Aci DSIM-SS Bedienungsanleitung

DSIM-SS

Installation Guide

Revision B

DSIM-SS

Installation Guide Rev B

Page 2 of 18

1. Quick Start Instructions for Single Pilot AGC Operatation

1. Remove the RF module cover and install the DSIM-SS AGC module into theamplifier.

2. If the DSIM-SS has a slope POT use it to set the inter-stage slope

3. Check and set desired amplifier levels.

4. Re-install the RF module faceplate

5. Plug the controller cable into the DSIM and plug the controller into the cable.

6. Press mode button once. The controller light will flash blue and red for approximately

45 seconds.

7. When done, the controller light will have a half second blue blink indicating that the

DSIM is in AGC mode.

8. Remove the controller from the amplifier, and the DSIM is all set!

DSIM-SS

Installation Guide Rev B

Page 3 of 18

Table of Contents

1. QUICK START INSTRUCTIONS FOR SINGLE PILOT AGC OPERATATION ....................... 2

2. DSIM AGC MODULE & DSIM CONTROLLER OVERVIEW ..........................................4

3. DSIM MODE DEFINITIONS ......................................................................................6

4. DSIM CONTROLLER OPERATION INSTRUCTION GUIDELINES ..................................8

5. DSIM CONTROLLER STATUS LED ESSENTIALS..........................................................8

6. DSIM MODULE STATUS LED ESSENTIALS.................................................................9

7. SINGLE PILOT AGC STANDARD SETUP ...................................................................10

8. THERMAL AGC SETUP ...........................................................................................12

9. LED PILOT CHANNEL BLINK SERIES OVERVIEW ........................................................14

DSIM-SS

Installation Guide Rev B

Page 4 of 18

DSIM AGC Module & DSIM Controller Overview

The Digital Station Intelligence Manager (DSIM®) product line is the next generation of

automatic gain control modules that provides the outside plant maintenance team with station

diagnostic tools that are unprecedented in the industry. The DSIM AGC module is agile that

allows the program settings to be modified at any time to change the pilot channel number

and type from analog to digital or to change the operational mode into the SPAGC, thermal

AGC, or manual modes of operation. Having this flexibility to reprogram the DSIM modules is

a huge cost savings when doing system modifications over the fixed SPAGC or T-bode

modules since only the program settings need to be changed instead of having to change out

the entire AGC fixedmodule.

DIGITAL STATION INTELLIGENCE

MANAGER

DSIM CONTROLLER

Status LED DSIM Controller Variable EQ

Blue / Orange Interface Connector 0 to 20 dB

With Variable Equalizer

Mode Decreas Increase

Status LED

Blue / Orange

DSIM Controller

Interface Connector

Status LED

Red/Blue

DSIM Module

Interface

Connector

Without Variable Equalizer

DSIM-SS

Installation Guide Rev B

Page 5 of 18

The DSIM module can be programmed to operate as a single pilot AGC or a thermal AGC.

In the SPAGC mode the DSIM can be programmed to use either an analog or digital pilot

signal from channels 52 to 142. If the pilot channel is lost, the DSIM module will default into a

thermal TGC mode and then return to the single pilot SPAGC mode automatically once the

pilot channel has been restored. In the thermal AGC mode the DSIM module can be

programmed by the operator to have the upfront cable compensation settings at 9, 18, or 27

dB. The DSIM incorporates a bi-colored blue and orange LED that indicates the different

operational modes and settings of the DSIM during setup and operation.

The DSIM controller is used to set the DSIM module’s pilot channel and to change into the

different operational modes during the amplifier setup. The bi-colored blue and red LED

indicator's blinking patterns will denote the current optional mode setting.

The DSIM modules will be configured at the factory to have the default channel 88 digital

(609.00 MHz) pilot channel programmed. The DSIM controller is used to set the DSIM

modules to the customer selected pilot channel. In the setup of the DSIM module the pilot

channel that is programmed into the controller is downloaded into the memory of the DSIM

module. The pilot channel setting in the DSIM module can be changed in the future by

simply using a controller with the new desired pilot channel programmed.

DSIM-SS

Installation Guide Rev B

Page 6 of 18

DSIM Mode Definitions

Operation Mode

Definition

MGC

In the Manual Gain Control (MGC) mode the DSIM automatic gain

control is turned off.

The MGC mode is used during the setup of the station so that no

gain adjustments are made when the levels and slopes are setup.

AGC

In Automatic Gain Control (AGC) mode will make gain adjustments

to the station based on the level changes that occur on the pilot

channel.

TGC

In Thermal Gain Control (TGC) mode the DSIM will make gain

adjustments based on the changes in the internal temperature of

the station. In the TGC mode there is a selection of 9, 18 or 27 dB

for the amount of cable that is in front of the station. The dB of

cable setting is used to more accurately predict actual losses that

occur in the cable with the changes in the outside temperature.

Note: Thermal operational mode should not be used in amplifiers

that are pedestal mounted for underground networks. These units

operate on the assumption that cable temperature will change at

the same rate as amplifier temperature, while amplifiers mounted

in pedestals will vary in temperature far greater than the

underground cable temperature.

DSIM-SS

Installation Guide Rev B

Page 7 of 18

DSIM Mode Flow Chart

MGC mode:

This is the default mode for Amp. Setup

The controller LED will be solid blue

The DSIM LED will blink blue every half sec

Press MODE

once to start the

align process

Align Process:

This takes 45 sec. to lock on to the pilot CH.,

and save the pilot level

The controller will flash blue/ red

The DSIM will flash CH & type pattern

DSIM Locks on to the

channel successfully, it

starts the AGC mode

AGC mode:

The DSIM will maintain pilot level stability

The controller will blink blue every half sec.

The DSIM LED will give a channel &

ch type pattern

If the pilot is too

low, the DSIM

will use the

TGC process

If the pilot drop

more than 10

dB the DSIM

will go to

thermal fallback

Align Process: Thermal Fallback

If the Align Process fails check/ adjust levels or

reduce AGC PAD. return the MGC mode to try

again. DO NOT leave the DSIM in this mode.

The controller will flash blue/ red

The DSIM will flash blue/ orange

AGC mode: Thermal Fallback

The DSIM will calculate the output level until the

pilot channel returns. Then the DSIM will resume

AGC mode.

The controller will blink blue every half sec

The DSIM will flash blue/ orange

Press MODE once to return to MGC mode

TGC mode:

This mode calculates the output level based on

the internal Amp. Temperature

The controller LED will be solid purple

The DSIM LED will give the cable length

(9, 18, 27) dB and three long blinks

Press MODE

once from any

of these 4

modes to go to

TGC mode

DSIM-SS

Installation Guide Rev B

Page 8 of 18

DSIM Controller Operation Instruction Guidelines

Switch

Function

Description

Increase

In MGC Mode, Click to increase RF output level

(See Note 1)

In AGC Mode, no function

In TGC Mode, Click to increase cable length value

Decrease

In MGC Mode, Click to decrease RF output level

(See Note 1)

In AGC Mode, no function

In TGC Mode, Click to decrease cable length value

Mode

Mode Change

In MGC mode, Click to go to Align Mode to load

controller channel setting, DSIM module willthen

automatically switch to AGC mode

In AGC Mode, Click to return to TGC Mode

In TGC Mode, Click to go to MGC Mode

Note 1: Making adjustment to the output levels is only recommended when setting up the

DSIM modules in temperatures bellow 32ºF / 0ºC or above 104ºF / 40ºC.

DSIM Controller Status LED Essentials

LED Blinking Pattern

Indications

Quick Blue / Red Blinks

DSIM controller to module syncing process -

Occurs when controller is installed into the DSIM

module.

Aligning process: in progress

Steady on Blue

In MGC Mode

Series of Blue Blinks

In AGC Mode

Steady on Purple

In TGC Mode

DSIM-SS

Installation Guide Rev B

Page 9 of 18

DSIM Module Status LED Essentials

Operation Blinking Patterns for DSIM Module:

LED Blinking Pattern

Indications

Steady Repeating Blue Dashes

Manual Mode

Series of Blue Blinks

Pilot Channel Number ‐See tables in section 9

at the end of the guide for blinking sequences

Single Blue Long Dash Between Series

of Blue Blinks

Analog channel is set

2 Blue Long Dashes Between Series

of Blue Blinks

Digital channel is set

3 Blue Long Dashes Between Series

of Blue Blinks

TGC Mode‐The default cable length setting for

TGC mode is 27 dB of cable in front of the

amplifier

Quick Blue / Orange Blinks

Pilot paste in progress‐Wait

or Pilot channel not found or lost

LED Fault Conditions Blinking Patterns

LED Blinking Pattern

Indications

Steady on Pink

24 volt input into DSIM module is out of the

operational range of 21.5 to 26.5 VDC. If this

occurs, check for correct AC voltage input to the

amplifier and for correct output DC voltage of

internal power supply to the RF module

Steady Repeating Orange Blinks

Temperature in DSIM module is too high / low

(above 221ºF/105ºC or below -40ºF/-40ºC)

Quick Blue / Orange Blinks

Pilot Lost; DSIM automatically switches to

Thermal (TGC) mode until Pilot channel is

restored.

Note 2: The DSIM LED blinks after the pilot channel count will be orange during

programming and blue when in operation.

Page 10 of 18

DSIM-SS

Installation Guide Rev A

Single Pilot AGC Standard Setup

The DSIM controllers will come preset to have a desired pilot channel stored in the memory.

The controller is used to set the DSIM module to the desired pilot channel by downloading

the pilot channel program into the DSIM module's memory during setup.

Remove the RF module cover and install the DSIM-SS AGC module into theamplifier.

If the outside temperatures are below 40ºF or above 80ºF, then the RF levels will need

to be adjusted to ensure that the full gain compensation range of the DSIM will be

available over the operational temperature range. If the outside temperatures are

between 40ºF and 80ºF then go to step 4.

Using the table bellow adjust the RF output level at highest operating frequency by

pushing the “+" button to increase or the "-“ button to decrease the RF output level.

Pressing the button once is used for small increments, holding the button down isfor

large increments.

Below 0ºF

-2dB

Between 40ºF & 0ºF

-1dB

Between 40ºF & 80ºF

no change

Between 80ºF & 100ºF

+1dB

Above 100ºF

+2dB

If the DSIM-SS has a slope POT use it to set the inter-stageslope.

Check and set desired amplifier levels.

Re-install the RF module faceplate.

Plug the controller cable into the DSIM and plug the controller into the cable.

The controller LED will then flash red / blue rapidly while the DSIM controller andDSIM

module completes the syncing process. This process will take approximately

2-3 seconds to complete.

Once the controller LED stops flashing the red / blue sequence, it should then display a

constant blue, indicating that it is in MGC (manual) mode. Note: If the controller LED is

flashing blue, it indicates that it is in AGC mode; click “Mode” button two times to go

from AGC mode to MGC Manual Mode. In addition, if the controller LED displays a

constant purple, it indicates that it is in TGC mode; click “Mode” button once to go from

TGC to MGC Manual Mode.

10.

Press the 'Mode' once to go to MGC mode. Check that the output level and slope are

correct. Once level and slope are set, press “Mode” once to exit MGC (manual) mode.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere aci Verstärker Handbücher

aci

aci ASA Series Montageanleitung

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung

aci DSIM-SS Bedienungsanleitung

Beliebte Verstärker Handbücher anderer Marken
