Contents

TravelMate 4740/4740Z/4340

Series

Quick Guide

Model number: ____________________________________

Serial number: _____________________________________

Date of purchase: __________________________________

Place of purchase: _________________________________

TravelMate 4740/4740Z/4340 Series Quick Guide

Original Issue: 02/2010

TravelMate 4740/4740Z/4340 Series Notebook PC

First things first

We would like to thank you for making an Acer notebook your choice for

meeting your mobile computing needs.

Your guides

To help you use your Acer notebook, we have designed a set of guides:

First off, the poster helps you get started with setting up your computer.

The TravelMate Series Generic User Guide contains useful information applying

to all models in the TravelMate product series. It covers basic topics such as

using the keyboard and audio, etc. Please understand that due to its nature, the

Generic User Guide as well as the AcerSystem User Guide mentioned below will

occasionally refer to functions or features which are only contained in certain

models of the series, but not necessarily in the model you purchased. Such

instances are marked in the text with language such as "only for certain

models".

The Quick Guide introduces you to the basic features and functions of your new

computer. For more on how your computer can help you to be more productive,

please refer to the AcerSystem User Guide. This guide contains detailed

information on such subjects as system utilities, data recovery, expansion

options and troubleshooting. In addition it contains warranty information and

the general regulations and safety notices for your notebook. It is available in

Portable Document Format (PDF) and comes preloaded on your notebook.

Follow these steps to access it:

1 Click on Start > All Programs > AcerSystem.

2 Click on AcerSystem User Guide.

Note: Viewing the file requires Adobe Reader. If Adobe Reader is not

installed on your computer, clicking on AcerSystem User Guide will run the

Adobe Reader setup program first. Follow the instructions on the screen to

complete the installation. For instructions on how to use Adobe Reader,

access the Help and Support menu.

English

Your Acer notebook tour

After setting up your computer as illustrated in the poster, let us show you

around your new Acer notebook.

Top view

#Icon Item Description

1 Acer Crystal Eye

webcam

Web camera for video communication

(only for certain models).

English

1. The front panel indicators are visible even when the computer cover is closed up.

Note: The exact configuration of your PC depends on the model

purchased.

2 Microphone Internal microphone for recording sound.

3 Display screen Also called Liquid-Crystal Display (LCD),

displays computer output

(configuration may vary by model).

4 Speakers Left and right speakers deliver stereo

audio output.

5 Keyboard For entering data into your computer.

6 Touchpad Touch-sensitive pointing device which

functions like a computer mouse.

7Power indicator1Indicates the computer's power status.

Battery indicator1Indicates the computer's battery status.

1. Charging: The light shows amber when

the battery is charging.

2. Fully charged: The light shows blue

when in AC mode.

8 Click buttons (left

and right)

The left and right buttons function like

the left and right mouse buttons.

9 Palmrest Comfortable support area for your hands

when you use the computer.

10 Communication

indicator

Indicates the computer's wireless

connectivity device status.

HDD indicator Indicates when the hard disk drive is

active.

11 Power switch Turns the computer on and off.

#Icon Item Description

English

Hotkeys

The computer employs hotkeys or key combinations to access most of the

computer's controls like screen brightness and volume output.

To activate hotkeys, press and hold the <Fn> key before pressing the other key

in the hotkey combination.

Hotkey Icon Function Description

<Fn> + <F3> Communication

key

Enables / disables the computer's

communication devices. (Communication

devices may vary by configuration.)

<Fn> + <F4> Sleep Puts the computer in Sleep mode.

<Fn> + <F5> Display toggle Switches display output between the

display screen, external monitor

(if connected) and both.

<Fn> + <F6> Display off Turns the display screen backlight off to

save power. Press any key to return.

<Fn> + <F7> Touchpad

toggle

Turns the internal touchpad on and off.

<Fn> + <F8> Speaker toggle Turns the speakers on and off.

NumLk

NumLock Turns the embedded numeric keypad on

or off.

<Fn> + <F12> Scr Lk Scroll Lock When Scroll Lock is on, the screen moves

one line up or down when you press the

up or down arrow keys respectively.

Scroll Lock does not work with some

applications.

<Fn> + < > Brightness up Increases the screen brightness.

<Fn> + < > Brightness

down

Decreases the screen brightness.

<Fn> + < > Volume up Increases the sound volume.

<Fn> + < > Volume down Decreases the sound volume.

<Fn> +

<Home>

Play/Pause Play or pause a selected media file.

<Fn> +

<Pg Up>

Stop Stop playing the selected media file.

<Fn> +

<Pg Dn>

Previous Return to the previous media file.

<Fn> +

<End>

Next Jump to the next media file.

English

Closed front view

Left view

#Icon Item Description

1Multi-in-1card

reader

Accepts Secure Digital (SD), MultiMediaCard

(MMC), Memory Stick (MS), Memory Stick

PRO (MS PRO), xD-Picture Card (xD).

Note: Push to remove/install the card. Only

one card can operate at any given time.

#Icon Item Description

1 DC-in jack Connects to an AC adapter.

2 Ethernet (RJ-45)

port

Connects to an Ethernet 10/100/1000-based

network.

3 Ventilation slots Enable the computer to stay cool, even after

prolonged use.

4 External display

(VGA) port

Connects to a display device

(e.g., external monitor, LCD projector).

5 USB 2.0 port Connect to USB 2.0 devices

(e.g., USB mouse, USB camera).

21345

English

Right view

#Icon Item Description

1 Headphones/

speaker/line-out

jack

Connects to audio line-out devices

(e.g., speakers, headphones).

Microphone jack Accepts inputs from external microphones.

2 USB 2.0 port Connect to USB 2.0 devices

(e.g., USB mouse, USB camera).

3 Optical drive Internal optical drive; accepts CDs or DVDs.

4 Optical disk

access indicator

Lights up when the optical drive is active.

5 Optical drive

eject button

Ejects the optical disk from the drive.

6 Emergency eject

hole

Ejects the optical drive tray when the

computer is turned off.

Note: Insert a paper clip to the emergency

eject hole to eject the optical drive tray

when the computer is off.

7 Kensington lock

slot

Connects to a Kensington-compatible

computer security lock.

2134567
