your new Acer notebook.
Front view
#Icon Item Description
1 Webcam Web camera for video communication.
A light next to the webcam indicates that the
webcam is active.
2 Screen Also called Liquid-Crystal Display (LCD),
displays computer output.
3 Power indicator Indicates the computer's power status.
Battery indicator Indicates the computer's battery status.
1. Charging: The light shows amber when the
battery is charging.
2. Fully charged: The light shows blue when
in AC mode.
Communication
indicator
Indicates the computer’s wireless connectivity
device status.
1
2
3
5
English
Keyboard view
#Icon Item Description
1 Power button Turns the computer on and off.
2 Keyboard For entering data into your computer.
3 Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
4 Click buttons (left
and right)
The left and right buttons function like the left
and right mouse buttons.
5 Palmrest Comfortable support area for your hands when
you use the computer.
1
2
3
4
5
6
English
Hotkeys
The computer employs hotkeys or key combinations to access most of the
computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the other
key in the hotkey combination.
Hotkey Icon Function Description
<Fn> + <F3> Communication Enables/disables the computer’s
communication devices. Communication
devices may vary by configuration.
<Fn> + <F4> Sleep Puts the computer in Sleep mode.
<Fn> + <F5> Display toggle Switches display output between the
display screen, external monitor
(if connected) and both.
<Fn> + <F6> Screen blank Turns the display screen backlight off to
save power. Press any key to return.
<Fn> + <F8> Speaker toggle Turns the speakers on and off.
<Fn> + <F11> Num Lock When Num Lock is on, the embedded
keypad is in numeric mode. The keys
function as a calculator (complete with
the arithmetic operators +, -, *, and /).
Use this mode when you need to do a lot
of numeric data entry. A better solution
would be to connect an external keypad.
<Fn> + <F11> only for certain models.
<Fn> +
<F12>
Scroll Lock When Scroll Lock is on, the screen
moves one line up or down when you
press the up or down arrow keys
respectively. Scroll Lock does not work
with some applications.
<Fn> + < > Brightness up Increases the screen brightness.
<Fn> + < > Brightness down Decreases the screen brightness.
<Fn> + < > Volume up Increases the sound volume (only for
certain models).
<Fn> + < > Volume down Decreases the sound volume (only for
certain models).
7
English
Left view
Information on USB 3.0
•Compatible with USB 3.0 and earlier devices.
•For optimal performance, use USB 3.0-certified devices.
•Defined by the USB 3.0 (SuperSpeed USB) specification.
#Icon Item Description
1 External display
(VGA) port
Connects to a display device (e.g., external
monitor, LCD projector).
2 Ethernet (RJ-45) port Connects to an Ethernet 10/100 based
network.
3 HDMI port Supports high-definition digital video
connections.
4 USB port Connects to USB devices.
If a port is black, it is USB 2.0 compatible; if
a port is blue it is also USB 3.0 compatible.
21 34
8
English
Right view
#Icon Item Description
1 Multi-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
(MS), Memory Stick PRO (MS PRO),
xD-Picture Card (xD).
2 Headphone/speaker/
line-out jack
Connects to audio line-out devices
(e.g., speakers, headphones).
Microphone-in jack Accepts inputs from external microphones.
3 USB ports Connects to USB devices.
If a port is black, it is USB 2.0 compatible; if
a port is blue it is also USB 3.0 compatible.
4
5 DC-in jack Connects to an AC adapter.
6 Kensington lock slot Connects to a Kensington-compatible
computer security lock.computer security
lock.
Note: Wrap the computer security lock
cable around an immovable object such as
a table or handle of a locked drawer. Insert
the lock into the notch and turn the key to
secure the lock. Some keyless models are
also available.
12 6354
9
English
Base view
Environment
#Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Ventilation slot and
cooling fan
Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening
of the fan.
3 Speakers Left and right spearkers deliver stereo audio
output.
•Temperature:
•Operating: 5 °C to 35 °C
•Non-operating: -20 °C to 65 °C
•Humidity (non-condensing):
•Operating: 20% to 80%
•Non-operating: 20% to 80%
1
2
3
Part no.:
Ver.: 02.01.01
