Acer eMachines E510 Series Bedienungsanleitung
eMachines E510 Series
User's Guide
Changes may be made periodically to the information in this publication without obligation
to notify any person of such revisions or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.
Record the model number, serial number, purchase date and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your computer. All correspondence concerning your unit should include the serial
number, model number and purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronically, mechanically, by photocopy, recording or otherwise,
without the prior written permission of Acer Incorporated.
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Copyright © 2008.
All Rights Reserved.
eMachines E510 Series User's Guide
Original Issue: 05/2008
eMachines E510 Series Notebook PC
eMachines and the eMachines logo are registered trademarks of Acer Incorporated. Other
companies' product names or trademarks are used herein for identification purposes only and
belong to their respective companies.
3
Federal Communications Comission
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including
interference that may cause undesired operation.
The following local manufacturer/importer is responsible for this declaration:
We,
Acer Computer (Shanghai) Limited
3F, No. 168 Xizang medium road, Huangpu District,
Shanghai, China
Contact Person: Mr. Easy Lai
Tel: 886-2-8691-3089 Fax: 886-2-8691-3000
E-mail: easy_lai@acer.com.tw
Hereby declare that:
Is compliant with the essential requirements and other relevant provisions of the following
EC directives, and that all the necessary steps have been taken and are in force to assure
that production units of the same product will continue comply with the requirements.
EMC Directive 2004/108/EC as attested by conformity with the following harmonized
standards:
Product name: Notebook PC
Model number: ICL50
Machine type: eMachines E510
SKU number: eMachines E510-xxxxx
("x" = 0 - 9, a - z, or A - Z)
Name of responsible party: Acer America Corporation
Address of responsible party: 333 West San Carlos St.
San Jose, CA 95110
USA
Contact person: Acer Representitive
Tel: 1-254-298-4000
Fax: 1-254-298-4147
Product: Notebook PC Trade Name: eMachines
Model Number: ICL50 Machine Type: eMachines E510
SKU Number: eMachines E510-xxxxx ("x" = 0~9, a ~ z, or A ~ Z)
4
-. EN55022:1998 + A1:2000 + A2:2003, AS/NZS CISPR22:2002, Class B
-. EN55024:1998 + A1:2001 + A2:2003
-. EN61000-3-2:2000 + A2:2005, Class D
-. EN61000-3-3:1995 + A1:2001 + A2:2005
Low Voltage Directive 2006/95/EC as attested by conformity with the following harmonized
standard:
-. EN60950-1:2001 + A11:2004
Council Decision 98/482/EC (CTR21) for pan- European single terminal connection to the
Public Switched Telephone Network (PSTN).
RoHS Directive 2002/95/EC on the Restriction of the Use of certain Hazardous Substances in
Electrical and Electronic Equipment
R&TTE Directive 1999/5/EC as attested by conformity with the following harmonized
standard:
•Article 3.1(a) Health and Safety
-. EN60950-1:2001+ A11:2004
-. EN50371:2002
•Article 3.1(b) EMC
-. EN301 489-1 V1.4.1
-. EN301 489-3 V1.4.1
-. EN301 489-17 V1.2.1
•Article 3.2 Spectrum Usages
-. EN300 328 V1.6.1
-. EN301 893 V1.2.3
CE Issued Date: 29 February 2008
Acer Computer (Shanghai) Limited
Easy Lai / Director Date
29 Feb 2008
5
First things first
We would like to thank you for making an eMachines notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your eMachines notebook, we have designed a set of guides:
First off, the Just for Starters... poster helps you get started with
setting up your computer.
The printed User's Guide introduces you to the basic features and
functions of your new computer. For more on how your computer
can help you to be more productive, please refer to the
eMachinesSystem User's Guide. This guide contains detailed
information on such subjects as system utilities, data recovery,
expansion options and troubleshooting. In addition it contains
warranty information and the general regulations and safety
notices for your notebook. It is available in Portable Document
Format (PDF) and comes preloaded on your notebook.
To view the user guide, click on eMachinesSystem User's Guide.
Note: Viewing the file requires Adobe Reader.
6
English
Your eMachines notebook tour
After setting up your computer as illustrated in the Just for Starters... poster,
let us show you around your new eMachines notebook.
Top view
#ICON Item Description
1 Microphone Internal microphone for sound recording.
1
3
4
6
7
8
11
9
11
2
5
10
12
7
English
1. The front panel indicators are visible even when the computer cover is closed
up.
2 Integrated
webcam
Web camera for video communication.
(for selected models)
3 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output.
4 Power button Turns the computer on and off.
5 Wireless
communication
button/indicator
Enables/disables the wireless function.
Indicates the status of wireless LAN
communication.
6 Speakers Left and right speakers deliver stereo audio
output.
7 Keyboard For entering data into your computer.
8 Palmrest Comfortable support area for your hands
when you use the computer.
9 Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
10 Click buttons (left,
center and right)
The left and right buttons function like the
left and right mouse buttons; the center
button serves as a 4-way scroll button.
11 Power1Indicates the computer's power status.
Battery1Indicates the computer's batttery status.
1. Charging: The light shows amber when
the battery is charging.
2. Fully charged: The light shows green
when in AC mode.
HDD Indicates when the hard disk drive is active.
Num Lock Lights up when Num Lock is activated.
Caps Lock Lights up when Caps Lock is activated.
12 <Fn>
+
<>
Volume up Increases the sound volume.
<Fn>
+
<>
Volume down Decreases the sound volume.
#ICON Item Description
8
English
Closed front view
Left view
#Icon Item Description
1 Microphone-in jack Accepts input from external
microphones.
2 Headphones/speaker/
line-out jack
Connects to audio line-out devices
(e.g., speakers, headphones).
3 Latch Locks and releases the lid.
#Icon Item Description
1 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
Note: Wrap the computer security lock
cable around an immovable object such
as a table or handle of a locked drawer.
Insert the lock into the notch and turn
the key to secure the lock. Some keyless
models are also available.
2 External display
(VGA) port
Connects to a display device
(e.g., external monitor, LCD projector).
3 Ethernet (RJ-45) port Connects to an Ethernet 10/100-based
network.
4 2 USB 2.0 ports Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
12 3
12 34
9
English
Right view
Rear view
#Icon Item Description
1 USB 2.0 port Connect to USB 2.0 devices
(e.g., USB mouse, USB camera).
2 Optical drive Internal optical drive; accepts CDs or DVDs
3 Optical disk
access indicator
Lights up when the optical drive is active.
4 Optical drive
eject button
Ejects the optical disk from the drive.
5Emergency
eject hole
Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the emergency
eject hole to eject the optical drive tray when
the computer is off.
#Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 Ventilation slots Enable the computer to stay cool, even after
prolonged use.
1 3 4 52
1 2
10
English
Base view
#Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch Releases the battery for removal.
3 Battery lock Locks the battery in position.
4Memory
compartment
Houses the computer's main memory.
5 Hard disk bay Houses the computer's hard disk (secured
with screws).
6 Ventilation slots and
cooling fan
Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening
of the fan.
1
2
3
5
4
6
