eMachines E730/E730Z/E640/

E530/E440 Series

Quick Guide

Model number: ________________________________

Serial number: _________________________________

Date of purchase: ______________________________

Place of purchase: ______________________________

eMachines E730/E730Z/E640/E530/E440 Series Quick Guide

Original Issue: 04/2010

eMachines E730/E730Z/E640/E530/E440 Series Notebook PC

First things first

We would like to thank you for making an eMachines notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your eMachines notebook, we have designed a set of guides:

First off, the setup poster helps you get started with setting up your computer.

The eMachines Generic User Guide contains useful information applying to all

models in the eMachines product range. It covers basic topics such as system

recovery, using the keyboard, audio, etc. Please understand that due to its nature,

the eMachines Generic User Guide will occasionally refer to functions or features

which are only contained in certain models, but not necessarily in the model you

have purchased. Such instances are marked in the text with language such as "only

for certain models".

This Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the eMachines Generic User Guide,which contains detailed

information on such subjects as system utilities, data recovery, expansion options

and troubleshooting. In addition it contains warranty information and the general

regulations and safety notices for your notebook. It is available in Portable

Document Format (PDF) and comes preloaded on your notebook. Follow these

steps to access it:

1 Click on Start, All Programs, eMachines Documentation.

2 Click on eMachines Generic User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not installed

on your computer, clicking on eMachines Generic User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader, access

the Help and Support menu.

English

Your eMachines notebook tour

After setting up your computer as illustrated in the setup poster, let us show you

around your new eMachines notebook.

Top view

#Icon Item Description

1 Integrated webcam Web camera for video communication (only for

certain models).

2 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output (configuration may

vary by model).

3 Communication

indicator

Indicates the computer’s wireless connectivity

device status.

English

4 HDD indicator Indicates when the hard disk drive is active.

5 Power button/

indicator

Turns the computer on and off. Indicates the

computer's power status.

6 Keyboard For entering data into your computer.

7 Touchpad Touch-sensitive pointing device which functions

like a computer mouse.

8 Click buttons (left

and right)

The left and right buttons function like the left

and right mouse buttons.

9 Palmrest Comfortable support area for your hands when

you use the computer.

10 Speaker Deliver stereo audio output.

11 Microphone Internal microphone for sound recording.

#Icon Item Description

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key in

the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Communication

key

Enables/disables the computer’s

communication devices.

(Communication devices may vary

by configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between

the display screen, external monitor

(if connected) and both.

<Fn> + <F6> Display off Turns the display screen backlight

off to save power. Press any key to

return.

<Fn> + <F7> Touchpad

toggle

Turns the internal touchpad on and

off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness

down

Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> + <Home> Play/Pause Play or pause a selected media file.

<Fn> + <Pg Up> Stop Stop playing the selected media file.

<Fn> + <Pg Dn> Previous Return to the previous media file.

<Fn> + <End> Next Jump to the next media file.

English

Closed front view

1. The front panel indicators are visible even when the computer cover is closed up.

Rear view

#Icon Item Description

1 Power indicator Indicates the computer's power status.

2Battery indicator1Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

3 Multi-in-1 card reader Accepts Secure Digital (SD),

MultiMediaCard (MMC), Memory Stick (MS),

Memory Stick PRO (MS PRO), xD-Picture

Card (xD).

Note: Push to remove/install the card. Only

one card can operate at any given time.

#Icon Item Description

1 Battery bay Houses the computer's battery pack.

12 3

English

Left view

#Icon Item Description

1 DC-in jack Connects to an AC adapter.

2 Ventilation slots Enable the computer to stay cool, even after

prolonged use.

3 External display (VGA)

port

Connects to a display device (e.g., external

monitor, LCD projector).

4 Ethernet (RJ-45) port Connects to an Ethernet 10/100/1000-

based network.

5 HDMI port Supports high-definition digital video

connections.

6 USB 2.0 port Connects to USB 2.0 devices (e.g., USB

mouse, USB camera).

7 Microphone-in jack Accepts inputs from external microphones.

Headphone/speaker/

line-out jack

Connects to audio line-out devices (e.g.,

speakers, headphones).

2134567
