Acer Travelmate 273X Bedienungsanleitung
Acer Travelmate 273X
The TravelMate 270 series has been especially designed for the
outbound professional user, either self-employed or working in
small, medium and large corporations, looking for a powerful work
tool that integrates multimedia, communication and performance
features required to meet the challenges of today's business-critical
applications. High-quality audio and video, real-time access to
Internet and office network, simple system set-up and installation as
well as hassle-free management of cables, storage devices and
other accessories - these are the comprising needs of mobile
professionals who need to keep up with today's fast-moving
business world. The TravelMate 270, with its all-in-one design,
integrates the power and the latest innovations in connectivity to
ensure that executives and professionals maintain a high level of
performance and productivity, even and especially when undertaking
outbound work. Especially designed for demanding multimedia
applications, this notebook PC is the excellent solution for graphics
intensive presentations and audio-visual shows.
www.dooyoo.co.uk :: Computer :: Laptops :: Acer Travelmate 273X
General
Recommended Use Small business, corporate business
System Type Notebook
Built-in Devices Microphone, stereo speakers, keyboard, touchpad, display
Width 32.2 cm
Depth 27.2 cm
Height 3.8 cm
Weight 3 kg
Localisation German / Germany
Processor
Processor Intel Pentium 4-M 1.7 GHz
Data Bus Speed 400 MHz
Features Deeper Sleep, Enhanced SpeedStep technology, streaming
SIMD extensions 2, MMX instructions set
Chipset Type SiS650
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
Cache Memory
Type L2 Cache - Advanced Transfer Cache
Installed Size 512 KB
RAM
Installed Size 256 MB / 1 GB (max)
Technology DDR SDRAM - 266 MHz
Memory Specification Compliance PC2100
Form Factor SO DIMM 200-pin
Storage Controller
Type IDE
Storage
Floppy Drive 3.5" 1.44 MB floppy - integrated
Hard Drive 20 GB
Optical Storage
Type CD-ROM - integrated
Read Speed 24x
Display
Display Type 14.1" TFT active matrix
Max Resolution 1024 x 768 ( XGA )
Widescreen Display No
Colour support 24-bit (16.7 million colours)
Video
Graphics Processor / Vendor SiS 650 - AGP 4x
Video Memory Shared Video Memory (UMA)
Audio
Audio Output Sound card
Compliant Standards DirectSound, AC '97, Sound Blaster Pro
Audio Input Microphone
Input Device(s)
Type Keyboard, touchpad, 4-way scroll button
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
Telecom
Modem Fax / modem
Max Transfer Rate 56 Kbps
Protocols & Specifications ITU V.90 , Hayes AT command set
Networking
Networking Network adapter
Data Link Protocol Ethernet, Fast Ethernet
Expansion / Connectivity
Expansion Slots Total (Free) 1 ( 1 ) x CardBus - type III (2 x type I / II) ¦ 2 memory
- SO DIMM 200-pin
Interfaces 1 x modem - phone line - RJ-11 ¦ 1 x network - Ethernet
10Base-T/100Base-TX - RJ-45 ¦ 1 x parallel - IEEE 1284
(EPP/ECP) - 25 pin D-Sub (DB-25) ¦ 1 x serial - RS-232C
- 9 pin D-Sub (DB-9) ¦ 1 x keyboard / mouse - generic -
6 pin mini-DIN (PS/2 style) ¦ 1 x display / video - VGA -
15 pin HD D-Sub (HD-15) ¦ 1 x audio -
line-out/headphones - mini-phone stereo 3.5 mm ¦ 1 x
audio - line-in/microphone - mini-phone 3.5mm ¦ 3 x USB
- 4 PIN USB Type A ¦ 1 x IEEE 1394 (FireWire) ¦ 1 x
display / video - S-video output - 4 PIN mini-DIN
Miscellaneous
Features Security lock slot (cable lock sold separately), administr
ator password, wake on LAN, Wake on Ring
Compliant Standards ACPI 2.0
Power
Power Device External
Voltage Required AC 100/240 V ( 50/60 Hz )
Power Provided 65 Watt
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
Battery
Technology Lithium Ion
Installed Qty 1
Capacity 57 Wh
Run Time (Up To) 3 hour(s)
Recharge Time 3 hour(s)
Operating System / Software
OS Provided Microsoft Windows 2000 / XP Professional
Software Drivers & Utilities, Adobe Acrobat Reader, Norton
AntiVirus, Acer System Recovery, Acer Launch Manager
Manufacturer Warranty
Service & Support 2 years warranty
Service & Support Details Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature 5 °C
Max Operating Temperature 35 °C
Humidity Range Operating 20 - 80%
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
